MK-00002

Micanan Timer Module (2 wire)

MT22-BLACK-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

��Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

Installation Manual Worksheet Sell Sheet

751

Fasteners Self Drill & Tap Tek Screw 1/4-20 x 1" (#2PT) 1000/Box

7/16" Head
Indented hex washer head
Max RPM = 2000

CH505L5-RH

LiftMaster Hoist Op. with Carwash Mod. 1/2 HP 575 VAC 3 Ph Logic 5 Right Hand

Industrial Duty Hoist Operator with Damp Environment modification.
Comes with CPS-UN4 photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

CH751L5-LH

LiftMaster Hoist Op. with Carwash Mod. 3/4 HP 115/230 VAC Logic 5 Left Hand

Industrial Duty Hoist Operator with Damp Environment modification.
Comes with either CPS-UN4 or CPS-RPEN4 photoeyes

Installation Manual Manuel d'Installation Sell sheet Brochure

K72-12515-1

LiftMaster Limit Switch Kit

For models T H Logic 5 and various L3 L4 commercial operators
Also known as: K75-12515-1 K75-12514

K72-14130-1

LiftMaster Limit Shaft Kit

For models H J and HJ Logic 3 Logic 4 and Logic 5 commercial operators
Kit includes: Limit shaft Limit nuts Limit bearings Limit sprocket Interrupter cup Shim washers Compression ring Roll pin and E-rings.

029-98200

W-Style Replacement Door White Stainless Steel Package 029-98200

Replacement door size between 96-1/4" - 98" wide x 90-100" high
Painted white
Stainless steel package
Includes Hinges Rollers and Cable

178B35

LiftMaster Curved / Bent Arm Kit (41B0035B)

Will work with most residential garage door openers
Also known as: 4178B0035B 178B32 41B0035B 4178B35 178B35 012385990357 178B35B

178B34

LiftMaster Straight Door Arm

Will work with most residential garage door openers
Also known as: 012385041783 178B33 178B34 4178B0034B

26-14623

Truck Door Top Panel (13" x 98") for Todco DryFreight

These panels are cut to an extra wide width to fit wider vehicle applications
Interlocking tongue and groove design for weather-tight joint and proper alignment.
.75" thick 7 ply exterior grade medium density plywood
Primer finish

71B575G

LiftMaster Brake Kit 575V with Solenoid Field Install SL585 and SL595

Kit comes complete with: Brake hub kit brake release lever brake disk spring cup studs compression springs brake solenoid solenoid cover spacers mounting plate pressure plate feather key and conduit.

Instruction Manual

41D216

LiftMaster End Panel with all Labels and Light Socket

End panel that goes on model 8355
For the circuit board order 45ACT

41DB001-1

LiftMaster Circuit Board Assembly

For belt drive unit model 3500 (315MHz)
Assembly includes: Board end panel and light socket
Also known as 041DB001-1C

75-10170

LiftMaster Trolley-Slider Assembly (08-10169)

For LiftMaster trolley models MT T GT
Also known as: 307085008 75-10170 08-10169 085008 7510170

MOFT20-M14-8

Carlo Gavazzi Photoelectric Sensor Thru-Beam Transmitter

Maximum sensing distance is 20 meters
11-pin
Waterproof for harsh environment i.e. water dust steam etc.
To be used with amplifier series S142.
Supplied with 15 m of shielded cable.
For receiver unit order part no. MOFR-M14-8.

.......more details

Installation Manual

41AC075-2

LiftMaster Circuit Board Assembly for Dual Capacitor Models 315Mhz ** To extent of inventory

Assembly includes: End panel Logic board and Light socket
For chain drive units with two lights ie..3575 3585 3595 PD752D and PD758D
Also known as 41AB075-2 41AC075-2 041AC075-2A

915007048X

Extension Cable 1/8" 7x19 14' Sold as a Pair

Cable assembly for extension spring door - looped on one end the other is raw (no stops)

1104-8FT-GREY

Residential Side & Top PVC Weather-Strip with cap 8' Long - Grey (G)

Grey rigid vinyl retainer with grey flexible vinyl seal.
Dual fin vinyl.
Comes with cap to hide screws.

02-410B

LiftMaster Commercial Key Control Station Open-Close and Off with Stop Button and BEST Cylinder

Outdoor Surface Mount Nema 4/12 station
Standard key cylinder is replaced with BEST cylinder
Open/Close spring return to center (off)
Key removable in center position only
With Stop button

MV-00026

Micanan 24V Commercial Receiver CR32-24V

Programming Instructions

8FT-BELT-LDO

Linear 8ft Belt Drive Rail for LD050/LS050/LDCO (HBT8C)

8ft belt-drive T-rail for LDO33 LDO50 LSO50 LCO75 & LDCO800 door operators
Fully-assembled & pre-tensioned
Compatible with Model CHCR-7/8 & CHCR-8 carriage house I-rail conversion kits

8FT-CHAIN-LDO

Linear 8ft Chain Rail for LD050/LS050/LDCO (HCT8C)

8ft chain-drive T-rail for LDO33 LDO50 LSO50 LCO75 & LDCO800 door operators
Fully-assembled & pre-tensioned
Compatible with Model CHCR-7/8 & CHCR-8 carriage house I-rail conversion kits

423LMC

LiftMaster 3-Channel Co-Axial Receiver 390 MHz

8" coaxial antenna included
Used for open/stop/close on commercial motors
N/O and N/C selectable
Compatible remote: 33LM

Installation Manual Manuel d'Installation

MD-00007

Sprocket 41B12 1" Bore 1/4" Keyway 2 SS 5/16"

EL25G

LiftMaster Telephone Entry System Gray

Capable of accepting up to 2000 codes
4 assignable and programmable built-in relays
Mounting versatility and available in 3 colors: Gray Nickel or Silver

Installation Manual Sell Sheet

20-1100C-2P

LiftMaster Electric Motor 1HP 115/230V 1P

Replacement motor for SL595

990LM

LiftMaster Surge Protector ** NLA

Installation Manual Manuel d'Installation

CR-2000

EMX Keypad/Card Reader Waterproof 5401-1

Back-lit keys for nighttime operation
2000 users (card or passcode)
Rugged waterproof design and vandal resistant
9-24 VDC
Tamper alarm
Door call button

.......more details

Instruction Manual Spec Sheet

08-11013

LiftMaster Bevel Gear 3/4" ID

Fits the LiftMaster GH operator

SOLID_SHAFT_7FT

Solid Shaft 1" Keyed 7 ft Galvanized

Actual length is approx. 7'-1"

3AG3

Miniature Fast Acting Glass Fuse 3 Amp 250V (5/pkg) - 766124

6 x 30mm miniature fast acting glass fuse
Rated voltage: 250V
Rated current:3A
ROHS compliant

MK-00493

Reversing Contactor Telemecanique 24V Coil (MK-01179)

Same as MK-01179

15-50B40LGH

Sprocket 40 Teeth 1" Bore 1/4" Keyway

41A7756

LiftMaster End Panel with Light Socket for 8557

50-105

LiftMaster Black Coil Cord 4-Wire 18-ga 20 ft. Extended Curly Cord

50-104-2

LiftMaster Orange Coil Cord 3-Wire 18-ga 20 ft. Extended Curly Cord

TUBE_SHAFT_9FT

Hollow Shaft 1" x 9'-10" Galvanized 16 gauge

3-42-2A

Bottom Bracket with Removable Roller Carrier Commercial 3" 1-Hole BB-6 Pair *** To extent of inventory

Sold as a pair (1-left and 1-right)
11-guage
Dimensions: 4-1/2" W x 11" H x 1-3/8" D

C-200-INSTALLED

Cones 2" Factory Installed (Pair)

For do-it-yourself installation use part no. SF200

.262-2-R

Cut-to-Length Torsion Spring .262 x 2" Right Hand Wound Red/Yellow

Priced per inch - cones sold seperately
For factory installed cones use part no. C-200-INSTALLED

C-258-INSTALLED

Cones 2-5/8" Factory Installed (Pair)

For do-it-yourself installation use part no. SF258

.283-258-R

Cut-to-Length Torsion Spring .283 x 2-5/8" Right Hand Wound White

Priced per inch
For factory installed cones priced seperately - use part no. C-258-INSTALLED

HD-15

Reflector Hood for 3" Round Reflector

Black/Charcoal

ER100

Carlo Gavazzi Reflector 4" (100mm) Square

High quality reflector for retro-reflective photoelectric switches
Dimensions: 100 mm x 100 mm 9.2 mm thick

ME123-C

Miller Edge U-Shaped PVC Mounting Channel Sold by the Foot

2" Wide 1-1/4" High

CPS-UN4

LiftMaster Commercial Protector System Thru-Beam Eyes NEMA4

Waterproof photoeyes.
for direct connect to operators with Logic boards. L3 L4 L5
Receiving Eye - A: 50-50997 Sending Eye - A: 50-50998
These eyes will also work on the Micanan UL325 monitored operators

Installation Manual Manuel d'Installation Sell Sheet

20-2LMC

LiftMaster 2-Strand Bell Wire 500ft White/Red

2 strand 22 gauge tin-dipped copper hook-up wire
Color coded White & White/Red wires

7001-16-W/B

Commercial Side & Top Weather-Strip 16' Long - White and Black (WB)

White galvanized steel with black dual fin vinyl.
Commercial and Residential use.
Steel is notched on both ends for easier installation.
Full case quantity only (10)

7FT-RAIL-BELT

LiftMaster 7' Belt Drive rail 2777BD - colour code: Grey

Price reflects cost if purchased with an opener

ME112-R

Miller Edge Black 2W Non Monitored RH Outlet 1-5/16" wide x 1-1/2" high Sold by the Foot

Slide in edge designed for commercial sectional doors and gates.
Retrofits easily to 1" to 1-1/4" sectional doors
Touch sensitive signaling allows for immediate stopping/reversing of motion
For sectional doors: measure the daylight opening of the door or measure the panel width of the door
This gives you the "active length" of the edge - the length to order
Lead wire: 22 gauge univversal

.......more details

Installation Manual Worksheet Sell Sheet

ME113-R

Miller Edge Black Right Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

Slide in edge designed for commercial sectional doors
Retrofits easily to 1-1/4" to 1-1/2" sectional doors
Touch sensitive signaling allows for immedita stopping or reversing of motion
For a sectional door: measure the daylight opening of the door or measure the panel width of the door
This gives you the "active length" of the edge - the length to order.
Lead wire: 22 gauge universal

.......more details

Installation Manual Worksheet Sell Sheet

886LM

LiftMaster Motion-Detecting Control Panel Sec+ 2.0 *** To extent of inventory

Push button for garage door operation
Motion-detector automatically turns on the light when movement is detected
150 degree sensing angle for motion sensor
Program remote controls directly from the control panel
Light run-time is 4 1/2 minutes with adjustable light timer option
On/Off switch for deactivation of motion-detecting function

.......more details

Installation Manual

.393_5-1/4"-LH

Torsion Spring .393 x 5-1/4" x 12ft LH Orange

Wire size: .393
Inside diameter: 5-1/4"
Length: 12 ft

.363_3-3/4"-LH

Torsion Spring .363 x 3-3/4" x 12ft LH Green/White

Wire size: .363
Inside diameter: 3-3/4"
Length: 12 ft

.331_3-3/4"-LH

Torsion Spring .331 x 3-3/4" x 12ft LH Red/White

Wire size: .331
Inside diameter: 3-3/4"
Length: 12 ft

.243_2-5/8"-LH

Torsion Spring .243 x 2-5/8" x 12ft LH White/Yellow

Wire size: .243
Inside diameter: 2-5/8"
Length: 12 ft

.243_2"-LH

Torsion Spring .243 x 2" x 12ft LH White/Yellow

Wire size: .243
Inside diameter: 2"
Length: 12 ft

972LMC*

LiftMaster 2-btn Security+ Transmitter 390 MHz ***Discontinued

Both buttons feature Security+ rolling code technology
Compatible with models manufactured from 2005
Second button can learn other shared Liftmaster radio-controlled devices.
Includes visor clip and Lithium battery CR2032

813LM

LiftMaster 3-btn Dip-Style Transmitter Sec+ 2.0 ** To extent of inventory

Encrypted DIP style three-button remote control with Security+2.0 technology
Ideal for applications such as gated communities or commercial applications requiring a large number of remotes for a common entrance
Easy to code 12-position DIP switch offers up to 4096 codes
May also be programmed for Open/Close/Stop functionality
Narrow band transmission on 3 simultaneous frequencies (310 315 390 MHz)
Compatible only with Security+ 2.0™ commercial receivers and operators

.......more details

Programming Instructions Instructions de programmation Sell Sheet

380LMC

LiftMaster Remote Work Light

For use exclusively with the LiftMaster Wall Mount Garage Door Opener (model 8500)
Provides 200 watts of light with adjustable light time delay
Lights are controlled by opener activation or control panel light button
Add as many lights as you wish – perfect for brightening up a dark garage or workspace

Installation Manual Manuel d'Installation Troubleshooting

24-24-1

LiftMaster Relay 24VAC 8-Pin DPDT Flange

K001A6424-2

LiftMaster Circuit Board Assembly Kit 2008 315 MHz *** No longer available

Replacement circuit board for Medium-Duty Logic Commercial Operators
Used on models MJ MH MHS MT BMT and MGJ (non- UL325 compliant operators)
315 MHz intergral radio receiver accepts 20 Sec+ remotes or unlimited dip switch

Installation Manual

41A4885-5

LiftMaster MVIS Pulley/ Worm Gear Assembly

Gear and sprocket assembly for belt drive units after 2002.
Assembly includes: Spring washer thrust washer retaining ring bearing plate two roll pins drive gear and worm gear helical gear with retainer and grease.

Installation Manual Manuel d'Installation

24-24-2

LiftMaster Relay 24VAC 8-Pin DPDT

K75-18493

LiftMaster Chain Guide Kit

Compatible with SL575 SL585 SL595 SL595U SL595UL and IHSL
Kit includes chain guide retainers and bracket for guide holders

41A5483C

LiftMaster Circuit Board Assembly *** To extent of Inventory

Assembly includes: Circuit board end panel and light socket
For chain drive units with two lights
Fits 2265 2565 7420 PD610 PV612C & PD612K
Last letter of the part # indicates revision date
Also known as 41A5483 41A5483B

24-24-6

Small Relay 24VAC 11-Pin 3 PDT

41A4916

Gel Wire Connectors 19 to 26 AWG 100/ box

T-639

FL-Allstar 3-btn 9-Door O/C/S Transmitter 107476-311 MHz

This remote can control (open-close-stop) up to nine doors.
It has a eight switches encoder with three positions: + 0 and - .
Manufacturer's model number: 639T (190-107476)
Dimensions: 6 1/4" x 3 3/8" x 1 3/8".

Programming Instructions

T-733

FL-Allstar 3-btn 3-Door O/C/S Transmitter 107477-311 MHz

This transmitter can control (open-close-stop) up to three doors.
It has a eight switches encoder with three positions: + 0 and - .
Manufacturer's model number: 733T (190-107477)
Dimensions: 6 1/4" x 3 3/8" x 1 3/8".

Programming Instructions

CP-SW-TD6A

Lynx Switch Light Delay

For the old Lynx 455 operators

41AB050-2

LiftMaster Electronic Circuit Board Assembly

Assembly includes: Logic board end panel and light sockets
For belt drive models with 2-lights
Also known as 41AB050-2M

144C56

LiftMaster Idler - Cable Pulley for chain drive

For square rail assemblies
Same as 144C0056

.363_6"-RH

Torsion Spring .363 x 6" x 12ft RH Green/White

Wire size: .363
Inside diameter: 6"
Length: 12 ft

.234_2"-RH

Torsion Spring .234 x 2" x 12ft RH Blue/White

Wire size: .234
Inside diameter: 2"
Length: 12 ft

50307

Doorlec Cam Shaft Sub-Assembly EHJ ETH ETBH LJH

For models; EHJ ETBH and ETH
Assembly includes: Cam shaft (26140) Oilite (11801) x 2 Sprocket 41B12-5/8" (31118) Flange Bearing (28002) x 2 and nuts.

MK-00653

Micanan 3-btn O/C/S Transmitter 372 MHz

Hand held transmitter for on-board receiver with smart 10.0 board only

Programming Instructions

CP-BRAKE-ASSBLY

Lynx Brake Shoe Assembly

Brake shoes for all Lynx operators
Assembly includes the shoes
release spring and bolt included

CP-CRG-OLD

Lynx Auto Re-Connect Carriage 20-1/2" Arm Sold Separately *** Discontinued

Will work on most brands of commercial trolley operators using 2" angle tracks.

H14G01

Hinge #1 x 14 gauge

Bright zinc plated 14-gauge steel hinge
For use with 7/16" diameter stem rollers
Full body hinge 2-3/4" wide
#1 position
Use between sections 1 and 2 or in the center position
Same as part number 241

.......more details

SEL2641R433-C2P

Erone 2-Relay Stand Alone Power Receiver 433MHz

Up to 85 transmitter keys
1 NO relay + 1 NO/NC relay (230Vac)
Self-learning memorization
Relays with Pulse step or delayed operating mode.
Power requirements: 12/24Vac/dc
Dimensions: 140 x 115 x 53mm (5.5 x 4.5 x 2in)

.......more details

Installation Manual Wireless System Chart

14FT-TROLLEY-SET

LiftMaster 14ft Double Angle Rail Set for Comm. Trolley Ops 10-5814-P (2 pcs) *Actual length 203"*

Double Angle Rails for doors up to 14' high
Works with models : MT T GT APT
Indicated selling price is calculated with the purchase of a commercial operator. For pricing on a double angle rail only please contact us
Actual Length 16' 11"

VBELT_4L340

Manaras VBelt 4L 34" - repl. by A32

Used on MTH/MTBH APE APT models
Same as Doorlec 19030

LIMIT025

Manaras Single Snap-Action Limit Switch with Flat Lever

Replacement for LIMIT001
For all Manaras commercial operators prior to 2000 - except light duty models
Can be used on Doorlec Lynx and others
Unimax (SPDT)

Limit Switch Chart

8331.96

Whiting Brush Top Seal assembly 96"

Fits Coldsaver and Tempguard

2234.296

Whiting Coldsaver Bottom Panel 12-1/2" x Max 96" with lock seal and retainer ** Cut to Length

Fits Coldsaver Roll-Up Doors
1-1/8" thick 96" wide
Includes Lock and keeper

298601

Linear Wireless Multi-Code Keypad 310 MHz

Compatible with 310 MHz Stanley and Multi-Code receivers
4-digit access code
Backlit keys
Easy access to battery
Power: 9-volt battery
Codes: 1024 (set by dip switches)

.......more details

Installation Manual

308913

Linear 1-Channel Multi-Code Visor Transmitter 310 MHz

Open/Close remote for 1 door
Compatible with 310 MHz Stanley and Multi-Code receivers
Supplied with visor clip
Easy access to battery and coding switches - 10 dip switches
Power: 9-volt battery
Codes: 1024 (set by dip switches)

.......more details

Programming Instructions

1336.1

Whiting Curbside Top Panel Closure Bracket for 10" radius

831-RJ

Allstar 1-Door O/C/S Receiver in Oil Tight Case (JIC) 107478 318 MHz *** To extent of inventory

Three channels - three relay outputs
Oil-tight JIC ABS case
Terminal strip for wiring
Wire whip antenna with "F" connector
Compatible with Allstar Classic Allister and Pulsar dipswitch transmitters and MVP quik-code transmitters
Power: 24 VAC/VDC

.......more details
