Home Dock Equipment
MF-341-011

Serco Manual Brake Band

  • For use with Serco brand dock levelers
LB610-14

Laminated Bumper Standard Black 10" x 14" 6" Projection Horizontal Installation

  • For use in low to medium traffic loading docks in factories and warehouses.
  • Can be used as rub rails at the sides of truck wells
  • Fabric reinforced rubber pads cut from recycled truck tires.
  • Rubber pads laminated between steel angles and secured with 3/4” rods
  • Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
  • Wall mounting hole size is 7/8” diameter.
    • .......more details
LVB420-11/P1

Laminated Bumper Black 4" Projection Vertical Installation 20" x 11" Sold Individually Style P1

  • For use in low to medium traffic loading docks in factories and warehouses.
  • Can be used as rub rails at the sides of truck wells
  • Fabric reinforced rubber pads cut from recycled truck tires.
  • Rubber pads laminated between steel angles and secured with 3/4” rods
  • Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
  • Wall mounting hole size is 1” diameter.
    • .......more details
Specification Sheet
LVB420-11

Laminated Bumper Black 4" Projection Vertical Installation 20" x 11" Sold Individually

  • For use in low to medium traffic loading docks in factories and warehouses.
  • Can be used as rub rails at the sides of truck wells
  • Fabric reinforced rubber pads cut from recycled truck tires.
  • Rubber pads laminated between steel angles and secured with 3/4” rods
  • Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
  • Wall mounting hole size is 1” diameter.
    • .......more details
LVB620-11

Laminated Bumper Black 6" Projection Vertical Installation 20" x 11" Sold Individually

  • For use in low to medium traffic loading docks in factories and warehouses.
  • Can be used as rub rails at the sides of truck wells
  • Fabric reinforced rubber pads cut from recycled truck tires.
  • Rubber pads laminated between steel angles and secured with 3/4” rods
  • Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
  • Wall mounting hole size is 7/8” diameter.
    • .......more details
60-7248-CMH94

Wheel Chock Safety Pkg incl'd: chock with integral handle wall bracket 15' chain 3/8" x 1 7/8" anchors (4) & 3/16" quick links (2)

  • System Includes (1) CMH-94 Chock Bracket Tie Back Chain English and French Caution Signs and (4) Wall Bracket Anchors
  • One Piece Solid Rubber
  • Integral Handle
  • Long Lasting 80 Durometer rubber
  • Size: 7-1/4" wide x 9-3/4" long x 7-3/4" high
DB13-T

Molded Rubber Bumper Black 13" L x 10" W 4" Projection 2-Hole Tapered Sides Sold Individually

  • Manufactured from reinforced prime rubber
  • Rectangular horizontal mount
  • 4-1/2" depth
  • Ideal for light traffic loading docks.
  • Molded bumpers are molded in one piece and will not warp rust rot or harden.
  • Perfect protection for in-plant wall protection from forklifts and other material handling vehicles. and will not warp rust rot or harden.
    • .......more details
TRACK-GUARD-48

Track Guard 48" Tall Safety Yellow With Base Sold as a Pair

  • Provides impact protection to vertical track
  • 45° angle flange adds strength protects from side impact.
  • 7-gauge steel construction powder coated safety yellow for high visibility.
  • 1/4” foot plate drilled with slotted holes for three 1/2” anchors.
  • Wall flange drilled with slotted holes for four 3/8” anchors
  • Includes: 60-5094 (right) and 60-5095 (left) sides
    • .......more details
48"Track Guard Shop Drawing - Left48"Track Guard Shop Drawing - Right
TRACK-GUARD-36

Track Guard 36" Tall Safety Yellow With Base Sold as a Pair *** To Extent of Inventory

  • Provides impact protection to vertical track
  • 45° angle flange adds strength protects from side impact.
  • 7-gauge steel construction powder coated safety yellow for high visibility.
  • 1/4” foot plate drilled with slotted holes for three 1/2” anchors.
  • Wall flange drilled with slotted holes for four 3/8” anchors
  • Includes: 60-5092 (right) and 60-5093 (left) sides
    • .......more details
TRACK-GUARD-60

Track Guard 60" Tall Safety Yellow With Base Sold as a Pair

  • Provides impact protection to vertical track
  • 45° angle flange adds strength protects from side impact.
  • 7-gauge steel construction powder coated safety yellow for high visibility.
  • 1/4” foot plate drilled with slotted holes for three 1/2” anchors.
  • Wall flange drilled with slotted holes for four 3/8” anchors
  • Includes: (right) and (left) sides
    • .......more details
TRACK-GUARD-72

Track Guard 72" Tall Safety Yellow With Base Sold as a Pair

  • Provides impact protection to vertical track
  • 45° angle flange adds strength protects from side impact.
  • 7-gauge steel construction powder coated safety yellow for high visibility.
  • 1/4” foot plate drilled with slotted holes for three 1/2” anchors.
  • Wall flange drilled with slotted holes for four 3/8” anchors
  • Includes: 60-5094 (right) and 60-5095 (left) sides
    • .......more details
72"Track Guard Shop Drawing - Left72"Track Guard Shop Drawing - Right
RATCHET_BAR

Ratchet Bar for Holdown Assembly 8-8786 ** Quote Only

LVB420-11SF/P2

Steel-Faced Laminated Bumper Black 4" Projection Vertical Installation 20" x 11" Sold Individually Style P2

  • Used on docks where excessive friction from up and down trailer movement occurs (yard jockeys air ride trailers etc.).
  • Can be used in material handling application where medium to heavy dock protection is required.
  • 5/8" anchor bolts mounted through pre-drilled holes into dock or can be welded to curb angle.
  • Steel face is 3/8" thick heavy duty high carbon steel that is mounted over a laminated dock bumper.
  • Plate to be welded to 2 or 3 steel support brackets which are to extend back to the 3/4" supporting rods.
  • Brackets to be punched with elongated holes to allow steel face to "float" upon impact.
    • .......more details
LVB420-11SF/P1

Steel-Faced Laminated Bumper Black 4" Projection Vertical Installation 20" x 11" Sold Individually Style P1

  • Used on docks where excessive friction from up and down trailer movement occurs (yard jockeys air ride trailers etc.).
  • Can be used in material handling application where medium to heavy dock protection is required.
  • 5/8" anchor bolts mounted through pre-drilled holes into dock or can be welded to curb angle.
  • Steel face is 3/8" thick heavy duty high carbon steel that is mounted over a laminated dock bumper.
  • Plate to be welded to 2 or 3 steel support brackets which are to extend back to the 3/4" supporting rods.
  • Brackets to be punched with elongated holes to allow steel face to "float" upon impact.
    • .......more details
LB610-102

Laminated Bumper Standard Black 102" x 10" 6" Projection Horizontal Installation

  • For use in low to medium traffic loading docks in factories and warehouses.
  • Can be used as rub rails at the sides of truck wells
  • Fabric reinforced rubber pads cut from recycled truck tires.
  • Rubber pads laminated between steel angles and secured with 3/4” rods
  • Bumper is fastened to dock surface with 3/8” steel angles and/or flat plates depending on the model chosen.
  • Wall mounting hole size is 7/8” diameter.
    • .......more details
TB-20

Molded Rubber Bumper Black 3 1/2" L x 6" W 3 1/2" Projection 2-Hole Sold Individually

  • Manufactured from reinforced prime rubber
  • Rectangular horizontal mount
  • Molded Truck Bumper molded in one piece and will not warp rust rot or harden.
  • Bumper comes with 2 pre-drilled countersunk mounting holes drilled to accept 3/4" anchor bolts
  • 3 1/2" L x 6" W 3 1/2" Projection
D4-120

Extruded Bumper Black 120" L x 4 1/2" W x 3 3/4" H w/Metal Insert

  • Sold in 10' Lengths and cut to measure
  • Includes 10' Metal Washer Insert
  • Comes with 5 Holes for mounting or none - Please Specify When Ordering Bumper
D4-12

Extruded Bumper Black 12" L x 4 1/2" W x 3 3/4" H w/Metal Insert

  • Reinforced prime rubber of Durometer 75 (±5) (ASTM D2240)
  • 8.3 N/mm2 (±0.5) Tensile Strength (ASTM D792)
  • 98% (±2) impact recovery
  • All extruded fenders are supplied with a metal washer insert
D4-18

Extruded Bumper Black 18" L x 4 1/2" W x 3 3/4" H w/Metal Insert

  • Reinforced prime rubber of Durometer 75 (±5) (ASTM D2240)
  • 8.3 N/mm2 (±0.5) Tensile Strength (ASTM D792)
  • 98% (±2) impact recovery
  • All extruded fenders are supplied with a metal washer insert
LVB420-11SF

Steel-Faced Laminated Bumper Black 4" Projection Vertical Installation 20" x 11" Sold Individually

  • Used on docks where excessive friction from up and down trailer movement occurs (yard jockeys air ride trailers etc.).
  • Can be used in material handling application where medium to heavy dock protection is required.
  • 5/8" anchor bolts mounted through pre-drilled holes into dock or can be welded to curb angle.
  • Steel face is 3/8" thick heavy duty high carbon steel that is mounted over a laminated dock bumper.
  • Plate to be welded to 2 or 3 steel support brackets which are to extend back to the 3/4" supporting rods.
  • Brackets to be punched with elongated holes to allow steel face to "float" upon impact.
    • .......more details
