Home Your Search Misc Garage Door Dock & Gate
H11G04

Hinge #4 x 11 gauge

  • 11 gauge # 4 hinge - 0.72 lbs
  • Bright zinc-plated steel construction
  • For use with 7/16" stem rollers
H11G01

Hinge #1 x 11 gauge

  • 11 gauge hinge #1 - 0.61 lbs
  • Bright zinc-plated
  • For use with 7/16" stem rollers
  • Item code # 224185
H11G05

Hinge #5 x 11 gauge

  • 11 gauge # 5 hinge - 0.76 lbs
  • Bright zinc-plated steel construction
  • For use with 7/16" stem rollers
SF200

Spring Fitting 2" Pair

  • Unviversal thread for use in either LH or RH wound springs.
  • Pair includes: (1) winding and (1) stationary.
  • Maximum wire size diameter: .3065".
  • Set screw installed: 3/8"-16 x 1" (2).
  • Mounting: 1" tube or solid shaft
  • Winding bar hole 1/2"
    • .......more details
C16-32FHD

Bearing 1" x 2" Press Fit Heavy-Duty

  • Flanged ball solid steel bearing
  • Rating: 1 000 000 revolutions
  • Axial load: 150lb max
  • Radial load: 900lb max
Z9401

Coupler 1" Bore Non-Ajustable

  • Non-Adjustable Shaft Coupler Steel Zinc plated
  • 1" Bore
  • L= 4.7" 3 screws and nuts
  • Tightening torque on shaft: 20lb-ft max
3-42-2B

Bottom Bracket with Removable Roller Carrier Commercial 2" & 3" 2-Hole BB-6 Pair *Includes (1) Right and (1) Left Bracket (2) U-Brackets (2) Clevis Pins (2) Cotter Pins*

  • Sold as a pair (1-left and 1-right)
  • 13-guage
  • Dimensions: 4-9/16" W x 11" H
  • For 1-3/4" door
19-3025

Roller Chain #50 Nickel Plated 25ft Length

GBUP412EF-1

Gate Roller 4-1/2" x 2-3/8" Polymer Sold Individually

  • Polymer gate roller with bracket for 4-1/2" upright post
  • Works with gate pipes that are 2-3/8" thick or less
JRGX114

Chain Hoist Jack Shaft JRG V2 1-1/4" Shaft Torque Force (126690)

  • Jack Shaft Mounting plastic guide 4.5:1 reduction
  • Gear drive
  • Fits 3-3/8" minimum offset
  • Includes: 26' of galvanized hand chain - doors higher than 15' require additional hand chain
  • 1 chain keeper
  • 2 shaft collars
    • .......more details
Sell sheet
PS241F

Adjustable Regulated Power Supply with Optional BBU 6-24VDC 1AMP

  • 3 preset voltages: 6 12 and 24 VDC
  • Full adjustment from 2 to 24 VDC if required
  • Requires AC transformer for input power (minimum 14 VAC for 12 VDC output 26 VAC for 24 VDC output cannot be connected directly to 120 VAC)
  • Maximum 1 amp. Output at 70 deg. F and free air
  • Ripple: Minimum load: 0.007vrms Half load: 0.028vrms Maximum load: 0.057vrms
  • Regulation: 97.5%
    • .......more details
Wiring DiagramDiagramme de raccordementSpec SheetSpécifications
H14G01

Hinge #1 x 14 gauge

  • Bright zinc plated 14-gauge steel hinge
  • For use with 7/16" diameter stem rollers
  • Full body hinge 2-3/4" wide
  • #1 position
  • Use between sections 1 and 2 or in the center position
  • Same as part number 241
    • .......more details
CB18A500-KOR

Cable 1/8" 7x7 500' Galvanized Supreme

  • Galvanized cable 1/8" 7x7 500ft spool.
  • A higher quality cable than the Chinese cable.
  • Meets endurance test requirements of over 35000 work cycles
  • Lubricated for flexability and longer service life
Comparison charts
CB18A0500

Cable 1/8" 7x7 500' Galvanized

  • Galvanized cable 1/8" 7x7 500ft spool.
Comparison charts
E3K-2018

Omron Retro-Reflective Photocell w/Built-In 10K Resistor UL325-2018 *Same as model E3K-R10K4-NR-1

  • Fully complies with UL325-2018 standard for gate ops. that use the 10K resistor method and also the Normally Closed method
  • Easy to wire terminal strip
  • Plug-in replaceable outputs
  • Range: 40ft
  • Power: 24-240V AC/DC
  • The E3K-2018 has a second relay to accommodate traditional dry contact for non-monitored applications.
    • .......more details
Wiring DiagramsSell sheet
50-LW1000BLK

Loop Wire Black 1000ft 18AWG

O02R9210

AirLift Bottom Cap Check Ball

AHB-716

Adjustable Hinge Bracket for 7/16" Roller Shaft

  • Mounts on the #1 hinge to make the hinge adjustable from #2 through #13
  • Eliminates the need to stock odd size hinges
  • Works for 7/16" shaft diameter rollers
19-50ML

Master Link #50

  • For #50 chain
  • ANSI Standard Carbon Steel
19-41ML

Master Link #41

  • For #41 chain
  • ANSI Standard Carbon Steel
