Devanco Canada - Get The Right Garage Door Opener‎ and Parts

02-411

LiftMaster Pull Switch Assembly Nema 4

May be used in two different ways: as an OPEN only control (all LiftMaster operators) or as an OPEN/CLOSE control (only LiftMaster operators with types B2 and S2 control wiring).
In the latter case pulling the cord will open a fully closed door close a fully opened door and reverse a closing door.
Pulling the cord whlie the door is opening will either have no effect (type B2 wiring) or will stop the door (Solid State Logic Control Board).

50-104-1

Black Coil Cord 2-Wire 18-ga 20 ft. Extended Curly Cord

Retracted Length=4 Feet Extended Length=20 Feet 2 Wire 18 Gauge Cord Type SJEO

LMWEKITU

LiftMaster Wireless Edge Kit Monitored

Meets 2016 UL 325 requirements
low-energy Bluetooth® transmission up to 130 ft. range
Integrated Diagnostics with Gate Operator Speed Installation
Protects up to 8 entrapment points
Receiver accepts up to 4 transmitters
Transmitter accepts up to 2 wired resistive edges

.......more details

Installation manual Manuel d'installation Instruction manual Manuel d'instructions Product Guide Guide de produit

LD7LP

LiftMaster 10-30VAC/DC Low Power Loop Detector ( 50-DSP7LP )

10-30 VAC/DC low power fail-safe loop detector
<2mA stand-by current draw
Compact design - ideal for linear actuator control boxes
Automatic sensitivity and frequency adjustments
Ideal for solar or battery powered gate applications

LMTBUL

LiftMaster Monitored Through Beam Photo Eye w/ Heater Nema 4X

Tested and evaluated by UL and meet UL 325 requirements.
Long Range powerful beam provides reliable performance.
Sensing distance up to 90 ft.
Anti-Fogging Lens
NEMA 4X rated
Wireless network mode eliminates the need to wire between operators in dual-gate applications.

.......more details

Installation manual Manuel d'installation Product guide

LMWETXU

LiftMaster Wireless Edge Transmitter Monitored

Connects to wireless edge receiver using low-energy Bluetooth transmission
Sensing distance up to 130 ft
Transmitter accepts up to 2 wired resistive edges
Battery life 2 years
NEMA 4X rated
Compatible with LMWEKITU Wireless Edge Kit and L50 and S50 Monitored Resistive Edges

.......more details

Installation manual Manuel d'installation Product Guide Guide de produit

02-103LGO-1

Push Button Station 3-btn Surface Mount O/C/S Nema 1 For LGO Ops only

PBS-3R
Open-Close-Stop
Works with Liftmaster LGO commercial operator
Also known as: 02-103LGO1 02103LGO1
Dimensions: 5-5/16" H x 2-3/8" W x 1-13/16" D
Normally Open contact on Stop therefore it won’t work on any other LiftMaster operator besides the LGO. The 02-103 will work on all operators.

.......more details

LOOPDETLM

LiftMaster plug-in loop detector

Plug-in Loop detector for CSW24V CSL24V AND LA500
Includes diagnostic and test feature
12VDC/3mA power draw
For exit interrupt or shadow loop applications
Activates only when a vehicle passes over a loop
8 sensitivity levels plus boost to ensure that vehicles are easily identified

.......more details

Installation Manual

50-CP4

LiftMaster Sensing Probe Free Exit 100ft Lead

Self-contained free exit system designed to detect moving vehicle and open your automatic gate.
Can be installed above or below ground
Connects directly to any gate operator without an external output board.
Works with powered or solar gates.
SPECIFICATIONS: Cable Lead Length: 100 ft.
Power Requirements: 8-24 VAC oe 8-30 CSX

.......more details

Installation Manual

LMHS120R

LiftMaster Fire Rated Red Horn / Strobe 120VAC

LMHS24R

LiftMaster Fire Rated Red Horn / Strobe 2-Wire 12/24VDC

S50E-PAIR

LiftMaster Small Profile end kit for one edge only 8.2KOhm resistance

Fast easy to install and cost effective system no glue is required
One end for output wire other end with resistor for monitoring
Compatible with S50 Small Profile Edge
Includes: (1) set enough for one edge
p/n 1804-1463

LC-36M

LiftMaster Light Curtain Monitored

The Monitored Light Curtain is a primary safety entrapment protection device that is compliant with UL 325.
IP67 Water-resistant housing anodized aluminum corrosion resistant
Operating Temperature: -40° F to +140° F (-40° C to +60° C)
Liftmaster Compatibility: LOGIC 5.0 Medium-Duty DDO8900W / LJ8900W / LJ8950W / ATSWVFOH HPH1 / HPH2 HCTDCUL Fire Door Egress

Product Guide (EN)Guide du Produit

K26-438

LiftMaster Artisan Timer

For use with various LiftMaster® Speed Jack Commercial Door Operators
Also known as: 26-438 AB117-00121 G26438 438USA
The DIP switches are used to set the time delay period between 1 and 1024 seconds.
The timer has an internal 1 second delay opening of the DIP switches adds their corresponding value to that internal delay.
The switches to the right are all opened for a total delay of 1023 seconds adding that to the internal 1 second provides the full 1024 seconds.
Any time delay from 1 to 1024 seconds can be achieved by opening the appropriate switches.

.......more details

K13-32087

LiftMaster RPM Cup

SL595UL

LMSC1000

LiftMaster RFID Long Range Vehicle Access Card Reader

Easy wall or post mount vehicle tag/prox card reader can service an entire facility parking garage gated community/HOA or guarded properties.
Integrates into (CAPXL CAP2D) Liftmaster PPWR Passport Receiver and LiftMaster CSW24U 24 VDC Commercial Swing Gate Operator CSL24UL HCTDCUL systems to give access via encrypted-digital code.
Opens swing or slides gates from 20-30 feet distance
26-bit Wiegand Interface console
Encrypted binary protocol signal
Helpful Programming/Testing/Function tri-color LEDs on both reader face and Wiegand console

.......more details

Installation manual Manuel d'installation Sell sheet Brochure Wiring the LMSC1000 to KPR2000 Raccordement éléctrique du LMSC1000 au KPR2000

41K4629

LiftMaster CPS Interface Black Box (CPICARD)

Allows CPS-U photoeyes to provide a 'NO' contact
Interface is included with CPS & CPS-N4
Also known as 041K4629 1C4489 41K4629 41C4489 CPI

CPS3CARD

LiftMaster Option Card Only (41K0811)

Works with all commercial Logic versions L2 L3 L4 L5
Use with CPS-U to add a second set of eyes to the operator
Allows activation of Timer-To-Close without CPS-U
Simply plugs into Logic board
Cut resistors on JU1 & R16 to activate timer feature
Same as 041K0811

.......more details

02-110

LiftMaster Tamperproof Two-Position Key Switch

Two Position Key Control Station with STOP button
Indoor Flush Mount (NEMA 1)
Tamperproof
Steel back box with architectural aluminum faceplate and standard key cylinder
OPEN/CLOSE spring return to center (OFF) key removable in center position only with STOP button. Allows complete control of door. May be used with all LiftMaster industrial operators.
