Home Your Search Doorlec
VBELT_5L345

Doorlec VBelt 5L 34.5" *** Replaced by VBELT_5L350

  • Same as part number #19052
VBELT_4L355

Doorlec VBelt 4L 35.5" *** NLA

  • Same as part number 19045
VBELT_4L340

Manaras VBelt 4L 34" - repl. by A32

  • Used on MTH/MTBH APE APT models
  • Same as Doorlec 19030
TCBOS-311

Doorlec Single Arm Barrier Gate Op 1/3HP 120volts w/ heater and DC2000 board

  • Includes 500W heater
TCBOD-321

Doorlec Double Arm Barrier Gate 1/2HP 230-1

  • Max length of double arm barrier 18ft (5.5m)
TCBOD-311

Doorlec Double Arm Barrier Gate Operator 1/2HP 120volts w/ heater and DC2000 board

  • raffic Control Barrier Gate Operator with 24' wishbone arm
Installation manual
SGP-353-2-575/3

Doorlec Gate Master 2 HP 575V/3P with TEFC Motor

  • Post mount heavy-duty industrial slide gate operator
  • Max. gate weight: 2500 lbs
  • Gate travelling speed: 45 ft / minute
  • 175 watt heater included
SGP-353-1-575/3

Doorlec Gate Master 1 HP 575V/3P with Heater

  • Post mount heavy-duty industrial slide gate operator
  • Max. gate weight: 2500 lbs
  • Gate travelling speed: 45 ft / minute
  • 175 watt heater included
SGP-321-1-230/1

Doorlec Gate Master 1 HP 230V 1 Phase with Heater and Lights in Cabinet

  • Post mount heavy-duty industrial slide gate operator
  • Max. gate weight: 2500 lbs
  • Gate travelling speed: 45 ft / minute
  • 175 watt heater included
SGP-311-1-115/1

Doorlec Gate Master 1 HP 115V 1 Phase with Heater

  • Post mount heavy-duty industrial slide gate operator
  • Max. gate weight: 2500 lbs
  • Gate travelling speed: 45 ft / minute
  • 175 watt heater with thermostat included
  • Includes Omron reflective photocell
SGO-311-1/2HP

Doorlec Slide Gate Op. 1/2HP 120V w/500w Heater

  • Engineered to accommodate heavy duty hight frequency commercial and industrial sliding gates with cantilever overhead or roller V track application
  • It is enclosed in a heavy steel base with 500 Watt thermostatically controlled heater and lockable cover
  • Three button control O/C/S
  • Adjustable clutch
  • Solenoid brake
  • Universal mount. Left or Right side
    • .......more details
SAFEPACK-MOD

Doorlec Safepack 24V Control Circuit

  • A safepack module is used as an "Intrinsically Safe Barrier Relay" and in hazardous locations with non-voltage producing sensors allowing the user to use a N.O. non-monitored sensing edge.
RESET-12A-32V

Doorlec Reset 12A 32V Overload

RDOF-311-1/2

Doorlec RDOF Rolling Curtain Fire Door Op. Compact Design w/ECB 1/2 HP 115V 1PH

  • Comes with Mounting Plate for Front of Hood Mount
RDO-321-3/4

Doorlec RDO Rolling Curtain Op. w/ECB 3/4HP 230V 1PH

  • Additional charge for doors over 14' high
MPB-3

Doorlec Open Mushroom Stop Lockable Close Push Button Station

  • Green (Open) Red (Mushroom Stop) Black (Close) push-button station
MJ7104

Doorlec Utility Switch 21800

  • Utility switch with a 'NO' and a 'NC' contact
  • Adjustable arm with roller
LJH-383-1/2-RH

Doorlec 1/2 HP 208V 3PH Jackshaft Operator Right Hand

  • Heavy duty industrial type control station open close stop 24V. control circuit
  • Universal mounting right or left
  • Floor level disconnect device electrical and mechanical
  • Emergency chain hoist operation on LJH model only
  • Colour code wiring diagrams
  • Rotary type limit switches readily adjustable in both directions
    • .......more details
Technical information
LJH-353-3/4

Doorlec 3/4HP 575V 3PH Jackshaft Operator

Technical information
LJH-353-1/2

Doorlec 1/2 HP 575V 3PH Jackshaft Operator

  • Heavy duty industrial type control station open close stop 24V. control circuit
  • Universal mounting right or left
  • Floor level disconnect device electrical and mechanical
  • Emergency chain hoist operation on LJH model only
  • Colour code wiring diagrams
  • Rotary type limit switches readily adjustable in both directions
    • .......more details
LJH-311-3/4

Doorlec 3/4HP 115V 1PH Jackshaft Operator

Technical information
LJH-311-1/2-RH

Doorlec 1/2 HP 115V 1PH Jackshaft Operator Right Hand

  • CSA approved
  • Heavy duty industrial type control station open close stop 24V. control circuit
  • Universal mounting right or left
  • Floor level disconnect device electrical and mechanical
  • Emergency chain hoist operation on LJH model only
  • Colour code wiring diagrams
    • .......more details
Technical information
LIMIT025A

Manaras Single Snap-Action Limit Switch with 'S' Lever

  • For all Manaras commercial operators prior to 2000 - except light duty models
  • Can be used on Doorlec Lynx and others
  • Unimax (SPDT)
Limit Switch Chart
LIMIT025

Manaras Single Snap-Action Limit Switch with Flat Lever

  • Replacement for LIMIT001
  • For all Manaras commercial operators prior to 2000 - except light duty models
  • Can be used on Doorlec Lynx and others
  • Unimax (SPDT)
Limit Switch Chart
LIMIT024

Manaras Double Snap-Action Limit Switch with Flat Lever

  • Replacement for LIMIT003
  • 2x SPDT - Unimax
  • Same as Doorlec # 21702
Limit Switch Chart
LDJ-CAP-48MFD

Doorlec Run Capacitor for LDJ RCR50-370

  • 370VAC/B 50 uf 50/60 Hz
  • CSC run capacitor
GUSSET-MOUNT

Doorlec Gusset Mount Plate Up-Charge (L Bracket)

  • Mounting plate for GH op
GHX-383-3/4HP-LH

Doorlec Explosion Proof Gear Head 3/4 HP 208V 3PH ECB Left Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings and NEMA 7/9 O/C/S push-button station
GHX-383-1HP-LH

Doorlec Explosion Proof Gear Head 1 HP 208V 3PH ECB Left Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings and NEMA 7/9 O/C/S push-button station
GHX-353-3/4HP-LH

Doorlec Explosion Proof Gear Head 3/4 HP 575V 3PH ECB Left Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings
  • NEMA 7/9 O/C/S push-button station included
GHX-353-1HP-RH

Doorlec Explosion Proof Gear Head 1 HP 575V 3PH ECB Right Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings
  • NEMA 7/9 O/C/S push-button station included
GHX-353-1.5HP-R

Doorlec Explosion Proof Gear Head 1-1/2 HP 575V 3PH ECB Right Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings
  • NEMA 7/9 O/C/S push-button station included
GHX-321-3/4HP-RH

Doorlec Explosion Proof Gear Head 3/4 HP 230V 1PH ECB Right Hand

  • Nema 7/9 control box
  • Electrical connections from motor to control box consists of hazardous location certified fittings and NEMA 7/9 O/C/S push-button station
GHW-383-3-230V

Doorlec Industrial Gear Head Door Operator 3 HP 230V 3P with ECB and Nema4 modification

  • Extra heavy-duty industrial-type electric door operator for damp environments.
  • Worm gear reducer 40:1 ratio
  • #50 roller chain and sprockets from operator shaft to door shaft. (#60 chain optional)
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter (also called friction clutch)
  • Rotary type limit switches
    • .......more details
GHW-383-2

Doorlec Industrial Gear Head Door Operator 2 HP 208V 3P with ECB and Nema4 modification

  • Extra heavy-duty industrial-type electric door operator for damp environments.
  • Worm gear reducer 40:1 ratio
  • #50 roller chain and sprockets from operator shaft to door shaft. (#60 chain optional)
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter (also called friction clutch)
  • Rotary type limit switches
    • .......more details
GHW-383-1HP-RH

Doorlec Industrial Gear Head Door Operator 1 HP 208V 3P with ECB and Nema4 modification

  • Extra heavy-duty industrial-type electric door operator for damp environments.
  • Worm gear reducer 40:1 ratio
  • #50 roller chain and sprockets from operator shaft to door shaft. (#60 chain optional)
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter (also called friction clutch)
  • Rotary type limit switches
    • .......more details
GHW-353-3HP-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 3 HP 575V 3P Right Hand *** By Quote Only

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GHW-353-2-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 2 HP 575V 3P Right Hand

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GHW-353-1HP-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 1 HP 575V 3P with ECB

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GHW-353-1.5-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 1.5 HP 575V 3P with Nema4 modification

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GHW-311-1HP-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 1 HP 115V 1P with ECB

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GHW-311-1.5HP-RH

Doorlec Ind. Duty Jackshaft Carwash Op. 1-1/2 HP 115V 1P with ECB

  • With DC2000 logic board
  • Worm-Gear Jackshaft type Industrial operator NEMA 4/12
GH-383-3/4

Doorlec Industrial Jackshaft Door Operator 3/4 HP 208V 3P with ECB

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-383-2

Doorlec Industrial Jackshaft Door Operator 2 HP 208V 3P with ECB

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-383-1.5

Doorlec Industrial Gearhead Door Operator 1.5 HP 208V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-383-1

Doorlec Industrial Gearhead Door Operator 1 HP 208V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-353-3/4

Doorlec Industrial Gearhead Door Operator 3/4 HP 575V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-353-3

Doorlec Industrial Gearhead Door Operator 3HP 575V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-353-2

Doorlec Industrial Gearhead Door Operator 2 HP 575V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-353-1.5

Doorlec Industrial Gearhead Door Operator 1.5 HP 575V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-353-1

Doorlec Industrial Gearhead Door Operator 1 HP 575V 3-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-343-3/4

Doorlec Industrial Jackshaft Door Operator 3/4 HP 460V 3-Phase

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-343-2

Doorlec Industrial Jackshaft Door Operator 2 HP 460V 3-Phase

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-343-1.5

Doorlec Industrial Jackshaft Door Operator 1.5 HP 460V 3-Phase

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-343-1

Doorlec Industrial Jackshaft Door Operator 1 HP 460V 3-Phase

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-321-3/4

Doorlec Industrial Gearhead Door Operator 3/4 HP 230V 1-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-321-1.5

Doorlec Industrial Gearhead Door Operator 1.5 HP 230V 1-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-321-1-CONT

Doorlec Industrial Jackshaft Door Operator 1 HP 230V 1P Contactor Model (Hard Wired)

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-321-1

Doorlec Industrial Jackshaft Door Operator 1 HP 230V 1P with ECB

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-311-3/4

Doorlec Industrial Gearhead Door Operator 3/4 HP 115V 1-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-311-1.5

Doorlec Industrial Gearhead Door Operator 1.5 HP 115V 1-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-311-1-CONT

Doorlec Industrial Jackshaft Door Operator 1 HP 115V 1P Contactor Model (Hard Wired)

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-311-1

Doorlec Industrial Gearhead Door Operator 1 HP 115V 1-Phase

  • Extra Deavy-Duty Gearhead Industrial Operator or large Sectional or Rolling Steel Doors
  • DC-2000 Logic Board with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Worm gear reducer 40:1 ratio for high-torque and long life
  • Solenoid Disk Brake Prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Optional Friction Clutch available
    • .......more details
GH-3-RH

Doorlec Industrial Jackshaft Door Operator 3 HP 575V 3P TEFC Motor Right Hand

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
GH-3-LH

Doorlec Industrial Jackshaft Door Operator 3 HP 575V 3P TEFC Motor Left Hand

  • Custom-designed extra heavy-duty industrial-type electric door operator
  • Worm gear reducer 40:1 ratio
  • #60 roller chain and sprockets from operator shaft to door shaft.
  • Door speed: 7 inches per second (approx.)
  • Adjustable torque limiter
  • Rotary type limit switches
    • .......more details
ETH-A

Doorlec Trolley Type Apartment Op. 1/2 HP 120V Head Only

  • This operator can be wire to receive radio and photo electric control systems loop detectors etc..
  • Headroom Required: 2" minimum at doors highest arc of travel
ETH-311-1/2HP

Doorlec 1/2HP 115V Trolley Door Opener

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
ETBHW-311-3/4HP

Doorlec 3/4 HP 115V-1Ph Waterproof Trolley OP

  • Trolley Industrial type operator with DC2000 Logic controller
  • Watertight/Dust tight
ETBH-383-3/4HP

Doorlec 3/4HP 208V 3P Trolley Door Opener with solenoid brake

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
ETBH-353-1

Doorlec 1 HP 575V-3Ph Trolley OP

ETBH-311-3/4HP

Doorlec 3/4 HP 115V Trolley Door Opener with solenoid brake

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
ETBH-311-1/2HP

Doorlec 1/2HP 115V Trolley Door Opener with solenoid brake

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
ETB-321-1/2HP

Doorlec 1/2HP 230V 1PH Trolley Door Opener

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
ETB-311-1/2HP

Doorlec 1/2HP 115V Trolley Door Opener TEFC Motor

  • Trolley model heavy-duty door operator designed to provide smooth dependable operation of sectional overhead type doors.
  • DC2000 Logic Controller
  • Comes with standard O/C/S push button station
EHJX-383-3/4

Doorlec Industrial Jackshaft Op. Explosion Proof 3/4 HP 208V-3Ph

  • Explosion proof NEMA 7/9 Heavy-Duty Industrial Operator
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse.
  • Solenoid Brake prevents coasting and secures the door when closed
  • Explosion-proof (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJX-353-1

Doorlec Industrial Jackshaft Op. Explosion Proof 1 HP 575V-3Ph ** Price on Request

  • Explosion proof NEMA 7/9 Heavy-Duty Industrial Operator
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse.
  • Solenoid Brake prevents coasting and secures the door when closed
  • Explosion-proof (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJX-311-3/4

Doorlec Industrial Jackshaft Op. Explosion Proof 3/4 HP 115V-1Ph

  • Equipped with: 3-btn control Adjustable Automatic Friction Clutch Emergency Chain Hoist and Heavy-Duty Solenoid Brake.
  • Explosion proof EEMAC 7/9
EHJX-311-1/2

Doorlec Industrial Jackshaft Op. Explosion Proof 1/2 HP 120V-1Ph

  • Explosion proof NEMA 7/9 Heavy-Duty Industrial Operator
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse.
  • Solenoid Brake prevents coasting and secures the door when closed
  • Explosion-proof (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJW-383-3/4

Doorlec Ind Jackshaft Op. Watertight ECB 3/4 HP 208V-3Ph

  • Equipped with: 3-btn control Adjustable Automatic Friction Clutch Emergency Chain Hoist and Heavy-Duty Solenoid Brake.
  • With DC-2000 controller
  • Watertight and Dust Tight EEMAC Type 4/12
EHJW-353-3/4

Doorlec Industrial Jackshaft Op. Watertight ECB 3/4 HP 575V-3Ph

  • Equipped with: 3-btn control Adjustable Automatic Friction Clutch Emergency Chain Hoist and Heavy-Duty Solenoid Brake.
  • With DC-2000 controller
  • Watertight and Dust Tight EEMAC Type 4/12
EHJW-321-3/4

Doorlec Ind Jackshaft Op. Watertight ECB 3/4 HP 230V-1Ph

  • Heavy-Duty Industrial Operator with Waterproof Mod. for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer-To-Close Delay On Reverse and Traffic Light Control (monitored board optional)
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJW-311-3/4

Doorlec Ind Jackshaft Op. Watertight ECB 3/4 HP 120V-1Ph

  • Heavy-Duty Industrial Operator with Waterproof Mod. for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer-To-Close Delay On Reverse and Traffic Light Control (monitored board optional)
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJW-311-1/2

Doorlec Ind Jackshaft Op. Watertight ECB 1/2 HP 115V-1Ph

  • Heavy-Duty Industrial Operator with Waterproof Mod. for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer-To-Close Delay On Reverse and Traffic Light Control (monitored board optional)
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-383-3/4

Doorlec Industrial Jackshaft Op. 3/4 HP 208V-3Ph

  • Equipped with: 3-btn control Adjustable Automatic Friction Clutch Emergency Chain Hoist and Heavy-Duty Solenoid Brake.
EHJ-383-1/2

Doorlec Industrial Jackshaft Op. 1/2 HP 208V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-383-1

Doorlec Industrial Jackshaft Op. 1 HP 208V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-353-3/4

Doorlec Industrial Jackshaft Op. ECB 3/4 HP 575V-3Ph

  • Equipped with: 3-btn control Adjustable Automatic Friction Clutch Emergency Chain Hoist and Heavy-Duty Solenoid Brake.
  • With DC-2000 controller
EHJ-353-1/2

Doorlec Industrial Jackshaft Op. 1/2 HP 575V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-353-1

Doorlec Industrial Jackshaft Op. 1 HP 575V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-343-3/4

Doorlec Industrial Jackshaft Op. 3/4 HP 460V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-343-1/2

Doorlec Industrial Jackshaft Op. 1/2 HP 460V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-343-1

Doorlec Industrial Jackshaft Op. 1 HP 460V-3Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-321-3/4

Doorlec Industrial Jackshaft Op. 3/4 HP 230V-1Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-321-1/2

Doorlec Industrial Jackshaft Op. 1/2 HP 230V-1Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-311-3/4

Doorlec Industrial Jackshaft Op. 3/4 HP 115V-1Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
EHJ-311-1/2

Doorlec Industrial Jackshaft Op. 1/2 HP 115V-1Ph

  • Heavy-Duty Industrial Operator for Sectional or Rolling Steel Doors
  • DC-2000 logic with adjustable Timer To Close Delay On Reverse and Traffic Light Control
  • Solenoid Brake prevents coasting and secures the door when closed
  • TEFC (sealed) continuous-duty electric motor with overload protection
  • Automatic Friction Clutch protects the door and operator
  • Self-aligning Heavy Duty sealed Pillow Block bearings on all shafts for high cycle applications
    • .......more details
E402-00-FM

Doorlec Ersce Utility Switch 6A/230V Roller Arm ** Indef. Delivery

  • Utility switch with a 'NO' and a 'NC' contact
  • Adjustable arm with roller
  • Made in Italy
51115

Doorlec Fire Release System

  • For fire rated rolling service doors connecting to existing dropout fusible link device
  • For GH and Belt Drive operators
50740

Doorlec On/Off Switch 575V 3Ph Gate Op

  • 20amp
50695

Doorlec Clutch & Pulley Assembly for EHJX

  • Includes shaft and bearings
50690-2

Doorlec Clutch Assembly for ETBH w/Double V-Belt

50690

Doorlec Clutch Assembly for ETBH

50685

Doorlec Clutch Assembly for EHJ Incl. Pillow / Speed Bearings with Metal Housing

50680

Doorlec Clutch Assembly for LJH

50450

Doorlec Mushroom Push-Button Red for 3-Doors

  • Capable of opening three doors
  • NEMA 4 Enclosure
50445

Doorlec Mushroom Push-Button Red with 2 Contacts

  • Capable of opening two doors or gates simultaneously
  • NEMA 4 Enclosure
50442

Doorlec Mushroom Push-Button Red for 1-Door

  • Capable of opening one door
  • NEMA 4 Enclosure
50430-KEY

Doorlec PBS 2-Btn O/C and Key Switch On/Off Nema 4/12

  • Open / Close with On / Off Key Switch Nema 4/12
  • Green - Open Black - Close
50430

Doorlec Push-Button Station 2 Button Nema 4/12

  • Open / Close Nema 4/12
50346

Doorlec Electric Switch and housing for Mechanical Edge

50324

Doorlec Drive Shaft Kit ETB-3

50307

Doorlec Cam Shaft Sub-Assembly EHJ ETH ETBH LJH

  • For models; EHJ ETBH and ETH
  • Assembly includes: Cam shaft (26140) Oilite (11801) x 2 Sprocket 41B12-5/8" (31118) Flange Bearing (28002) x 2 and nuts.
50304

Doorlec Hoist Shaft Kit w/Disconnect Coupler

  • For models LJH LJHW
50220

Doorlec Lifting J-Arm Assembly Trolley

50200

Doorlec Front Idler for ETB-3 with 410B9 -5/8" Sprocket

50195

Doorlec Front Idler Assembly with Shaft Trolley Models

  • Fits all Doorlec commercial trolley operators
  • Same as # 50190
50183

Doorlec Brake Assembly 575V

  • Brake assembly consists of solenoid drum shoes plate spring cover and fasteners
  • For all V-belt driven models that have brakes
50180

Doorlec Brake Assembly 120V

50175

Doorlec Adjustable Torque Limiter GT/GH Models 3HP Operators

  • Also known as Friction Clutch
50170

Doorlec Adjustable Torque Limiter GT/GH Models 3/4HP up to 2HP Ops

  • Also known as Friction Clutch
50150

Doorlec Electro-Mechanical Safety Edge and Weatherstrip Sold per Foot

  • For the protection of vehicles doors and safety of people.
  • Any upward-acting door may be fitted at the leading edge with an electro-mechanical safety weatherstrip.
  • This mechanism consists of a formed galvanized steel section covered with vinyl impregnated rubber hinged along the full width of the leading door edge.
  • Can be adjusted to approximately 2½" (63.5mm) to form a tight weather seal.
  • The hinge linkage is arranged that minimum pressure is required to activate the electrical control switch causing door to reverse direction of travel to the fully open position.
  • Reverse switch is enclosed in a galvanized housing with a sliding plunger to assure positive actuation every time.
    • .......more details
50074

Doorlec Flashing Light Option for TCBOD 120 volts can be field installed

  • Light package with flashing relay
50060

Doorlec Explosion-Proof Pneumatic Edge Kit

  • Kit includes explosion-proof air switch air hose plugs coil cord & fittings
  • Door size needs to be specified when ordering
50030

Doorlec Key Switch with Spring Return in Waterproof Housing

  • Weatherproof start key switch
  • Nema 4 enclosure.
  • Cast aluminum base with tamperproof aluminum cover
  • Rating: 10 amps 124VAC
  • Contacts: Single pole silver alloy momentary contact
  • Two keys supplied with each switch
    • .......more details
50027

Doorlec Maximum Run Timer with Base

50018

Doorlec Photo Switch Polarized Explosion Proof Reflective w/Round Reflector

  • Class 1 Div 1 Groupes CDEFG explosion proof Certified CSA
42208

Doorlec Z Bracket Control Cabinet Support - Front

  • Works with various models such as ETBHW ETHW
41014

Doorlec Emergency Release Spring

  • Attaches to the wall disconnect leverto put the operator in manual mode in case of power failure
37502

Doorlec DC-2000 Electronic Circuit Board for Constant Pressure Close

  • Works in all Doorlec model openers except R-99
  • Input power to board is 120V
  • 24V DC available on terminals 9 & 11
  • Accessory power on terminals 1 & 11
  • Programmed to work with constant pressure to close
37500

Doorlec DC-2000 Electronic Circuit Board

  • Works in all Doorlec model openers except R-99
  • Input power to board is 120V
  • 24V DC available on terminals 9 & 11
  • Accessory power on terminals 1 & 11
  • 1 = Stop. 2 = Com. 3 = Open 4 = Close
37408-PREWIRED

Doorlec Reversing Contactor BF9 120VAC Prewired for Single Phase

37408

Doorlec Reversing Contactor BF9 120VAC

37407

Doorlec Reversing Contactor BF9 24VAC

37380

Doorlec Auxiliary Contacts BF9 Contactor

37314

Doorlec Relay Mini 120V

  • For overrun pre-wired 25 Amp
37313

Doorlec Relay Flat Pins 2 Pole 24V

36350

Doorlec Reversing Time Delay 1.5 sec. 24VAC

  • In closing cycle door will stop for 1.5 seconds and reverse to fully open
36310

Doorlec Flicker Relay OFF/ON 120V AC

35800

Doorlec Rubber C.I Packing 1/16" x 10" Wide Sold per Foot

  • Low temperature rubber
  • Replaces existing worn or cracked MRSB rubber
  • 10" wide to suit most applications
  • Sold per foot
34202

Doorlec V-belt Pulley MA15 1-1/2" x 5/8" bore

34201

Doorlec V-belt Pulley MA20 2" x 5/8" bore

34115

Doorlec Awning Pulley 194 x 1"

  • Used on model LDJ & LDJ-3
34104

Doorlec V-belt Pulley 7" x 5/8" bore

34102

Doorlec V-belt Pulley 9" x 1" bore 5L

  • Fits model ETBH
34101

Doorlec V-belt Pulley 9" x 5/8" bore

  • Fits model ETB-3
34054

Doorlec V-belt Pulley Double 2" x 5/8" bore

33102

Doorlec Overload 1.20 to 2.00 Amps

31375

Doorlec Coupling Sprocket 50B23

31373-114

Doorlec Sprocket 60B36 1-1/4" Bore

31369-114

Doorlec Sprocket 60B12 1-1/4" Bore

31369

Doorlec Sprocket 60B12 1" Bore

31355

Doorlec Sprocket 80B14

31343

Doorlec Sprocket 41B23 - 5/8" bore 2-Hole

31337

Doorlec Idler Sprocket with Oilite bushing 50B12 for a 1" Shaft

31128

Doorlec Sprocket 41B12 Plain Bore 1"

  • Plain bore (no keyway)
31118

Doorlec Sprocket 41B12-5/8" Plain Bore

  • Plain bore no keyway
31117

Doorlec Sprocket 41B12-1" Bore. KW/SS

31114

Doorlec Sprocket 410B09 5/8" Bore 3/16" Keyway

  • 9 tooth sprocket
31111-114

Doorlec Sprocket 50B70 1-14" Bore KW/SS

31111

Doorlec Sprocket 50B70 2" Bore KW/SS 1/2T

31110

Doorlec Sprocket 50B23 1" Bore KW/SS

31107

Doorlec Sprocket 41B29 5/8" Bore

31105

Doorlec Sprocket 41B23 1" Bore

31104

Doorlec Sprocket 41B23-5/8"

31103

Doorlec Sprocket 41B36. KW/SS 1"

30005

Doorlec Brake Solenoid 208V with wire leads

30004

Doorlec Brake Solenoid 460V with wire leads

30003

Doorlec Brake Solenoid 115V with wire leads

  • Works with all 115 Volt Doorlec Commercial and Gate operators
30002

Doorlec Brake Solenoid 230V with wire leads

  • orks with all 230V Doorlec Commercial and Gate operators
30001

Doorlec Brake Solenoid 575V with wire leads

29203

Doorlec Transformer 230V pr 120V sec 35VA

  • 230V prImary 120V secondary 35VA
29202

Doorlec Transformer 550Vpr 120V sec. 35VA

29201

Doorlec Transformer 460V pr 120V sec 35VA

  • 460V prImary 120V secondary 35VA
29200

Doorlec Transformer 208V pr 120V sec 35VA

  • 208V prImary 120V secondary 35VA
29150

Doorlec Transformer 600Vpr 120V sec. 50VA

29140

Doorlec Transformer 230V pr 120V sec 50VA

  • 230V primary 120V secondary 50VA
29138

Doorlec Transformer 208V pr 120V sec 50VA

  • 208V prImary 120V secondary 50VA
29135

Doorlec Transformer 550Vpr 28V sec. 50VA

29120

Doorlec Transformer 120V pr 28 V. sec. 50VA

  • 120V primary 28 V secondary 50VA
28002

Doorlec Flange Bearing F-360-13 5/8" Hole

  • Fits model LJ
27122

Doorlec Electric Motor 1/3HP 208/480/575V 3PH DC321

27121

Doorlec Electric Motor 1-1/2 HP 208/480/575V 3PH DC223C

27120

Doorlec Electric Motor 1/2HP 208/480/575V 3PH DC221

27119

Doorlec Electric Motor TEFC 3/4HP 208/480/575V DC423

  • Frame size is 56C
27035

Doorlec Elect Motor 1 HP 208V 1 Phase base mount TEFC

  • For V-belt and worm gear reducer driven models
27028

Doorlec Electric Motor 3/4HP 115/230V DC403C

  • Bolts to gearhead (c-flange) openers
Wiring diagram for 120VWiring diagram for 230V
27026

Doorlec Electric Motor TEFC 1.5 HP 115/230V 1P DC203C

  • General purpose - Frame 56C
  • 1725 RPM for worm-gear reducer models TEFC type
27025

Doorlec Electric Motor TEFC 1 HP 115/230V DC101C

27024

Doorlec Electric Motor TEFC 3/4HP 115/230V DC403

  • ase mount
Wiring diagram for 120VWiring diagram for 230V
27021

Doorlec Electric Motor TEFC 1/2HP 115/230V DC201

Wiring diagram for 120VWiring diagram for 230V
27020

Doorlec Electric Motor TEFC 1/3 HP 115/230V DC301

26665

Doorlec Drive Shaft 1" x 19" Stress-Proof SGP

26253

Doorlec Shaft 9-3/4" x 5/8" Keyed LJ / LJH

26141-NEW

Doorlec Cam Shaft 11-1/4" x 5/8" (28.575 x 1.59cm)

  • Fits the new larger box
26141

Doorlec Cam Shaft 9-1/4" x 5/8" (24 x 1.59cm)

  • Fits the older smaller boxes
26140

Doorlec Cam Shaft Threaded 5/8" x 10-3/4"-24

  • This limit shaft will work on all Side-Mount Doorlec Openers
  • Cam shaft 5/8" (1.59 cm) - 24 x 10 3/4" (9.5 cm) fine thread
26124

Doorlec Clutch Shaft 12-5/8" x 5/8" LJH

  • Previous shaft size was 11-3/4" but have now been replaced by 12-5/8" to accomodate larger box size
26117

Doorlec Limit Cam Retainer Plate

  • Fits Most Doorlec Commercial operators except Explosion-Proof Operators
  • Will not fit on waterproof operators with small electrical enclosure built before 1999
26116

Doorlec Cam Retainer Plate Waterproof

25130

Doorlec Seal Oil CR6372
