SSZP24

Solid Shaft 1" Keyed Zinc Plated 24'

466LMC

LiftMaster Wireless Commercial Keypad 390 MHz ** Discontinued

Up to 100 000 individual codes
Mounts to wall or gooseneck post
Incl. 6-volt alkaline battery
Illuminated stainless steel faceplate and keypad
Tamper-resistant case and "low battery" indicator
Requires 412HMC receiver
Dimensions: 5" W x 6" H x 5 1/2" Depth. Tapers 4 1/2"
Replacement antenna kit K001C3196-1 (also known as 161A21)

Installation Manual Sell Sheet

PROMI-500

Erone 1-Door Stand Alone Card Reader / Keypad **DISC

500 users (proximity badges and/or codes)
3 operating modes: - Mode 0: badge and code - Mode 1: badge only - Mode 2: badge or code
Audible & Visual feedback
1 request-to-exit input
Tamper switch
1 form C door relay output (3A/125V)

.......more details

PROMI-500 Wiring Diagram & Instructions

08-11012

LiftMaster Bevel Gear 5/8" ID

Fits LiftMaster GH operator

MX00149

Micanan Complete Clutch Shaft Assembly for PRO-H

GC-100

Devanco Foaming Glass Cleaner 538g

A powerful foaming glass cleaner goes on thick does not run and wipes off clean
Does not leave streaks or an oily film on the glass
Virtually odorless

Safety data sheet Fiche de données de sécurité

MGT

Linear MegaCode Gate Safety Edge Transmitter 318 MHz (DNT00068)

The MGT is the industry’s only fully supervised gate safety edge transmitter.
It automatically sends an hourly status report to the access controller indicating battery condition and if the transmitter is operational.
Should the edge sensor be disconnected shorted or tampered with the MGT will report a trouble condition.
Features Include:
Signals access controller for stop or reverse when safety edge activates
No cables or coiled wires

.......more details

Programming Instructions

MDKP

Linear MegaCode Exterior Wireless Keypad 318 MHz

MDKP can transmit a unique signal for each 1-6 digit PIN code entered.
It has a built-in radio transmitter with a 250-foot range in line-of-sight conditions.
Access codes are programmed into the access controller or receiver the maximum number of codes possible depends on the receiver model used.
Features Include:
Internal antenna
1-6 digit PIN for each user

.......more details

Installation Manual

15-50B18QGH

Sprocket 18 Teeth 1-1/4" Bore 1/4" Keyway

AW-12A

Miller Edge Air Wave Switch in NEMA 4 Enclosure

Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
Applications: commercial sectional doors rolling doors and mass transit
Works on doors up to 60ft
Can be used with standard pneumatic hose and Miller Edge extrusion
Sensitivity: 2mm to 500mm
Ambient temperature range: -49F to 180F

.......more details

Instructions Manual Sell Sheet

85LMC

LiftMaster Plug-In Power Supply

Plug-in jack for easy installation on Liftmaster receivers
Power input level: 105-135AC 24AC output

50-105

LiftMaster Black Coil Cord 4-Wire 18-ga 20 ft. Extended Curly Cord

.283-2-R

Cut-to-Length Torsion Spring .283 x 2" Right Hand Wound White

Priced per inch - cones sold seperately
For factory installed cones use part no. C-200-INSTALLED

109950

Linear 1-Channel Multi-Code Gate Receiver 12-24V

Operates on 12-24 volts AC or DC power
One channel
Whip antenna
3-foot antenna coax and bulkhead connector
Codes: 1024 (set by dip switches)
RF frequency: 300 MHz or 310 MHz (jumper selectable)

.......more details

Programming Instructions

19-10929

LiftMaster Hoist Chain Sold by the Foot

and Chain for LiftMaster commercial hoist operators

8FT-RAIL-CHAIN

LiftMaster 8' chain drive rail 1708LMC - colour code: Blue

#48 chain size
Price reflects cost if purchased with an opener

365LMC

LiftMaster Universal Plug-in Receiver 315 MHz

Compatible with any garage door opener with a simple 2-wire dry contact
Includes 2-conductor bell wire
Able to accept 8 Security+ transmitters & 1 digital keypad
Compatible remotes; 893MAX 890MAX 892LT 373LM 371LM 374UT 375UT

Programming Instructions Instructions de programmation

41A3489

LiftMaster Complete Trolley Assembly for chain drive

For chain drive models 1984 +
Compatible with Sears Chamberlain

Installation Manual

41A5021-I

LiftMaster Electronic Circuit Board Assembly ** Discontinued. No Stock Left

Assembly includes: Logic board end panel and light socket
For chain drive models with 2-lights
Fits 1265 Security + 390MHz
Also known as; 41A5021 41A5021-B 41A5021-C 41A5021-D 41A5021-E 41A5021-F 41A5021-G 41A5021-H

23-10041-1

LiftMaster Double Limit Switch Commercial DP DT

Double limit switch DP DT
For LiftMaster and Micanan operators

RA-LYNX-RCVR

Lynx External Receiver

Add to most operator systems
Use with either residential or commercial applications
Unlimited transmitter capacity

Programming instructions Compatibility chart

LIMIT006

Manaras Single Micro Limit Switch with Flat Lever

Fits old medium-duty Manaras operators such as MDJ
SPDT - Cherry

Limit Switch Chart

108210

Linear 1-Channel Multi-Code Key Ring Transmitter 310 MHz

Open/Close mini remote for 1 door
Compatible with 310 MHz Stanley and Multi-Code receivers
Easy access to battery and coding switches - 10 dip switches
Power: 12-volt battery
Codes: 1024 (set by dip switches)
RF frequency: 310 MHz

.......more details

Programming Instructions

DR4

Linear 4-Channel Delta3 Receiver 310 MHz *** To Extent of Inventory

Activates four devices or UP DOWN STOP for one commercial device
310 MHz 8 dip switch
Power: 24 VAC/VDC
Dimensions: 4.9" W x 4.2" H x 1.3" D
Same as DNR00023A or DR4V

Programming Instructions

DT2A

Linear 2-btn Delta3 Transmitter 310 MHz (DNT00017A)

Activates two Delta-3 receivers independently
Test/operate LED
Visor mounting clip supplied
Power: 9-volt battery
Codes: 256 (set by dip switches)
RF frequency: 310 MHz

.......more details

Programming Instructions

HAE00022

Linear Inner Slide Assembly - Belt (HBT)

24-RWB-PAIR

Winding Bars Round 24" Set of 2

Cold rolled hardened steel.
Machined to 1/2" at one end with 5/8" outside dia. on the other.
Sold as a pair.

25-42-70

Extension Spring 7' Door - 70 lbs Orange

Double - Loop
25" long 42" stretch 70 lb load
Sold individually
Rated for 10000 cycles

Spec Sheet

28-02290

Truck Door 2" Vertical Track & Right Angle Assembly 96.5" Curbside (RH) for Whiting Roll-Up Doors

SPECS: Length: 96.5" Fits door sizes: 72" - 90" high
Assembly includes: Right angle mounting track Vertical track and Torsion bracket
Cross Reference: W #2275-1
Galvanized steel 14 gauge construction
Tongue and groove for proper alignment at joints

DM54

Cable Drum High Lift 54" 5250-54 Pair

54" High Lift aluminum die cast alloy.
3/8"-16x2" hardened cup point set screws installed with red heads.
Color coded: Red-LH and Black=RH.
Maximum High Lift: 54" Maximum Door Height: 180" + High Lift
Rated lift per drum: 500 lbs 1000 lbs per door max
Maximum cable diameter: 3/16"

.......more details

DM32

Cable Drum Standard Lift 32' 800-32 Pair

32' Standard Lift aluminum die cast alloy for a 1" solid shaft. Pair includes: (1) LH and (1) RH. Color coded: Red=LH and Black=RH
Max. Door Height: 32'-1".
Rated Lift per Drum: 1000 lbs
Max. Cable Diameter: 1/4".
Mounting: 1" solid shaft with 1/4" keyway
Cross Reference: D800-384 DNS 402-32 OMI 2300

.......more details

Z9401

Coupler 1" Bore Non-Ajustable

Non-Adjustable Shaft Coupler Steel Zinc plated
1" Bore
L= 4.7" 3 screws and nuts
Tightening torque on shaft: 20lb-ft max

DM18-125

Cable Drum Vertical Lift 18' 1100-18 (1-1/4") Pair

18' Vertical Lift aluminum die cast alloy cable drums for 1-1/4" shaft.
3/8"-16 x2" hardened cup point set screws installed with red heads.
Color coded: Red=LH and Black=RH. Pair includes (1) LH and (1) RH.
Max. Door Height: 18'-1".
Rated Lift per Drum: 660 lbs.
Max. Cable Diameter: 3/16".

.......more details

H11G08

Hinge #8 x 11 gauge

11 gauge #8 hinge - 0.87 lbs
Bright zinc-plated steel construction
For use with 7/16" stem rollers

R5210

Pulley 4" Zinc Plated Steel with Sheave Strap

Bored for 3/8" diameter bolt
Maximum cable diameter: 1/4"
Hardened inner race
Includes fork

41A2817

LiftMaster Drive Gear and Worm Kit (No Sprocket)

Also known as: 081B0045 062216 081C0179 81B45 2612159

Installation Manual Manuel d'Installation

25-10050

Truck Door Center Hinge Zinc for Todco Roll-Up Doors

Zinc plated Steel construction
Cross Reference: T #61196 T #59126 W #4012 220100

PRO-H-5011R-LH

Micanan 1/2HP 115V 1P Hoist Operator Contactor Model Left Hand

Continuous duty belt drive jackshaft operator with emergency chain hoist
Solenoid brake OPTIONAL

Installation manual Specification sheet

M10A

Safety Inertia Brake 1-1/2" Bore 8851 Torque

Provides a bearing to support the shaft and prevent the fall of a door if sudden acceleration occurs.
Ideal for commercial and industrial use; specifically with rolling shutters and rolling doors.
Normal Torque: 8851 lbf.in
Locking Torque: 31509 lbf.in

Reference manual Technical data Sell sheet

17JW

Rolling Steel 2" Flat Cast Windlock

Windlocks are especially used on rolling steel doors and shutters to prevent "blow-ins" from severe storms or winds.
A wind lock is a small metal device that is attached to each slat.
Its primary function is to reduce the amount of friction that occurs between the actual door & the guiding panel.
When the wind is strong the roller door may be dislodged bent or misaligned from the guide.
With a windlock your door can operate efficiently despite wind load or pressure.
Windlocks are easy to add on to any existing rolling steel or shutter door

.......more details

GH4416-05-R

Green Hinge #5 12-ga Right Hand *** to extent of inventory

A unique spring-loaded hinge that allows automatic adjustment of the door.
Provides a close tight seal of the door to the building
Green powder coat finish
For doors up to 20ft

PRO-H-5011E-LH

Micanan 1/2HP 115V 1P Hoist Operator NM ECB No Eyes Left Hand

Continuous duty belt drive jackshaft operator with emergency chain hoist
Full function Smart 10.0 Logic control board featuring on-board receiver with antenna
Solenoid brake OPTIONAL
Non-monitored board NO photoeyes
On-Board receiver holds up to 20 transmitters

Installation manual Specification sheet

SEF2410

Erone Ultra Flat Infrared Photocell 10M (33ft)

Fixed orientation 1 sender and 1 receiver
Range 10M (33ft) in all conditions
Adjustable Sensitivity
1 "NO" and "NC" contact
Power supply 12/24 Vac/dc
Will work with all commercial operators

.......more details

Wireless System Chart

H11G01

Hinge #1 x 11 gauge

11 gauge hinge #1 - 0.61 lbs
Bright zinc-plated
For use with 7/16" stem rollers
Item code # 224185

ME00057-COMPLET

Micanan Clutch Shaft Complete for PRO-APT (SCLUTCHSHAFT) MX00213

For model PRO-APT

1-0199

RW Hinge 700 03 x 7 18" (36" Open) Black

Straps: Formed steel 3/8" thick x 2-1/2" wide (basic width)
Pin: 3/4" dia steel Zinc plated. Pin loose with cotter pin
Bearings: 2 hardened steel disc bearings
Finish: Complete hinge black enamel
Fasteners are not included

Specification Catalogue

BOARD075M

Manaras Replacement Board Kit (Monitoring)

Includes BOARD70MR and BOARD66R
On-board 390MHz radio receiver accepts 50 remote controls

1005-1-3/8-16'

Aluminum Bottom Retainer U-Shaped 16' Long

For door thickness 1-3/8"

MP-00012

Micanan Reverse Limit Switches Mod.

For relay logic models

7549

Whiting Winding Cone for 2-5/8" ID Spring Wire Curbside (RH)

A Whiting original

019-034

Blue Giant Carriage Roller Housing w/Bearing

OUTER ROLLER IN YELLOW ZINC PLATED FINISH GREASED BEARING

110001-BULB-400FT

Janus T-Bulb Astragal Black 400ft Spool

Fits Janus mini storage doors M650
Bottom weather seal only no retainer

HOISTMOUNTMODDC

LiftMaster L5 GH to Maxum Mount Bracket Kit

HOISTMOUNTMODDC is a mounting bracket kit for Maxum Jackshaft and Hoist operators to aid in mounting operator in place of a previously installed LiftMaster® Logic 4.0/5.0 GH operator. This bracket mounts on top of existing GH bracket for easy Maxum JDC JHDC and RJDC installation.

BARL-1003-158-16

Elton Bottom Aluminum Retainer Fits 1-5/8" Doors Brush/Seal Channels 16ft Long

Aluminum bottom retainer that integrates a 45-degree brush seal channel combining two essential commercial door seals into one robust solution
Compatible with V1003 bottom rubber 3" to 6.5"
Integrated 45 degree angle retainer for our RL brush seals
Brush seal deters rodents
Available in 18 foot lengths easily customizable to desired length
Available for Garage Door Thickness: 1 5/8"

.......more details

IBGARM18

LiftMaster TECHNA Industrial Barrier Gate Arm 18 ft without LED

3” Aluminum arm designed exclusively for TECHNA industrial barrier gate operators
18’ Functional length arm
All parts ship in a single carton box for convenient transport and storage ensuring easy on-site assembly. The arm is field-customizable for added flexibility.
Made from durable aluminum extrusion with secure fasteners for a reliable fit. Arm joint uses bolts nuts and washers for stability and are reinforced by a torsion bar for added strength.
Operating temperature: -25°C to 60°C
Requires TECHNA INDUSTRIAL operator

.......more details

620-100991

Linear Heater Kit Assembly 460V Cage Style

Cage style heater is suited for large post mount operators (HSLG GSLG VS-GSLG SWG VS-SWG)

OSH-6433-M-N1-RH

Manaras Opera-SH 3/4HP 480V 3Ph Monitored w/ N1 Eyes Right Hand

An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a chain hoist for manual operation brake and a floor level engaging device
Clearence: side room required 16"

D0MKTRP017

DURULITE STD-IND V-CAM CAST ASSEMBLY KIT

-Cam Assembly Kit for Chase Doors Standard DURALITE model doors. fits 90 x 90 spec door.

ALUM-510

Aluminum 24" x 100' Spool Canyon Clay / Argile # 510

20% thicker than the aluminum sold in retail stores (0.022" )
Gentek # 510
Reverse side is #431 Bright White

TDC48-12

LiftMaster Trolley Chain Pack #48 700LBS 12ft Door

Chain pack only
TDC48-12 is a #48 Chain Pack Kit for 12 Ft. Trolley Rail Assemblies.
For use with LiftMaster® MAXUM TDC 700 Series Standard-Duty Trolley Commercial Door Operators; installed on 12' commercial doors.

D800-120-1

Cable Drum High Lift 800-120 1" HL Pair

Adjustable cable attachment with screw
Made of aluminum
High Lift capacity: 120" max
Flat capacity: 266" max
Rating: 2200 lb per door max
Keyway: 1 KW of 1/4" width

.......more details

CAPAC

LiftMaster Smart Access Hub

LiftMaster’s Smart Access Hub provides communities an affordable cloud-based option to monitor and control access points without needing to upgrade the entire system
Multiple-Entrance Control with myQ Community.
Flexible Connectivity Options - Ethernet Wi-Fi Cellular.
Universal Compatibility – Flexible connection options to control up to 4 access points (vehicle pedestrian amenity gates door strike or maglock).
Full Cloud-Based Management– For up to 50000 user and event history per unit.
Remote Programming and activity monitoring using myQ Community.

.......more details

Installation Manual (EN)Manual d'installation (FR)Product Guide Wiring Diagram (EN/FR)Data Sheet

H11G01-SS

Hinge #1 x 11 gauge Stainless Steel

Manufactured with 11ga. Rust-Resistant 304 Stainless Steel
Universal Design
Fits Most Overhead Sectional Doors
Priced Per Each

IP-MONB

CDVI Interior Touch Screen Monitor for IP-MDS/IP-SDS Video Intercom System in Black

Interior 7" touch screen TFT monitor for use with the IP-MDS/IP-SDS intercom systems in black.
IP system connects through the PoE system and also has a free to download app available on iOS and Android. The VDP app allows for users to connect with visitors at the door station and can control the door locks remotely.
Also available in white: IP-MON
SIP Server
Operating temperature: -10C to 55C
Call recording and built-in memory

.......more details

GALV-331-334-L

Cut-to-Length Torsion Spring .331 x 3-3/4" Left Hand Wound Galvanized Red/White

Priced per inch - cones sold seperately
For factory installed cones use part no. C-334-INSTALLED
Galvanized

LA400XL20W

LiftMaster Single Arm Solar Package for LA400 Gate Operator UL325 (Include (2x) SP10W12V Solar Panels (1x) XLSOLARCONTUL Control Box (1x) K94-37236 Solar Harness (1x) LMRRUL Photoeye (1x) K10-36183 Battery Tray (2x) A12330SGLPK Batt. (1x) LA400DC)

Kit Includes: LA400DC arm XL Solar control box (XLSOLARCONTU) which includes two 10WATT 12V Solar panels compatible with LA400 LA412 and LA500 Universal Solar harness (K94-37236) Monitored Retro Reflective Photos Eyes (LMRRU) Battery Tray (K10-36183) and two batteies (A12330SGLPK)
For dual gates order extra LA400DCS secondary arm
Updated unit complies with new UL325 code revised Jan 2016

99000568-PER-FT

Amarr Bottom U-Seal 3.5" Gray Vinyl 1/4" T Sold per Foot

1/4" T width
Used on Strat 3000 Herit 3000 and Commercial (exceot 1350 & 2700)

CPT215-PER-FOOT

Miller Edge Field Configurable Sensing Edge Cut-to-Length

For do-it-yourself edges on sectional or rolling doors.
Black extrusion flexible PVC conductive polymer Ends: Molded polymer
End plugs and mounting channel sold separately.
Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
When combined with the ME123 mounting channel ideal for 2" thick surfaces
Minimum Length: 3ft

.......more details

K41-0374-000

LiftMaster 24VDC Motor Gear Box Encoder (Jackshaft 700)

Maxum J-700

MOD050N2

Manaras Friction Clutch Mod. #50 Chain 1-1/4 RGH

Installed directly on the output shaft of the operator.
Provides added protection by causing the clutch to slip when the door systems requires adnormal torque to be operated.
Includes sprocket for #50 chain
Operator mounting side must be specified
A spreader bar cannot be used in conjunction with this modification
This modification applies to RGH ops

.......more details

TDC1222-10

Liftmaster Comm. 10FT Trolley Angle set (10-5810-P x 2) and #41 chain pack (TDC41-10) ___ ***Actual length 155"***

Double Angle Rails for doors up to 8'6" high
Includes #41 chain pack

TDC7-8

Liftmaster Comm. 8FT Trolley Angle set (10-5808-P x 2) and #48 chain pack (TDC48-08) ***Actual length 131*

Double Angle Rails for doors up to 8'6" high
Includes #48 chain pack

OGH-6534-M-N1-LH

Manaras 1 HP 600V 3Ph Gear Head Operator Monitored ECB w/N1 Eyes Left Hand

A heavy-duty worm gear industrial operator designed for use on industrial standard high and vertical lift sectional doors or rolling doors and grills.
Includes a self-engaging chain hoist for manual operation
25 cycles per hour 80 cycles a day
Hoist on right side standard can easily be moved to the left in field
Full overload protection
BRACKET112 must be used for wall mounting

.......more details

GALV-243-334-144-L

Torsion Spring .243 x 3-3/4" x 12ft LH Galvanized White/Yellow

Wire size: .243
Inside diameter: 3-3/4"
Length: 12 ft
Galvanized Stenciled

INFLAT-DOCK-SHLTR

Inflatable Dock Shelter *** Made to Order Sold by Quote Only

Custom order item. Sold by quote only

BEA-35-1555

BEA 50' of Cable Only for LZR Widescan

Optional 50 ft cable for use with the LZR-WIDESCAN

K20-3100M-5-H25

LiftMaster Electric Motor 1 HP 575V 3P L5

For use with various LiftMaster® Logic 5.0 Commercial Door Operators and Slide Gate Operators.
Also known as: 20-3100M-5 K20-3100M-5

OMH-6112-M-N1-RH

Manaras Opera-MH 1/2HP 120V 1Ph with Monitored Circuit Board N1 Eyes Right Hand

A medium-duty operator designed for use on standard high and vertical lift sectional doors and grills.
14 cycles per hour 50 cycles per day
Included PHOTO 070 Nema 1 eyes
Includes mechanical brake

K72-34845

LiftMaster Clutch Shaft Kit SL575GL

BEA-10-WBA

BEA Universal Mounting Bracket Arm and Plate

Extendable from 15.35" - 23.62"
-90 to 90 degree tilt range
Self Drilling screws provided
Carbon Steel Black Powder Coated
Mostly used for WIDESCAN and 10FALCON models

Installation Guide

GALV-234-2-144-L

Galvanized Torsion Spring .234 x 2" x 12ft LH Blue/White

Wire size: .234
Inside diameter: 2"
Length: 12 ft

27025

Doorlec Electric Motor TEFC 1 HP 115/230V DC101C

Motor Replacement Chart

CP-SH-34-16-1212

Lynx Complete Clutch Shaft Assembly for CDJH

3/4" -16 x 12.50"

CAP-390-468

Capacitor 390-468 MFD 3/4HP *** To Extent of Inventory

Same as CP-CAP-COM-450-540
Motor start capacitor

LAP

Linear External Antenna Kit LA-P AAE00366

Compatible with DVS-1200 DVS-2400 and DUAL-824 systems
Omni-directional external antenna
Antenna connector mounts inside case wire whip extends outside case
Compatible with EXA-1000 external antenna
Designed to enhance the radio range of Linear's DVS-1200 DVS-2400 and DUAL-824 systems.
The LA-P antenna Type F connector can also be used for coax connection with a remote mounted EXA-1000 antenna.

.......more details

OSH-6233-M-N1-RH

Manaras Opera-SH 3/4 HP 208V 3 Ph Monitored ECB w/N1 Photoeyes Right Hand

An ultra high-end heavy-duty V-belt drive industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a chain hoist for manual operation and a floor level engaging device
Clearence: side room required 16"
25 cycles per day > 100 cycles per day

.......more details

Installation Manual

7601351

FAAC Capacitor 8MF for 220V *** Price on Request

P-733T

Pulsar 3-btn 3-Door O/C/S Transmitter 318 MHz

Allstar compatible
Wall mount
OPEN-CLOSE-STOP 3 doors
8 dipswitches 318 MHz

Programming instructions

P-9931T

Pulsar 1-btn Transmitter 318 MHz

Allstar compatible
Single channel transmitter
8 dipswitches 318 MHz

Programming instructions

K41-0073-000

LiftMaster HD Main Control Board

Compatible with the following models: HDSL24UL HDSL24ULMC HDSW24UL HDSW24ULMC

14-1000

PVC Roll 6" x .060 x 400' Standard Clear Smooth for Replacement Strip Curtain

Suitable for most average applications.
Temperature Range: -20°F to 150°F (-28° C to 66° C).
Formulated with ingredients that meet USDA requirements for incidental food contact.
