Devanco Canada - Get The Right Garage Door Opener‎ and Parts

RA-AD-WKP-10

Lynx 10-btn Wireless Keypad AD455 372 MHz

Compatibility chart

PRO-HBH-7583U-R

Micanan 3/4HP 208V 3P Heavy-Duty Jackshaft N1 Eyes Monitored ECB Right Hand

3/4 HP208V 3PH Industrial Continuous Duty Jackshaft Operator Ideal for Sectional Doors Rolling Steel
Monitored logic board with integral 372Mhz radio receiver that can hold up to 20 transmitters (MK-00647/ MK-00653/ MK-00659) or 200 of the 1 channel hand held transmitters (MK-00660).
N-1 Through-beam (MK-00649) photocells included. Other options available.
3-btn O/S/C (02-103) wall control station included
Adjustable Friction Clutch 5L320 drive belt
#50 Roller chain 18 tooth door sprocket included

.......more details

MOFR-M14-8

Carlo Gavazzi Photoelectric Sensor Thru-Beam Receiver

Maximum sensing range is 20 meters
11-Pin
8 inch optical beam angle.
Waterproof for harsh environments i.e. water dust steam etc.
To be used with amplifier series S142
Supplied with 15 m of shielded cable.

.......more details

Installation Manual

MOFT20-M14-8

Carlo Gavazzi Photoelectric Sensor Thru-Beam Transmitter

Maximum sensing distance is 20 meters
11-pin
Waterproof for harsh environment i.e. water dust steam etc.
To be used with amplifier series S142.
Supplied with 15 m of shielded cable.
For receiver unit order part no. MOFR-M14-8.

.......more details

Installation Manual

HSC-600-JAWS

Replacement Jaws for Hand Swager

Can be used as replacement jaws for both the HSC-600 hand model and the HSC-600-B bench model

PRO-HBH-10023U-L

Micanan 1 HP 230V 3P Heavy-Duty Jackshaft N1 Eyes Monitored ECB Left Hand (Pro-HHD)

1 HP230V 3 PH Industrial Continuous Duty Jackshaft Operator Ideal for Sectional Doors Rolling Steel
Monitored logic board with integral 372Mhz radio receiver that can hold up to 20 transmitters (MK-00647/ MK-00653/ MK-00659) or 200 of the 1 channel hand held transmitters (MK-00660).
N-1 Through-beam (MK-00649) photocells included. Other options available.
3-btn o/s/c (02-103) wall control station included
Adjustable Friction Clutch 5L320 drive belt
#50 Roller chain 18 tooth door sprocket included

.......more details

SMR7620TP5

Telco Thru Beam Receiver M18

Supply voltage: 10 - 30 V dc
Control Feature: Sensitivity pot. and light/dark switch
Sensing range: 20 m
Output Status: N.C./N.O.
Housing: 18 x 1 Plastic
5M cable

.......more details

1086090001.S

Overhead Drive Gear for Overhead 556

White plastic gear only for Overhead model 556

PS241F

Adjustable Regulated Power Supply with Optional BBU 6-24VDC 1AMP

3 preset voltages: 6 12 and 24 VDC
Full adjustment from 2 to 24 VDC if required
Requires AC transformer for input power (minimum 14 VAC for 12 VDC output 26 VAC for 24 VDC output cannot be connected directly to 120 VAC)
Maximum 1 amp. Output at 70 deg. F and free air
Ripple: Minimum load: 0.007vrms Half load: 0.028vrms Maximum load: 0.057vrms
Regulation: 97.5%

.......more details

Wiring Diagram Diagramme de raccordement Spec Sheet Spécifications

20113R

Genie Limit Switch Screw Drive

For use on Genie screw-drive openers.
Compatible with ALL Genie Screw and Trac Drive garage door openers with standard rail assemblies
Replaces either the UP or the DOWN limit switch
Replaces Genie Genius Trac Drive limit switch models 19795S and 22785R
Not compatible with excelerator models

MT21-BLACK-RH

Miller Edge 2-Wire Pressure Sensitive Edge Black Right Hand Outlet Sold per Foot

��Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

Worksheet Installation manual Sell sheet

GALV-393-6-144-R

Torsion Spring .393 x 6" x 12ft RH Galvanized Orange

Wire size: .393
Inside diameter: 6"
Length: 12 ft
Galvanized Stenciled

OTBH-6234-1M00

Manaras Trolley Operator 1 HP 208V 3 Ph monitored w/N1 Eyes

Heavy-duty low headroom trolley operator designed for use on industrial standard lift sectional door
25 cycles per hour 80 cycles per day
It incorporates a drum-band type solenoid brake.
Tracks are an extra 36 lbs per track
3/4 HP & 1 HP operators come with #41 full roller chain

HYBRID-BLK-14

Residential Side & Top PVC/Aluminum W/S with cap 14' Long (169") - Black

Black rigid vinyl retainer with aluminum cap and black flexible vinyl seal.
Dual fin vinyl.
Comes with aluminum slide-on cap to hide screws.

HYBRID-BLK-16

Residential Side & Top PVC/Aluminum W/S with cap 16' Long (193") - Black

Black rigid vinyl retainer with aluminum cap and black flexible vinyl seal.
Dual fin vinyl.
Comes with aluminum slide-on cap to hide screws.

HAE00047

Linear Complete Gear Set with Grease

Set includes: Helical gear worm gears and grease
Helical gear measures 2-7/8" diameter

LB412-18SF

Steel Faced Laminated Bumper Black 12" x 18" 4" Projection Horizontal Installation

Used on docks where excessive friction from up and down trailer movement occurs (yard jockeys air ride trailers etc.).
Can be used in material handling application where medium to heavy dock protection is required
“Gliding” heavy-duty steel face is 3/8” thick and independently anchored with elongated holes to face of bumper allowing bumper to compress AND offer high surface abrasion resistance
Rubber pads laminated between steel angles and secured with 3/4” rods
Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
Wall mounting hole size is 7/8” diameter.

.......more details

LB1212-14

Laminated Bumper Standard Black 12" L x 14" W 12" Projection Horizontal Installation

For use in low to medium traffic loading docks in factories and warehouses.
Can be used as rub rails at the sides of truck wells
Fabric reinforced rubber pads cut from recycled truck tires.
Rubber pads laminated between steel angles and secured with 3/4” rods
Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
Wall mounting hole size is 7/8” diameter.

.......more details
