Z9961

maxum Operator Mounting Bracket

  • Compatible with MAXUM® Jackshaft operators
  • Eliminates the need for a spreader arm by mounting a fixed bearing on the operator adjustment plate preventing the torsion shaft and operator from moving closer together
  • Precise chain tension adjustments through the adjustment bolt
  • Maintains parallel alignment between the operator output shaft and the door’s torsion shaft during chain tensioning
  • Operator installation is made easier by allowing the bracket to be hung on the torsion shaft via the bearing supporting its weight during fastener installation thereby removing the need to hold the operator manually
  • Has physical tick marks on both sides of the bracket and at the center of the bearing plate to indicate the torsion shaft’s center position allowing bracket to be accurately mounted prior torsion shaft installation
    • .......more details
Installation Manual
XF600VAC7

LiftMaster 600V Transformer Kit 700

  • For use with various LiftMaster® MAXUM Series DC 700 lbs. Standard-Duty and Industrial-Duty Commercial Door Operators
XF600VAC12

LiftMaster 600V Transformer Kit 1200

  • For use with various LiftMaster® MAXUM Series DC 1200 lbs. Standard-Duty and Industrial-Duty Commercial Door Operators
  • will supply a maximum of 12.5 amps on 120volts
TDC7S1BMC

LiftMaster maxum Trolley DC Comm. Op (#48) 1/2HP Equivalent 120/240V 1PH Std Cycles 700LB

  • Smooth Start/Stop Operation - New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - Provides seamless operation by supplying standby power when the power is down (battery backup sold separately)
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories.
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideBuying guide
TDC48-12

LiftMaster Trolley Chain Pack #48 700LBS 12ft Door

  • Chain pack only
  • TDC48-12 is a #48 Chain Pack Kit for 12 Ft. Trolley Rail Assemblies.
  • For use with LiftMaster® MAXUM TDC 700 Series Standard-Duty Trolley Commercial Door Operators; installed on 12' commercial doors.
TDC48-08

LiftMaster Trolley Chain Pack #48 700LBS 8ft Door

  • Chain pack only
  • TDC48-08 is a #48 Chain Pack Kit for 8 Ft. Trolley Rail Assemblies.
  • For use with LiftMaster® MAXUM TDC 700 Series Standard-Duty Trolley Commercial Door Operators; installed on 8' commercial doors.
TDC41-12

LiftMaster Trolley Chain Pack #41 1200/2200LBS 12ft Door

  • Chain pack only
  • TDC41-12 is a #41 Chain Pack Kit for 12 Ft. Trolley Rail Assemblies.
  • For use with LiftMaster® MAXUM TDC 1200 and 2200 Series Standard-Duty and Industrial-Duty Trolley Commercial Door Operators; installed on 12' commercial doors
TDC41-10

LiftMaster Trolley Chain Pack #41 1200/2200LBS 10ft Door

  • Chain pack only
  • TDC41-10 is a #41 Chain Pack Kit for 10 Ft. Trolley Rail Assemblies.
  • For use with LiftMaster® MAXUM TDC 1200 and 2200 Series Standard-Duty and Industrial-Duty Trolley Commercial Door Operators; installed on 10' commercial doors
TDC22X1BMC

LiftMaster maxum Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 60 Cycles/Hr 2200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC12X1BMC

LiftMaster maxum Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 60 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
TDC12S1BMC

LiftMaster maxum Trolley DC Comm. Op 3/4HP Equivalent 120/240V 1PH 30 Cycles/Hr 1200LB

  • Smooth Start/Stop Operation - DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator.
  • Faster Speed - Average of 12” per second opening on sectional doors.
  • Battery Backup Option - (battery backup kit sold separately).
  • Floor-Level Wall Controller - 4-line LCD display gives you access to programming troubleshooting and diagnostics at floor level saving time and money.
  • Wi-Fi® and myQ® - Easily connect to myQ Facility via Wi-Fi for visibility into what is happening at your door and control it from your web browser; no need for additional hubs or accessories. Know what accessories activate the door (remote transmitter keypad etc.)
  • Drive Type 65:1 Gearbox with #50 Chain Output
    • .......more details
TDC_Installation-manualTDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guide
K75-17034

LiftMaster Heavy-Duty Straight Door Arm Assbly

  • For use with various LiftMaster® Logic 4.0/5.0 and DC MAXUM Industrial-Duty and Extended Duty Jackshaft Hoist Commercial Door Operators
K41-0410-000

LiftMaster 1200 Extended Duty Motor Gear Box Encoder Hoist

  • For Maxum Hoist 1200 Op
K41-0409-000

LiftMaster 1200 Extended Duty Motor Gear Box Encoder Trolley

  • For Maxum Trolley 1200 Op
K41-0391-000

LiftMaster EMI Board 1200 (120VAC/240VAC)

  • For Maxum op
K41-0388-000

LiftMaster Main Board w/BBU maxum 700/1200 JHDC TDC

K41-0387-000

LiftMaster maxum Encoder Drive Sprocket & Hardware

K41-0383-000

LiftMaster Toroidal Transformer 1200lb / 120VAC-240VAC

  • For Maxum ops
K41-0381-000

LiftMaster Toroidal Transformer 700lb / 120VAC-240VAC

  • For Maxum ops
K41-0380-000

LiftMaster Bridge Rectifier 700/1200

  • For Maxum ops
K41-0378-000

LiftMaster 24VDC Motor Gear Box Encoder (Trolley 1200)

  • Maxum T-1200
K41-0377-000

LiftMaster 24VDC Motor Gear Box Encoder (Trolley 700)

  • Maxum T-700
K41-0375-000

LiftMaster 24VDC Motor Gear Box Encoder (Jackshaft 1200)

  • Maxum J-1200
K41-0374-000

LiftMaster 24VDC Motor Gear Box Encoder (Jackshaft 700)

  • Maxum J-700
K41-0372-999

LiftMaster Drive Sprocket Chain Repair Kit

  • Repair Kit to correct quality issue with TDC1200 & 2200 Maxum trolley openers
  • MAXUM CDO SKUs affected TDC7S1BMC TDC7S4BMC TDC12S1BMC TDC12S4BMC TDC12X1BMC TDC12X4BMC
K41-0157-000

LiftMaster Cable Tension Monitor Right Side

  • For use with various LiftMaster® MAXUM Series DC 700 lbs. to 2200 lbs. Standard-Duty and Extended-Duty Jackshaft Jackshaft Hoist and Trolley Commercial Door Operators
  • This service kit is compatible with the following MAXUM models: JDC JHDC and TDC.
  • NOTE: Refer to K41-0156-000 for Left-Side Cable Tension Monitor
K41-0156-000

LiftMaster Cable Tension Monitor Left Side

  • For use with various LiftMaster® MAXUM Series DC 700 lbs. to 2200 lbs. Standard-Duty and Extended-Duty Jackshaft Jackshaft Hoist and Trolley Commercial Door Operators
  • This service kit is compatible with the following MAXUM models: JDC JHDC and TDC.
  • NOTE: Refer to K41-0157-000 for Right-Side Cable Tension Monitor
JHDC7S1BMC

LiftMaster maxum Jackshaft 1/2HP 120/240V 1PH DC Operator 30 Cycles/Hour 700LB ***USE JHDC7S1BE***

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC_Installation-manualJHDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendations
JHDC7S1BE

LiftMaster maxum Jackshaft 1/2HP 120/240V 1PH DC Operator 30 Cycles/Hour 700LB long output shaft

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC22X4BMC

LiftMaster maxum Jackshaft 1.5 HP Heavy Duty 480V 3PH 60 Cycles/Hour 2200LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC22X1BMC

LiftMaster maxum Jackshaft 1.5 HP Heavy Duty 120/240V 1PH 60 Cycles/Hour 2200LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC12X1BMC

LiftMaster maxum Jackshaft 3/4HP 120/240V 1PH DC Operator 60 Cycles/Hour 1200LB

  • DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC_Installation-manualJHDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendation
JHDC12S4BMC

LiftMaster maxum Jackshaft 3/4HP 480V 3PH DC Operator 30 Cycles/Hour 1200LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC12S1BMC

LiftMaster maxum Jackshaft 3/4HP 120/240V 1PH DC Operator 30 Cycles/Hour 1200LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC_Installation-manualJHDC_Manuel-installationData sheetFiche techniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendations
JHDC12S1BE

LiftMaster maxum Jackshaft 3/4HP 120/240V 1PH DC Operator 30 Cycles/Hour 1200LB 3" output shaft

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC-7S-460

LiftMaster maxum Jackshaft 1/2HP 460V 3PH DC Operator 30 Cycles/Hour 700LB

  • New DC high-efficiency motor and gearbox provides the power needed and smooth start and stop to reduce wear-and-tear on your door and operator
  • Average of 12” per second opening on sectional doors and 8-9” per second on rolling steel doors
  • Provides seamless operation by supplying standby power when the power is down (battery backup kit sold separately)
  • Listed to ANSI/CAN/UL325 Standard for USA/Canada
  • Drive Type 65:1 Gearbox with #50 Chain Output
  • Radio Receiver DC Logic 1.0 board with Security+ 2.0® rolling code technology remote controls and binary DIP switch remote controls
    • .......more details
JHDC_Installation-manualJHDC_Manuel-installationData sheetFiche TechniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendation
JDC7S1BMC

LiftMaster maxum Jackshaft DC Commercial Op. w/BBU 700LB

  • Max door height: 40 ft. Max. Sectional doors up to 700 lbs. Rolling steel or insulated doors up to 450 lbs.
  • myQ Compatibility: Setup available for either myQ or myQ Facility
  • Operating Temperature: Without Heater: -4°F (-20°C) – 140°F (60°C). With Heater: -40°F (-40°C) – 140°F (60°C)
  • Heater sold seperately
  • Voltage: 120V/240V (1PH/3PH); 480V (3PH); 208V & 600V (3PH) available with transformer accessory
  • Motor Power: 24VDC
    • .......more details
JDC7S1BMC_Installation-manualJDC7S1BMC_Manuel-installationData sheetFiche TechniqueQuick connect guideGuide de connexion rapideOrdering guideSprocket recommendation
HTR120NC

LiftMaster Heater Kit for Maxum

  • Allows for operation in extreme cold environments effective for ambient temperatures down to -31°F (-35°C)
  • 120volt input power. standard 120V outlet required
  • Can be added easily in the field
  • Not for damp/wet environments
DCWALLCTL

LiftMaster Floor Level Wall Controller with LCD Display

  • Compatible with LiftMaster MAXUM Commercial Door Operators.
  • 4-line LCD display gives you access to more information at all times
  • Bringing programming troubleshooting and Diagnostics down to the floor level will save you time and money
  • Menu based user interface allows you to scroll through edit and save options and settings easily.
  • Dimensions: 3.586” W x 8.166” H x 1.732” D
DC7AH

LiftMaster Battery for maxum Integrated BBU DC Units 7AH

  • For use in Liftmaster MAXUM DC Commercial BBU ops
  • 7 AMP
  • 20 cycles when fully charged
CHAINTENSDC

LiftMaster Chain Tensioner 1" maxum DC

  • For use with various LiftMaster® MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators; manufactured after 2023 only.
  • Spreader for Maxum operators and 1" door shaft
CHAINTENS125DC

LiftMaster Chain Tensioner 1-1/4" maxum DC

  • For use with various LiftMaster® MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators; manufactured after 2023 only.
  • Chain Spreader for Maxum for 1" door shaft
AUXREL

LiftMaster Auxiliary Relay Board MAXUM

  • For use with various LiftMaster® Logic 4.0/5.0 and MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators
Configuration
8L5-OCS

Devanco O/C/S for 8-Doors L5

  • Compatible with all Liftmaster Logic 5 Commercial and MAXUM operators
  • Works with the 850LM and 860LM receiver to control OCS on 8 doors
  • also will do Open/Close for 24 doors.
  • 5.5" length x 3.25" wide x 1.25" thick
  • Splash-proof
Programming InstructionsInstructions de programmationSell sheet
7AUXTROLLEY10

LiftMaster AUX Trolley Mod JDC/JHDC 7 10ft (Incl. TDC48-1 (1) Chain #48 (1) 1"x 12' bar (2) 10-5810-P Tracks

  • AUX TROLLEY MOD JDC/JHDC 7 TO 10'
  • 7AUXTROLLEY10 is an auxiliary trolley kit for LiftMaster® Maxum JDC and JHDC Commercial Door Standard Duty Operators up to 10 ft.
  • Provides trolley type operation on standard lift doors (sectional) where side mount operator is preferred over a trolley operator.
15-50B72QGH

Sprocket 72 Teeth 1-1/4" Bore 1/4" Keyway

  • For use with various LiftMaster® Logic 4.0/5.0 and MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators
15-50B32QGH

Sprocket 50B32 1.25 Bore 1/4" w/SS

  • 71-1550B32QGH is a 32 Tooth Sprocket Kit 1-1/4" Bore x 1/4" keyway (50B32-114)
  • For use with various LiftMaster® Logic 4.0/5.0 and MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators
15-50B32LGH

Sprocket 50B32 1" shaft 1/4" KW

  • 71-1550B32LGH is a 32 Tooth Sprocket Kit 1" Bore x 1/4" keyway (50B32).
  • For use with various LiftMaster® Logic 4.0/5.0 and MAXUM DC Standard-Duty and Industrial-Duty Commercial Door Operators
1222_DUAL_TROLLEY_14'

LiftMaster Dual Trolley kit for 14' high door includes #41 Chain for 14ft High Door Angle tracks (2x) 14' (Actual length 227") and (1x) shaft

  • Provides a second drawbar-type operation on wide standard door
  • Includes 14ft tracks #41 chain hardware & Round Bar 1" x 20'
  • Works with TDC12 & TDC22 Maxum operators
1222_DUAL_TROLLEY_12'

LiftMaster Dual Trolley kit for 12' high door includes #41 Chain for 12ft High Door Angle tracks (2x) 12' and (1x) shaft

  • Provides a second drawbar-type operation on wide standard door
  • Includes 12ft tracks #41 chain hardware & Round Bar 1" x 20'
  • Works with TDC12 & TDC22 Maxum operators
02-401M

LiftMaster 1-Button Control Station

  • For use with various LiftMaster® Logic 4.0/5.0 and MAXUM Series Commercial Door Operator Applications
  • Sends the door to the full open position. Perfect for time sensitive situations.
