Home Your Search Miller Edge
MT22-YELLOW-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • €˘Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MU33-2WIRE-LH-Y

Miller Edge MU33 2-Wire NM Left Hand Yellow - Sold per Foot

  • MU style bumpers are designed for use with aircraft hanger doors and large specialty doors.
  • Must specify the exact length in feet and inches when ordering.
  • Mounts vertically or horizontally
  • Sensitivity: nominal 8-13 ibf
Worksheet
MWT12B

Miller Edge Transmitter Binary Nema 4 Enclosure

  • The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
  • Response time: 70 milliseconds
    • .......more details
Installation Instructions MWT12BSpec Sheet MWT12BFAQ MWT12B
ME116-BLK-LH

Miller Edge Black Left Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
MWTA12B

Miller Edge Transmitter with Low Battery Alarm Small

  • The transmitter comes standard with a NEMA 4 weather-proof enclosure
  • Compact design that allow for easy troubleshooting.
  • The transmitter has an audible alarm that activates when the battery has 25% of its life remaining
  • Easy to configure · Non-monitored system ideal for operators manufactured prior to: · Doors: August 2010 · Gates: January 2016 · NEMA 4 transmitter built to endure rugged environments
  • Power Source: (2) 1.5 volts AA lithium batteries
  • Input: 2-wire N.O. sensing edge
    • .......more details
Installation manualSpec sheet
ME120-BLK-E-4FT

Miller Edge 2-Wire Black End Outlet 4 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
MT22-BLACK-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • €˘Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
RB-TX10C

Miller Edge RBand Monitored Wireless Edge Transmitter

  • RBand transmitter only
  • On board diagnostics allows for easy set up and troubleshooting.
  • Offers pulsed and normally open outputs.
  • Ideal for commercial door operators manufactured after 2010.
  • Bi-directional link improves immunity to RF interference.
  • Nema 4
    • .......more details
RB-P-K10C

Miller Edge RBand Monitored Wireless Door Edge System

  • RBand is a monitored sensing edge transmitter/receiver system.
  • The receiver can be paired with up to three transmitters.
  • On board diagnosticsallows for easy set up and troubleshooting.
  • Offers pulsed and normally open outputs.
  • Ideal for commercial door operators manufactured after 2010.
  • Bi-directional link improves immunity to RF interference.
    • .......more details
MGR20-B-2U-PER-FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Sold Per Foot

  • €˘Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
  • Non-monitored edge
  • Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)
ME123-BLK-U

Miller Edge Black Universal Outlet 2 -Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
MWR22B

Miller Edge 2-Channel Wireless Edge Receiver RF 318 MHz

  • Power source: 12-24 volts AC/DC nominal Nominal 60 mA 140 mA activated
  • Output: N.O. N.C
  • Wire connections: Integral 18” wiring with #6 spade lugs
  • Antenna: Attached wire or F connector
  • LED Indicators: Power channel 1
  • Polycarbonate enclosure
    • .......more details
MT22-YELLOW-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • €˘Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
ME123-BLK-LH

Miller Edge Black Left Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
MWR12

Miller Edge 1-Channel Receiver RF 318 MHz *** To Extent of Inventory

  • €˘The MWR12 receiver is designed to receive information from the transmitter and relay it to the motor to stop or reverse motion if the edge comes into contact with an obstruction.
  • Power requirements: 10 to 40 VDC 10-30 VAC
  • Output: dry relay contact N/O and N/C 1A @60VAC
  • Operating temperature: -40C to 60C
  • Maximum operating distance: 100ft
  • Electrical configuration: optional N/O or N/C
    • .......more details
Installation ManualSell Sheet
CPT215-END-KIT-T3

Miller Edge End Kit for CPT215 Doide Capacitor (T3) Configuration

  • Kit contains: 2) Caps (2) cages (1) wired plug (1) diode capacitor plug (1) non-mon. plug (2) screws
CPT215-END-KIT-T2

Miller Edge End Kit for CPT215 10K Ohm Resistor (T2) Configuration

  • Kit contains: (2) Caps (2) cages (1) wired plug (1) 10K plug (1) non-mon. plug (2) screws
  • No glue is required
CPT-215-50

Miller Edge Field Configurable Sensing Edge 50 ft Roll

  • For do-it-yourself edges on sectional or rolling doors.
  • Black extrusion flexible PVC conductive polymer Ends: Molded polymer
  • End plugs and mounting channel sold separately.
  • Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
  • When combined with the ME123 mounting channel ideal for 2" thick surfaces
  • Lead Wire 12 in. 22 gauge SJTO
    • .......more details
ME120-Y-4E-P/FT

Miller Edge Sensing Edge Yellow 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME123-CA3

Miller Edge L-Shaped Aluminum Mounting Channel Sold by the Foot
