Home Radio Controls Receivers
GRD-2

Linear 2-Channel Delta3 Gate Receiver 310 MHz (DNR00102)

  • Auto voltage sensing - no jumpers to set
  • Two Form ”A” (normally open) relays rated at 30 Volts AC/DC up to 5 Amps
  • Supplied with whip antenna three feet of coaxial cable and bulkhead connector
  • Power: 12 - 30 VAC or 10.5 - 30 VDC
  • Codes: 128 (set by dip switches)
  • RF frequency: 310 MHz
    • .......more details
Programming Instructions
STAR1000

LiftMaster Commercial Access Control Receiver Security+ 2.0

  • Security+ 2.0™ technology provides 2X the range of standard remote controls
  • Compatible with HomeLink Wireless Control System
  • 1000 remote capacity to support large quantity remote control requirements
  • Single and block addition
  • Supports suspending and unsuspending of remote controls to withhold and reinstate access
  • Designed for outdoor environments
    • .......more details
Programming InstructionsInstructions de programmationSell SheetBrochure
P294-K

Heddolf 4-Wire Single Channel Receiver with F-Connector 318 MHz

  • Controls one gate or garage door.
  • 318MHz
  • 12 or 24VAC or VDC
  • 9 three position dipswitches (+/0/-) •Switchable relay for pulse to continuous
  • 5 wires: 2 for power 3 for relay contacts
  • Coax antenna not included. Please see MK-00719 86LM.
    • .......more details
AP5

Linear MegaCode Wireless Access Controller 318 MHz

  • Ideal for gated communities parking facilities and industrial sites
  • Easy to set-up and use up to 480 remotes can be programmed with a few keystrokes
  • Easy to add suspend and delete transmitters through programming mode no transmitter dipswitches to set
  • Supports 480 block coded transmitters or 238 individual transmitters/wireless keypad entry codes
  • Supports up to six fully supervised safety edge transmitters
  • AP-5 replaces Linear's AP-4; AP-5 available for replacement of existing AP-4 units only
    • .......more details
Programming Instructions
365LMC

LiftMaster Universal Plug-in Receiver 315 MHz

  • Compatible with any garage door opener with a simple 2-wire dry contact
  • Includes 2-conductor bell wire
  • Able to accept 8 Security+ transmitters & 1 digital keypad
  • Compatible remotes; 893MAX 890MAX 892LT 373LM 371LM 374UT 375UT
Programming InstructionsInstructions de programmation
850LM

LiftMaster Universal Receiver Sec+ 2.0

  • Designed for both gated communities and commercial buildings.
  • Innovative and exclusive narrow band multi-frequency radio which virtually eliminates radio interference and eliminates customer call backs due to poor range performance.
  • Three channels provide expanded remote control capacity: Channel 1 - 50 remotes and 2 keypads Channel 2 - 20 remotes and 2 keypads Channel 3 - 20 remotes and 2 keypads
  • Multiple remote control options available to provide secure access from the safety and convenience of a vehicle
  • Power: 12-24VDC or 12-24VAC
  • Compatible remotes; 811LM 813LM 891LM 893LM 890MAX 893MAX 892LT 894LT
    • .......more details
Programming InstructionsInstructions de programmationSell Sheet
P-831RE

Pulsar 1-Door O/C/S Receiver 318 MHZ P-110554

  • Allstar compatible
  • Economy housing receiver
  • OPEN-CLOSE-STOP
  • 24V AC/DC
  • 8 dipswitches 318 MHz
Wiring-diagram
85LMC

LiftMaster Plug-In Power Supply

  • Plug-in jack for easy installation on Liftmaster receivers
  • Power input level: 105-135AC 24AC output
DR

Linear 1-Ch DR3A Delta3 Receiver 310 MHz

  • 310 MHz frequency 8 dip switches for coding 256 possible codes
  • 24V AC/DC input power 3 terminal connection
  • Activates one device
  • Dimensions: 5.5" W x 4" H x 1.25" D
  • Same as: DNR00001
Installation Manual
309013

Linear 1-Channel Multi-Code Receiver 310 MHz

  • Three tabs for universal mounting
  • One N/O relay
  • Compatible with 310 MHz Stanley and Multi-Code transmitters only.
  • Operates on 24 VAC power
  • One channel
  • Codes: 1024 (set by dip switches)
    • .......more details
Programming Instructions
312HMC

LiftMaster Universal Coaxial Receiver Sec+ 315 MHz

  • External 8" coaxial antenna included
  • Security+ rolling code technology and/or Dip switch compatibility
  • 12 VDC or 18-35 VAC/DC jumper selectable
  • Momentary or constant contact selectable
  • For replacement antenna use 41C3196
  • Accepts up to 31 remote control codes on Normal Security setting
    • .......more details
Programming InstructionsInstructions de programmation
WR2

Erone Radium Stand-Alone Wireless Receiver 2-Relay 433MHz

  • Up to 85 transmitter keys
  • 1 NO relay + 1 NO/NC relay (24VA)
  • Self-learning memorization
  • Standard pulse output
  • Power requirements: 12/24Vac/dc
  • These 433 MHz radio frequency systems offer longer range (up to 250m (820ft) less interference jamming and excellent reliability
    • .......more details
Instruction manual
MK-00648

Micanan 1-Channel 24V Receiver with Antenna

  • Comes with antenna MK00719
  • Total of 20 regular remotes can be programmed or 200 of the block coded remotes MK-00660
Programming Instructions
36163R

Genie Dual Frequency Intellicode Receiver 315 MHz & 390 MHz

  • For Genie Intellicode Rolling Code remotes Or Overhead Door Code Dodger remotes using the 315 or 390MHz frequency.
  • 24-Volt 3-Wire Connection For Garage Door Opener And Gate Openers.
  • Accepts Up To 8 Genie Intellicode Or Overhead Door Code Dodger remotes on 315 or 390MHz Frequency. Note: Will not work with the older code switch type of remotes.
860LM

LiftMaster Universal Weather Resistant Receiver

  • Weather-resistant for outdoor mounting requirements
  • Provides convenient access to gated communities industrial facilities and commercial sites all with a single transmitter solution
  • Three channels provide expanded remote control capacity: Channel 1 - 50 remotes Channel 2 - 20 remotes Channel 3 - 20 remotes
  • Multiple remote control options available to provide secure access from the safety and convenience of a vehicle
  • Compact design fits most gate and commercial door operators
  • Compatible with 811LM 813LM and all MAX remote controls
    • .......more details
Programming InstructionsInstructions de programmationSell Sheet
WRW

Erone Wiegand Wireless Receiver 433MHz

  • 433 MHz radio frequency systems offer longer range (up to 250m (820ft) less interference jamming and excellent reliability.
  • KeeLoq® Rolling Code technology ensure ultra-secure transactions.
  • Output: Wiegand 26 bit
  • Power requirements: 12 or 24V (AC or DC)
  • Dimensions: 105 x 45 x 28mm (4.3 x 1.75 x 1.1in)
  • Compatible with Centaur and any 26 bit Wiegand-capable systems
    • .......more details
SEL2641R433-I

Erone 2-Relay Stand Alone Receiver 433MHz

  • Up to 85 transmitter keys
  • 1 NO relay + 1 NO/NC relay (24VA)
  • Self-learning memorization
  • Standard pulse output relay
  • Power requirements: 12/24Vac/dc
  • Dimensions: 105 x 45 x 28mm (4.3 x 1.75 x 1.1in)
    • .......more details
Instruction ManualSell SheetBrochureWireless System Chart
SEL2641R433-Z4

Erone 4-Relay Stand Alone Receiver 433MHz

  • Up to 85 transmitter keys
  • 2 NO relay + 2 NO/NC relay (24VA)
  • Self-learning memorization
  • Standard pulse output Relay number 4 can be setup to latched output
  • Can be used for O/S/C
  • Power requirements: 12/24Vac/dc
    • .......more details
Sell SheetBrochureWireless System Chart
109950

Linear 1-Channel Multi-Code Gate Receiver 12-24V

  • Operates on 12-24 volts AC or DC power
  • One channel
  • Whip antenna
  • 3-foot antenna coax and bulkhead connector
  • Codes: 1024 (set by dip switches)
  • RF frequency: 300 MHz or 310 MHz (jumper selectable)
    • .......more details
Programming Instructions
P-9931R-4F

Pulsar MVP 1-Channel 4-Wire Gate Receiver 318 MHz P-111645

  • One channel
  • 4-wire operator connection
  • Wire whip antenna with "F" connector
  • Compatible with Allstar Classic Allister and Pulsar dipswitch transmitters and MVP quik-code transmitters
  • Power: 24 VAC/VDC
  • Codes: 19683
    • .......more details
Programming instructions
