748

Fasteners Self Drill & Tap Tek Screw 1/4-20 x 3/4" (#2PT) 1000/Box

Indented Hex Washer Head
7/16" Head
Max RPM = 2000
#2 point = shorter cutting edge (more thread)

SBPFL205-16

Pillow Block Flange Bearing Football Style 1" Bore SBPFL205-16

C-334-DUPLEX_INSTALLED

Spring Fitting Pair 3-3/4" for Duplexing (Short) installed

Universal thread for use in either LH or RH wound springs.
Pair includes: (1) winding & (1) stationary.
Maximum wire size diameter: .4062".
Set screw installed: 3/8"-16 x 1-1/2" (2).
Mounting: 1" tube or solid shaft - min. 1/2 turns on the set screws.
3-3/4" fittings can be combined with 6" spring fittings for duplex assembly.

.......more details

19-41ML-NP

Master Link #41 Nickel Plated

For #41 chain

BL-BAG-1A

Barlock Hardware Bag Only for Doors 12ft and Under

Does NOT include the locking bars
Up to and including 12ft
Kit includes lock spacers and fastereners

Assembly Manual

C-600-114-INSTL

Cones 6" 1-1/4" bore Factory Installed (Pair)

For do-it-yourself installation use part no. SF600-114

BK311

Jamb bracket J-11 #11 12 gauge

Sold by the piece
Height 4.75" Length 1.9" Width 2.45"
Bright zinc plated 12 gauge steel
2" long track mounting slot
manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.

BK309

Jamb bracket J-09 #9 12 gauge

Sold by the piece
Height 4.25" Length 1.9" Width 2.45"
Bright zinc plated 12 gauge steel
2" long track mounting slot
manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.

BK306

Jamb bracket J-06 #6 12 gauge

Sold by the piece
Height 3.50" Length 1.9" Width 2.45"
Bright zinc plated 12 gauge steel
2" long track mounting slot
manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.

BK305

Jamb bracket J-05 #5 12 gauge

Sold by the piece
Height 3.25" Length 1.9" Width 2.45"
Bright zinc plated 12 gauge steel
2" long track mounting slot
manufactured to accept ¼” fasteners when attaching to the track and 5/16” to lag to the wall.

BK312

Jamb bracket J-12 #12 12 gauge

Sold by the piece
Height 5.0" Length 1.9" Width 2.45"
Bright zinc plated 12 gauge steel
2" long track mounting slot accepts 5/16" track bolts

GDI-LG920

GDI Jackshaft & Trolley JDMG-LG-A830 Nema 4 UL325 Photo Eyes Extra

Low Headroom at 4-3/4" (Trolley)
Dimensions: 11.35" x 4.3" x 4.3"
Motor type: Brushless DC
Max cyles: Open/Cose per day = 3200
One operator can handle all AC voltages - Single phase and three phase
No maintenance GearMotor sealed stainless steel bearings no limit switches no belts or hydraulic cylinders to maintain

.......more details

OCS-PANEL

GDI Panel Buttons Open/Close/Stop N1/ N4 G3253

Power LED

41A4916

Gel Wire Connectors 19 to 26 AWG 100/ box

27-48-150

Extension Spring 8' Door - 150 lbs Red

Single - Loop
27" long 48" stretch 150 lb load
Sold individually
Rated for 10000 cycles

Spec Sheet

27-48-160

Extension Spring 8' Door - 160 lbs Brown

Single - Loop
27" long 48" stretch 160 lb load
Sold individually
Rated for 10000 cycles

Spec Sheet

HD3130

End Stile Latch 7-1/2" Lockbar Length

Lockbar Length: 7-1/2"
Throw: 2-1/8" Use with: Lockbar or End Stile
Centerline Distance (key spindle to handle shaft): 2-3/4".
Handle in Bright Chrome Finish Latch in Bright Zinc Plated steel.

915007048X

Extension Cable 1/8" 7x19 14' Sold as a Pair

Cable assembly for extension spring door - looped on one end the other is raw (no stops)

GALV-375-334-144-R

Torsion Spring .375 x 3-3/4" x 12ft RH Galvanized Yellow/Green

Wire size: .375
Inside diameter: 3-3/4"
Length: 12 ft
Galvanized

GALV-375-334-144-L

Torsion Spring .375 x 3-3/4" x 12ft LH Galvanized Yellow/Green

Wire size: .375
Inside diameter: 3-3/4"
Length: 12 ft
Galvanized
