DXT-21

A battery powered portable transmitter designed for use with Linear’s DX Format receivers.
Each transmitter can be used in a limitless number of wireless remote control applications.
Pressing a button on the transmitter sends a digitally coded wireless signal to its companion receiver
The digital DX code format features over a million possible codes.
The DX transmitters are precoded at the factory to unique codes so no field coding is required
Powered by two 3-Volt #2032 lithium batteries included

Installation Manual

DXR-701

A digital receiver with an isolated relay output designed for use with Linear's DX Format transmitters.
When the receiver detects a signal from a transmitter programmed into its memory the relay output activates.
The relay has four optional output configurations.
32 transmitter capacity
RF activity indicator
Quick-learn programming

Installation Manual

105104

105104 is for adding obstacle sensing for motorized gates or barrier arms.
Using a safety edge transmitter is more economical and discrete than the traditional coiled cord connection method.
The transmitter mounts directly on the gate or barrier arm and wires to a standard exterior safety edge sensor.
Compatible with 310 MHz Stanley receivers and Model 109950 302850 and 309013 receivers.
Activates receiver for stop or reverse entrapment
No cables or coiled wires

Installation Manual

DXT-42

Battery powered portable miniature transmitter designed for use with Linear’s DX Format receivers.
Each transmitter can be used in a limitless number of wireless remote control applications.
Pressing a transmitter button sends a digitally coded wireless signal to its companion receiver. The transmitter buttons have a positive click feel.
The digital DX code format features over a million possible codes.
The DX transmitters are precoded at the factory to unique codes so no field coding is required. Transmitters can send a signal for up to 10 seconds with each button activation.
Each button sends a unique code. Pressing both buttons together sends code three. Press button(s) for a minimum of two seconds to insure receiver activation.

Installation Manual

308911

Installation Manual

412001

Installation Manual

2200-030

AK-21W

A digital keyless entry system designed for outdoor access control applications.
The keypad is housed in a rugged die-cast metal enclosure and is designed to be mounted in a standard single-gang electrical box.
The die-cast keys have bright easy-to-read yellow graphics.
Up to 480 entry codes from 1 to 6 digits in length can be programmed. They can activate either or both of the relay outputs.
Relay #1 has a 5 Amp capacity. Relay #2 has a 1 Amp capacity. The relays can be set for timed or latch-on/latch-off toggle operation per each individual entry code

Installation Manual

AK-21

The keypad is housed in a rugged plastic enclosure and is designed to be mounted in a standard single-gang electrical box. The die-cast keys have bright easy-to-read yellow graphics.
It is supplied with four different plastic snap-on mounting bezels to customize the look of the keypad. The satin-chrome bezel comes factory installed on the keypad. The white ivory & bronze bezels are packaged separately.
Up to 480 entry codes from 1 to 6 digits in length can be programmed. They can activate either or both of the relay outputs.
Relay #1 has a 5 Amp capacity. Relay #2 has a 1 Amp capacity. The relays can be set for timed or latch-on/latch-off toggle operation per each individual entry code.
The on or off toggle state of a relay is maintained even after power interruption. When power is restored to the keypad each relay will assume the state it was in when power was removed.

Installation Manual

SLR-221

Integral entrapment sensing system with digital set point for quick accurate adjustment and enhanced safety
Continuous-tone entrapment alarm with reset button
LED diagnostic display for ease of setup and troubleshooting
Selectable pre-start and run alarm with provision for ADA compliant visual pre-start and run alarm
Regulated 24 Volt DC power available for access control accessories
Integrated maximum run and auto close timer (0-9 minutes)
