Home Garage Door Hardware
BK308

Jamb bracket J-08 #8 12 gauge

  • Sold by the piece
  • Height 4.00" Length 1.9" Width 2.45"
  • Bright zinc plated 12 gauge steel
  • 2" long track mounting slot
  • manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.
DM54LC

Cable Drum High Lift 54" 400-54HL Pair

  • 54" LC High Lift-LD Aluminum die cast alloy.
  • 3/8"-16x2" hardened cup point set screws installed with red heads.
  • Color coded: Red-LH and Black=RH. Maximum High Lift: 54"
  • Maximum Door Height: 120" + High Lift
  • Rated lift per drum: 275 lbs 550 lb per door max
  • Maximum cable diameter: 5/32" max
    • .......more details
S-HOOK_SMALL

S Hook #8 Small 1/8" x 1-3/8"

D525-216-1

Cable Drum Standard Lift 18' 3-SS Torque Force Pair

  • 18' standard Lift aluminum die cast alloy with 3 set screws.
  • Pair includes: (1) LH and (1) RH.
  • Color coded: Red=LH and Black=RH
  • Max. Door Height: 18'-1" Rated Lift per Drum: 750 lbs.
  • Max. Cable Diameter: 3/16". Mounting: 1" solid shaft with 1/4" keyway
  • Cross Reference: DM518 DNS 5-18 OMI 2200
    • .......more details
RS36203

Roller 3" Steel Roller Head Only Heavy-Duty 6203 Bearing 5/8"

  • Steel Roller Wheel diameter: 3"-C 6203 bearing
  • Roller Head Only
BK309

Jamb bracket J-09 #9 12 gauge

  • Sold by the piece
  • Height 4.25" Length 1.9" Width 2.45"
  • Bright zinc plated 12 gauge steel
  • 2" long track mounting slot
  • manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.
HD3076

Lift Handle Roll Grip Round Zinc Plated 5-1/2"-5-3/4"

  • Measures 7" from end to end
  • Measures 5.5" from eyelet to eyelet
9150000622

5/32" Sleeve ONLY 100/pkg

  • Sleeves only 100 per pack
RN0039-SS

Roller 3" White Nylon 9" Stainless Steel Stem Double Sealed Bearing

  • A supreme double sealed bearing roller that never requires lubrication
  • Ideal for high usage and high moisture areas ie..carwash
  • 7/16" stainless steel shaft.
  • 200 lb load 100000 cycles of a 12' door
  • Stem Length - 8.312" Overall Length - 9.25"
EP2979

Exhaust Port 3" with latch long barrel

  • For use on insulated door panels up to 2" thick.
  • Inside diameter: 3" Includes fasteners & gaskets.
  • Polished aluminum finish.
BK000-B

Residential Top Roller Bracket Adjustable 2-Bolt Sold per Piece

  • Sold per piece - not sold as a pair
  • Meant for 2" hardware
Z9401

Coupler 1" Bore Non-Ajustable

  • Non-Adjustable Shaft Coupler Steel Zinc plated
  • 1" Bore
  • L= 4.7" 3 screws and nuts
  • Tightening torque on shaft: 20lb-ft max
CBC316-SMALL

Thimble 3/16" - 100 per pkg (Size Small)

BK111/PR

End Bearing Plate Flanged Heavy Duty 8-GA 3-3/8" without Bearing. Sold as a pair

  • They have 4 slots surrounding the hole to accommodate a regular bearing (with flange).
  • A pillow block bearing could be used if needed
  • Includes (1) RH and (1) LH plate
UCF-1

Self-Aligning Cast Flange Bearing 1" Bore UCF205-16

  • Grey cast iron painted.
  • Comes with 2x set-screws 1/4-28
  • Square 4 bolt
BK000

Residential Top Bracket Adjustable 1-Bolt Sold per Piece

  • Same as part number 3-31-1
  • Sold per piece - not a pair
R5202

Pulley 3" Zinc Plated Steel with Sheave Strap

  • Bored for 3/8" diameter bolt
  • Maximum cable diameter: 3/16"
  • Hardened inner race.
7-6095

RW Hanger 323 For use with #31 track

  • Wheels: 2-1/8" diameter Formed Steel
  • Apron: Formed steel vertically adjustable 5-3/4" long x 3-1/2" wide
  • Pendant: 1/2" diameter Steel
  • Door thickness: 1-3/4" inches to 2-1/2" inches
  • Included: 1 carriage bolt 2 flat head stove bolts
  • Capacity: 1 pair for a maximum of 400 lbs
    • .......more details
Z9200

Cable Snubbers Sold as a Pair

  • Prevents slack from forming in cables
  • Sold in pairs
Installation Instructions
TRACK-2"-RAW-10

Raw Vertical Track 2" 10'-0" Sold per Piece

  • 120" long 10'-0"
