INTERFACE003

Manaras Y-Connect Signal Merging Module

  • N4 compatible with 2 x monitored entrapment protection devices
  • Compatible primary devices: PHOTO061/061A/065/070
  • Secondary devices: monitored photocells light curtains electric sensing edges and/or non-contact sensing edges
Installation manual
RADIO-EM101

Manaras 1-btn 1-door Rolling Code transmitter 390 MHz

  • 2 operating sequences available: open/close or single button control.
  • Single button control allows the user the possibility to open stop or close the door by using the one button.
  • Comes with LED indicator CR2032 battery and visor clip.
  • Compatible with Manaras operators manufactured after August 2013 with control board070E & board070M.
LIMIT024

Manaras Double Snap-Action Limit Switch with Flat Lever

  • Replacement for LIMIT003
  • 2x SPDT - Unimax
  • Same as Doorlec # 21702
Limit Switch Chart
RADIO-EM901

Manaras 1-btn Mini Transmitter 313 MHz

  • Open/Close mini remote for 1 door
  • Comes with LED battery life indicator
  • Mini 12V battery included
  • Key chain holder included
  • Replaces RADIO-28
  • 10-dip switches
    • .......more details
ManualProgramming Instructions
LIMIT023

Manaras Single Limit Switch with 46 degree Lever

  • Single limit switch (SPDT) used to stop the door at top and bottom or as disconnect switch
  • Unimax
  • Snap-action.
SPREADER002

Chain Tensioner for 1" / 1-1/4"

  • Chain spreader for installation with 1" operator shaft and 1-1/4" door shaft
  • Designed to keep tension on the chain when used with a wall mount commercial operator. It helps avoid premature wear on the door shaft bearing and commercial operator output shaft bearing
Installation instructions
BRAKEPART019

Manaras Brake Band Assembly (Standard Brake)

  • Replaces BRAKEPART017 SHOE008
  • To use on brake drums with edges (DRUM004)
  • New part number is BRAKEPART019KIT
Installation Manual
MSJ-6213-M-N1-LH

Manaras MSJ 3/4HP 240V 1Ph Monitored Board w/N1 Eyes Left Hand

  • An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
  • For use on Standard High and Vertical Lift sectional doors
  • Can also be used on Rolling doors and Grilles
  • Comes with a chain hoist for manual operation and a floor level engaging device
  • Clearence: side room required 16"
  • 35 cycles per day > 150 cycles per day
    • .......more details
OSH-6213-M-N1-RH

Manaras Opera-SH 3/4 HP 240V 1 Ph Monitored ECB w/N1 Photoeyes Right Hand

  • An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
  • For use on Standard High and Vertical Lift sectional doors
  • Can also be used on Rolling doors and Grilles
  • Comes with a chain hoist for manual operation and a floor level engaging device
  • Clearence: side room required 16"
  • 25 cycles per day > 100 cycles per day
    • .......more details
Installation Manual
SPREADER001

Chain Tensioner for 1" shafts

  • Chain spreader for installation with 1" operator shaft & 1" door shaft.
  • Includes 2 shaft collars and set screws.
  • Designed to keep tension on the chain when used with a wall mount commercial operator. It helps avoid premature wear on the door shaft bearing and commercial operator output shaft bearing
Installation instructions
TRANSF142

Manaras Transformer 575-24V 40VA

  • Transformer 575V Primary 24V Secondary 40VA
BOARD075E

Manaras Replacement Board Kit (No Monitoring)

  • Replacement kit that includes BOARD070E (control board) & BOARD066R (power board)
  • BOARD070E is for standard operators without the monitoring function
  • For all Manaras operators built after October 2010
  • On-board 390MHz radio receiver accepts 50 remote controls
  • For older models built before October 2010 use BOARD060 or replacement kit BOARD065
Replacement ChartGuide de remplacement
OSH-6232-M-N1-LH

Manaras Opera-SH 1/2 HP 208V 3 Ph Monitored ECB w/N1 Photoeyes Left Hand

  • An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
  • For use on Standard High and Vertical Lift sectional doors
  • Can also be used on Rolling doors and Grilles
  • Comes with a chain hoist for manual operation and a floor level engaging device
  • Clearence: side room required 16"
Installation Manual
PHOTO-070

Manaras Monitored Photoelectric Cells N1 Thru-Beam 45' Range

  • Monitored NEMA 1 enclosure through-beam type photocell
  • 4-Wire
  • Indoor
  • Range: 45 ft
Manual
OSH-6113-M-N1-RH

Manaras Opera-SH 3/4HP 120V 1Ph Monitored Board w/N1 Eyes RH

  • An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
  • For use on Standard High and Vertical Lift sectional doors
  • Can also be used on Rolling doors and Grilles
  • Comes with a chain hoist for manual operation and a floor level engaging device
  • Clearence: side room required 16"
  • 25 cycles per day > 100 cycles per day
    • .......more details
Installation ManualSell Sheet
VBELTB29

Manaras VBelt 5L 29" Type B (5L320)

  • For models OPJ OHJ OPH & OSH
  • Same as 5L320
VBELT_5L350

Manaras VBelt 5L 35" - repl. by B32

  • Used on MTH MTBH MSL models
  • Type B
  • Inside length 32 inches
CAPACITOR008R

Manaras Capacitor 440-648uf incl. Bleeder Resistor

  • Used for 3/4 HP 120/230VAC 1 ph motor255 374 & 258
  • Also for 1 HP 120/230V 1 ph motor350
CONTACTOR044

Manaras Schneider Reversing Contactor 12A-24VAC

  • Reversing contactor with 24V coil
  • Same as part # LC2K12107B7
  • Demensions: 3.5" long x 2.25" wide x 2.25" high
  • Use 03-8024K as possible replacement
RADIO-EM103MD

Manaras 3-btn transmitter configured as 3x single-btn Multiple Doors Rolling Code 390 MHz

  • Open/Close remote for 3 doors
  • LED indicator CR2032 battery and visor clip included
  • Field Selectable: Jumper inside the remote can be positioned to Single Door (SD) or Multiple Door (MD)
  • Compatible with Manaras operators manufactured after August 2013 with control board070E & board070M.
Manual
