RADIO-EM932

Manaras 32-Door Dip Switch Transmitter O/C/S

3-button transmitter
Operates up to 32 doors by using a combination of 2 rotary dials and dip switch keys
Open/Close/Stop function
LED Indicator
Soft touch push buttons including a bright red stop button for easy identification
Includes 4 mounting screws and anchors
Comes with 2 AA batteries
Wall or Post mount
313 MHz

Programming instructions Manual

VWS-34-BLACK

Screw Colored for Vinyl Weatherstrip #8 x 3/4" 1000/Box Black

Pan head
S point

KPR2000

LiftMaster Wired Keypad and Proximity Reader

The KPR2000 supports a maximum of 2000 users in multiple access configurations (card only 4 to 6 digit PIN only or a combination of card and PIN).
Supports HID 26 and 30-bit Wiegand proximity card formats.
Designed for outdoor environments with a sealed weather proof design allowing you to easily mount anywhere.
Functions as a Stand-Alone Controller or in Pass-Through Mode (Wiegand Keypad Wiegand Proximity Credentials ASCII Keypad).
Latch Mode allows you to hold open a door or gate for an extended period of time.
Rapid Programming and Block Enrollment capability “Add” and “Delete” program cards included.

.......more details

Installation instructions Manuel d'installation Sell sheet Brochure Wiring instructions Instructions de cablage

1EBX

Explosion Proof 1-Btn Control Nema 7 & 9 Surface Mount

NEMA 7 & 9
Explosion proof enclosure
One button control
Button: 6 amp @ 125VAC
Normally open
Metal Enclosure: H=6-1/8" W=3" D=4-3/8"

.......more details

MCJH-12-115-ECB

Lynx MCJH Heavy-Duty Jackshaft 1/2 HP 115V with ECB UL325 ** Replaced by CDJH

New LX100 circuit board.
Built-in 3-channel 372 Mhz radio receiver accepts up to 20 remotes
4L V-belt primary reduction #41 drive chain and sprockets.
Adjustable friction clutch magnetic solenoid brake.
Fully driven adjustable limit switches.
Heavy duty 3 button wall station (Open Close Stop).

.......more details

110550

Allstar MVP 3 Channel 24V 3 Terminal 4 Wire Receiver 318 MHz *** NLA

3 channels 4-wire 3-terminal operator connection
Wire antenna included
Compatible with Allstar Classic Allistar and Pulsar dipswitch transmitters and MVP quik-code transmitters
Power: 24 VAC/VDC
Codes: 19683
RF frequency: 318 MHz

.......more details

Programming instructions

ZZ36767890

Rolling Service Door MDL 922 22-Ga 8' x 8'

Standard Max Width 14 ft
Standard Max Height 14 ft
Steel aluminum or stainless steel construction
Flat or curved slats available
Wind load 20 PSF standard; options up to 31 PSF
Non-Insulated

.......more details

109441.0002

Overhead Complete Limit Switch Assembly JST

Replaces part number 109441.0001
Replacement has 3 limit switches

TR-GUARD

Track Guard Z type 60" high to Protect 3" Track Sold as a Pair

Provides impact protection to vertical track
11 gauge (.125 thick)
Galvanized steel no paint

MK00642

Micanan Smart 10.0 Full Feature Circuit Board with Contactor Interface Monitored 575V

For all HP - 575V all voltages 1.5 2 3 & 5HP

Instructions Manual

JRGX1

Chain Hoist Jack Shaft JRG V2 1" Shaft Torque Force (126689)

Jack Shaft Mounting plastic guide 4.5:1 reduction
Gear drive
Fits 3-3/8" minimum offset
Includes: 26' of galvanized hand chain - doors higher than 15' require additional hand chain
1 chain keeper
2 shaft collars

.......more details

Sell sheet

OEB-1

Super Sneaky Operator Extension Bracket

Improves installation safety
Extends operator rail travel length. Use a 7′ rail for 7’6" – 8′ tall doors
Saves extra 2" of headroom required by draw bar type operators
Pulls door clear of opening
Eliminates garage door overhang
Greatly increased installation ease & safety

.......more details

M-VERSION

Manaras Monitored Entrapment Protection Option Upgrade Mont Thru-Beam + N1 Eyes

Upgrades added when purchasing a commercial operator

OPH-6113-CONT-R

Manaras Opera-H 3/4HP 120V 1Ph with Mechanical Contactor Right Hand

A heavy-duty industrial jackshaft operator
For use on Standard High and Vertical Lift sectional doors
Can also be used on Rolling doors and Grilles
Comes with a self-engaging chain hoist for manual operation
Clearence: side room required 15"

Installation Manual Sell Sheet

71-B575-1

LiftMaster Internal Brake Kit 575V 3PH for L5 Operators

Complete with: Brake hub kit Brake release lever Brake disc Spring cup Studs Compression springs Brake solenoid Solenoid cover Spacers Mounting plate Pressure plate Feather key and Conduit
Can be replaced in-field

Instruction Manual

AMB-3002

Ambassador 3002 1-Channel Receiver ***Replaced by DR & DT

Works with Ambassador remotes
Can use Allstar 313 MHz R-MVP3W or R-MVPC

SS-1

Super Sneaky Low Headroom Top Bracket Sold as a Pair

Designed for use with low headroom standard lift automatic garage door installations
Eliminates the need for low headroom double track
Effective and easily doubled up for heavy commercial door applications
Replaces top fixture and uses existing roller
Zinc plated heavy guage metal
Sold as a pair

.......more details

GH105-L5

LiftMaster Gearhead with Brake 1 HP 575V 3-Phase Logic 5

GH-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
The operators are typically mounted to the wall when used with sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
GH operators are attached to the door jackshaft to indirectly drive the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
MyQ Mobile App is a free download with no annual activation fee.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

MK-00002

Micanan Timer Module (2 wire)

T501L5

LiftMaster 1/2HP 115/230 Volt 1Ph Commercial Trolley Operator

New Logic 5
Suspended from the ceiling the operators are used on sectional overhead doors with standard lift.
T operators are directly attached to drive and control the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
MyQ Mobile App is a free download with no annual activation fee.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

.225-258-L

Cut-to-Length Torsion Spring .225 x 2-5/8" Left Hand Wound Orange/Green

Priced per inch - cones sold seperately
For factory installed cones use part no. C-258-INSTALLED

108135.0004

Overhead Serpentine V- Belt for JST 31"

Overhead Door commercial garage door opener serpentine belt 108135-0004
Type "J" 31"

ER4

Carlo Gavazzi Reflector 3-1/4" (84mm) Round

Can be used with the PMP12RI retro-reflective detector
Can be used with the reflector hood
Dimensions: 84 mm wide 7.4 mm thick

TUBE_SHAFT_10FT

Hollow Shaft 1" x 10'-10" Galvanized 16 gauge

When ordering order one foot longer that actual door width

STRIP_CURTAIN

Complete PVC Strip Curtains Made to Order

Please call us for price and delivery we can supply complete doors and replacement PVC strips for existing installations. Many different sizes and colors are available

K001A6837

LiftMaster Replacement Logic 4 Circuit Board L4

iftMaster replacement logic board (L4) kit for Commercial operators L4 board is UL325 compliant & requires CSPU photoeyes for momentary contact operation
Works with LiftMaster operators of all voltages and HP
Maintenance Alert System (MAS)
Open Mid Stop feature
Timer-to-close mode
Car dealer mode

.......more details

DT

Linear 1-btn Delta3 Transmitter 310 MHz (DNT00002A)

Activates one Delta-3 receiver
Test/operate LED
Visor mounting clip supplied
Power: 9-volt battery
Codes: 256 (set by 8 dip switches)
RF frequency: 310 MHz

.......more details

Programming Instructions

25-10577

Truck Door Cam Lock Handle Only for Whiting Roll-Up Doors

Steel construction Black E-coat finish.
Cam lock allows one hand operation and easily accomodates padlock or car seal.
Can be used as a lift handle in open position
Back plate is offset to clear bottom seal retainer
Spring assisted handle eliminates door bounce
Handle Keeper Sold Separately. Use part #25-10578

.......more details

SAG-M

Siren Activated Gate Sensor Formally SOS Sensor

New and Improved Siren Operated Sensor SOS.
Allows Entry of Emergency Vehicles through Gates
The Siren Activates Gate Opener while all other sounds are rejected
Comes with a 4 x 5 Inch Reflective Sign
12-24VAC/DC
Emergency responders use the YELP signal to activate the gate

.......more details

GH101-L5

LiftMaster Gearhead with Brake 1 HP 115/230V 1P L5

Gearhead style commercial door operators employ lubricated gears for heavy industrial high cycle applications.
GH-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
Hoist wheel is easily moved to Right or Left hand side of unit eliminating the need to order right or left hand mounting.
MyQ Technology enables you to securely monitor and control your facility operator with your smartphone tablet or computer. Internet Gateway 828LM required.
Security +2.0 radio receiver safeguards your facility - with every click a new code is sent to the commercial door operator so the door opens only for you.
Timer-To-Close: Conveniently and confidently closes the commercial door automatically after a predetermined amount of time has elapsed for added security and peace of mind.

.......more details

Installation Manual Manuel d'Installation Sell sheet Brochure

BGARM12

LiftMaster TECHNA Barrier Gate Arm 12 ft without LED

3” Aluminum arm with integrated LED lights channel designed exclusively TECHNA barrier gate operators
Ships in manageable 6-foot sections for streamlined transport and storage enabling easy on-site assembly
Strong aluminum extrusion with reenforced male/female joining sections and fasteners for a secure fit
The arm features a bottom channel designed to hold BGARMFOAM thereby minimizing the chance of scratching the vehicle. Additionally it is compatible with the S50L a wireless edge safety device.
(Optional) LEDs are easily installed by sliding them into the arm's center channel and securing them with the included press-in clip
IP68 rated waterproof LED lights

.......more details

210266

Skylink LED Board Atoms/Atoms Pro

K41-0383-000

LiftMaster Toroidal Transformer 1200lb / 120VAC-240VAC

For Maxum ops

K41-0410-000

LiftMaster 1200 Extended Duty Motor Gear Box Encoder Hoist

For Maxum Hoist 1200 Op

JDC7S1BMC

LiftMaster MAXUM Jackshaft DC Commercial Op. w/BBU 700LB

Max door height: 40 ft. Max. Sectional doors up to 700 lbs. Rolling steel or insulated doors up to 450 lbs.
myQ Compatibility: Setup available for either myQ or myQ Facility
Operating Temperature: Without Heater: -4°F (-20°C) – 140°F (60°C). With Heater: -40°F (-40°C) – 140°F (60°C)
Heater sold seperately
Voltage: 120V/240V (1PH/3PH); 480V (3PH); 208V & 600V (3PH) available with transformer accessory
Motor Power: 24VDC

.......more details

JDC7S1BMC_Installation-manual JDC7S1BMC_Manuel-installation Data sheet Fiche Technique Quick connect guide Guide de connexion rapide Ordering guide Sprocket recommendation

IRB-4X2

EMX Nema 4 Through-Beam Photocells EMX-1250-1 Hood Sold Separately

The IRB-4X2 photoeye is used as a safety reversing or opening device in conjunction with automatic operators.
The IRB-4X2 will work with any control board that accepts dry contact on the input.
The easy to install IRB-4X2 is used with garage doors rolling doors parking barriers and other equipment.
*Not for use in applications requiring UL325 compliance
Thru beam design is not affected by shiny surfaces
Wide 24˚ transmission angle allows easier alignment and increases reliability

.......more details

Installation Manual Specification Sheet

PHOTO-065

Manaras Monitored Photoelectric Cells N4X Retro-Reflective 5-50' Range

Monitored NEMA 4X enclosure retro-reflective type photocell
2-Wire
Suited for harsh environments
Range: 5-50 ft

Manual

MSEL

LiftMaster Steel Stand for Mounting to Concerte Pad

Stand height: 7.5 in.
Compatible with SL3000UL

P-535T

Pulsar 3-btn 27-Door O/C/S Transmitter 318 MHz

Allstar compatible
Wall mount
OPEN-CLOSE-STOP 27 doors
8 dipswitches 318 MHz

Programming instructions

PRO-SD-7511-U-LH

Micanan 3/4 HP 115V 1P Horizontal Sliding Door Op. ECB Monitored Left Hand

Designed for use on commercial / industrial sliding doors or sliding fire doors
External radio control terminal strip
3-btn O/C/S control station Nema 1
#41 roller chain & sprockets on all internal drives
Heavy duty 5L v-belt
Solenoid brake standard

.......more details

MA010

LiftMaster Gate Arm Bracket

Designed for use on all Mega Arm gate openers
Bracket will work with either right-hand or left-hand operation gate arm.

MAX-ROLL-DOOR

Max-Roll Rapid Rubber Door Custom Order Price by Quote ONLY

Safe durable and easy to maintain.
For industrial commercial & institutional usage.
Quality materials & components at the forefront of technology.
Each door is custom ordered price by quote only

HAE00072

Linear WiFi Wall Station

This Wi-Fi wall station allows direct operation of the door operator and light using the buttons.
When connected to your local wireless access point you can check status get notifications open or close the door and manage user access from any location via the Linear Android or iOS app.
Requirements: To use with the app you will need:
a Wi-Fi network with internet connectivity
a strong Wi-Fi signal in the garage where you are installing the wall station
an Android or iOS smartphone or tablet

.......more details

Programming Instructions

FORK002-LH

Manaras Disconnect Fork Left hand

ZAP-8800

Zap 8800 Series-3 Opener

ncludes: (1) 8825-3-(pulley size TBA) c/w motor head assembly and control box

MIC001

Manaras Internet Control Device Modification (Op has to be compatible)

The internet control device allows you to control and monitor your garage door from anywhere using the MIC app and your smart device
Includes the MIC device and Wi-Fi compatible board & software
Must be purchased and used with a Manaras monitored operator

EXA-1000

Linear Omni-Directional Remote Antenna (AAE00198)

The EXA-1000 is a 1/2 wave center fed vertical antenna composed of three parts: an Antenna assembly with an F connector attachment; a Base Plate assembly with radial mounting provisions; and a five-foot 75-ohm coaxial cable.
The cable connects to the antenna base on one end and the receivers F connector on the other.
If the antenna must be mounted further than five feet from the receiver an extension cable of up to a maximum of 25 feet may be used instead of the five foot cable supplied.
Because of the cable resistance the performance of the EXA-1000 may be degraded by using longer than a 25 foot cable
Compatible with all Linear receivers with Type F antenna connector
Receives signals in 288 to 320 MHz range

.......more details

Installation manual

RSL12UL

LiftMaster Res. / Light Com. DC Slide Gate Op. MyQ Tech. Heater Sold Separately UL Listed

RSL12UL features battery backup that provides up to 114 cycles or 63 days of standby power.
myQ® Technology enables you to securely control and monitor your gate operator from anywhere.
Wireless Dual-Gate Communication synchronizes gate opening/ closing and eliminates expensive driveway trenching costs.
Security+ 2.0® safeguards access with an encrypted tri-band signal to virtually eliminate interference and offer extended range.
Includes: LMRRUL Monitored Retroreflective Photo Eye and S505AL Monitored Small Profile Resistive Edge
Gate Travel Speed: 10” per second

.......more details

Installation manual Manuel d'installation Sell sheet Brochure

LDCO863B

Linear DC Powered Garage Door Opener Accepts Both Belt or Chain Rail

Ultra-Smooth and Quiet Industry leading performance with variable speed operation soft start/stop and ultra quiet motor
Integrated Battery Backup Energy-Efficient LED Lighting Long life dimmable LED light panels included. Secure.
Responsive Remote Control Linear MegaCode remote controls operate over long range and employ high-security technology
Release the operator’s quick-disconnect trolley to open or close the garage door manually
Self-Diagnostic System: Confirms proper operation and alerts users both audibly and flashing the lights. In the event of a problem it pinpoints the trouble and alerts users by flashing the courtesy lights
Linear ® Smart App Advanced real-time monitoring and control of garage doors from any mobile device. * Assign custom access and permissions for up to 10 authorized users and schedule door and light operation.*Wi-Fi and internet connection required

.......more details

Remote compatibility chart

CPS-EI

LiftMaster 4-Wire Sensing Edge Interface

Designed to provide advanced safety and security to the door system in commercial environments.
This device is intended for use with LiftMaster Logic Commercial door operators and compatible with 4-wire monitored sensing edges.
This is a stand-alone reversing system and is not intend to be used in conjunction with any additional entrapment protection devices.
A junction box not provided is recommend to protect exposed wiring.
Compatible with Logic 5.0 Logic 4.0 Medium Duty Operators and Fire Door Operators.

255743

Wayne Dalton D-Shaped Bottom Seal Black Sold per Foot

Black only
Flexible PVC

CHAIN059

Manaras #41 chain 48 Pitch (24" long)

Includes 1 chain link

HCNB14

Richards-Wilcox 14 Gauge Center Hinge 9-2317

Galvanized 12 gauge hinge

BEA-10-BR3X

BEA Programmable 3 Relay Logic Module w/13 Functions

For use on automatic pedestrian doors access controls industrial automation and single-occupancy restrooms. •13 Functions Include:
Timer
Ratchet/Latching
2 Relay Sequence + Inhibitor
2 Relay Sequence + Door Position
Deactivation Timer

.......more details

Product guide

DW-3S-200

Fraba Air Wave Switch Small Housing NOC

Fraba DW3S-200 air switch
Normally Open Contact (NOC)
Small Housing does not come with copper end
Screw Type Connector
Housing dimensions: 101x48.5x48 mm (3.97x1.91x1.89 '')
Housing: ABS Switch: PA6V0

.......more details

Operating Instructions

SOFT_EDGE-ENDCAP

Devanco Canada Soft Edge End Caps Sold Individually

229557

Torque Force EZ Low Headroom Conversion Kit

Reduced headroom as low as 8"
Convert a standard lift door to a low headroom door without using an outside hookup configuration.
Easy to install 3 piece kit
Fits on 15" radius and 12" tracks

827LM

LiftMaster MyQ Remote LED Light Sec+ 2.0 *** To Extent of Inventory

Easily mounts on ceiling or wall within 6 feet of a 120V electrical outlet.
Can be programmed to turn on and off at certain times through the MyQ App.
LED bulbs require no maintenance.
1500 lumens – about 50% brighter than many standard LED lights ensures the garage is always bright.
Programmable to work with any MyQ – connected garage door opener Security+ 2.0® garage door remote control/control panel or smartphone.
Compatible with remote models: 374UT 375UT 892LT 894LT 891LM 893LM 890MAX and 893MAX

.......more details

MF00009

Micanan Hex Head Bolt 1/4" - 20 UNC x 2-1/4" Partial Thread

Used on PRO-HHD
1 required per operator

K1D8388-1CC

LiftMaster Main Control Board Linear Actuators for UL325

This replacement board is compatible with the following models: LA500U LA400U LA412U
Same as 001D8388-1CC
Sticker on board references 001D9040-1CC

VWS-34-WHITE

Screw Colored for Vinyl Weatherstrip #8 x 3/4" 1000/Box White

Pan head
S point

VWS-34-BROWN

Screw Colored for Vinyl Weatherstrip #8 x 3/4" 1000/Box Chocolate Brown

Pan head
S point

BBU

Linear Battery Backup Unit for LDCO800 Models

Easily integrates with all Linear LDCO800 Garage Door Operators
Supplies 800 Newtons of lifting force for heavy doors
Delivers smooth efficient power in the event of a power failure
Compact kit contains all necessary installation/mounting hardware
Dimensions: 4.25" W x 5.00" H x 3.12" D

F3100MBC

Linear Wireless Keypad with Intercom Estate Series *** Disc

Increased Surveillance: Screen visitors and solicitors safely from inside your home
Superior Range: Crystal clear two-way wireless communication up to 500 ft. (152.4 m) without any obstructions
Stand Alone Keypad: Program up to 100 entry codes for added security
Motion activated backlit keypad
Kit includes 1 base station with rechargeable battery

CRBH751L5-LH

LiftMaster 3/4 HP 115/230 VAC 1 PH Commercial Hoist Operator Logic 5 with Carwash Modification

H-style operators include a floor level chain hoist to ease manual operation in an emergency or power outage.
The operators are typically mounted to the wall when used with larger sectional overhead doors with vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
H operators are attached to the door jackshaft to indirectly drive the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Alerts can be received as email or pop-up (push) notifications on a mobile device ensuring the status of your commercial door.
Security+ 2.0™ safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you.

.......more details

V-101-B

Vinyl Black Sold per Foot

Vinyl for 101-ALUM

BELT-GEAR

Skylink Belt Gear for EQ Operators 210131 ***NLA

New model # 210131 no cover is needed
Metal Gear

103146

Marantec Synergy 380 Residential Opener 1.1 HPCS Head Only

Equipped with over 1 HPCS of pull and push force
Ideal opener for large and heavy applications like carriage house doors or large wind-loaded doors
315MHz 2-channel remote control is included. Multi-bit code technology ensures interference free performance
Soft Start and Soft Stop functionality is reducing wear and tear on the operator system garage door and hardware
HomeLink compatible
Comes with 1.2 mm heavy-duty rail

.......more details

Installation manual Sell sheet

CPS3-N4

LiftMaster Option Card with CPS-UN4 Eyes for applications requiring 2 sets of photocells

For applications requiring two sets of photoeyes in a damp location
Range up to 45ft water dust and corrosion proof eyes (Nema 4x rating)
Works with Logic 3 4 5 Commercial Operators
Includes Durable steel brackets - floor or track mounting
Kit Inludes one set of CPS-UN4 and one CPS3 card ( CPSIII )

T-832-M-H

FL-Heddolf 2-btn Mini Transmitter P219-2K-311 MHz (T-832-M-S)

Open/Close mini remote for 2 doors
Keychain and 12V battery included
Compatible with Keystone T-832-H and old Allstar T-832
8 dip switch
Same as P219-2K

Manual

LYNX-6000-BOARD

Lynx 6000 Commercial Logic Board

Replacement logic board for Lynx commercial operators built from 2002 through 2005
Will not work for the ALDJ Model (Light Duty)

Basic Operation Manual

C16-32FHD

Bearing 1" x 2" Press Fit Heavy-Duty

Flanged ball solid steel bearing
Rating: 1 000 000 revolutions
Axial load: 150lb max
Radial load: 900lb max

27-24301

Truck Door Single Torsion Spring Assembly 89.5/48 for Todco Roll-Up Doors

Single counterbalanced spring design available in 36" 48" and 60" spring lengths.
Shaft Length: 89.50" Spring Length: 48" Wire Size: .243
Right hand wound
Quick and easy counterbalance spring adjustment with easy calibration to door size and weight for effortless operation.
Springs treated with rust preventative
Heavy .243 dia. spring wire

.......more details

J751L5

LiftMaster Industrial-Duty Jackshaft 3/4 HP 115/230V 1Ph L5

Doors used with this operator should be balanced with the ability to be manually lifted by hand in an emergency or power outage.
The operators are typically mounted to the wall when used with smaller sectional overhead doors with a vertical or high lift and mounted to the wall or the front of the hood when used with rolling doors and grilles.
J operators are attached to the door jackshaft to indirectly drive the door
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Security+ 2.0® safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you

Installation manual Manuel d'installation Sell sheet Brochure

DXR-701

Linear 1-Channel Digital Receiver 315 MHz

A digital receiver with an isolated relay output designed for use with Linear's DX Format transmitters.
When the receiver detects a signal from a transmitter programmed into its memory the relay output activates.
The relay has four optional output configurations.
32 transmitter capacity
RF activity indicator
Quick-learn programming

.......more details

Installation Manual

HSC-1000

Hand Swager 1/4" & 5/16"

Swages 1/4" and 5/16"
Made in Japan

LA400DC-S

LiftMaster Residential 24VDC Linear Actuator Secondary Arm Only New Model

Secondary Arm Only for LA400
All new arms are backwards compatible with the previous model but the LiftMaster branding is different

Installation Manual Manuel d'Installation Sell Sheet

BRAKE013

Manaras Band Brake Assembly Kit OSH

Installation Manual

21-10340

Transformer 115-24V AC 20VA

120V Primary 24V Secondary 20VA

.225-2-5/8-RH-C

Torsion Spring .225 x 2-5/8" x 144" RH Coated ** Price by Quote Only

Black Oxide coating
Wire size painted on spring
Wire size: .225 ID: 2-5/8" Length: 12 ft

CPS-MEI

LiftMaster Electric Edge Card **to extent of inventory

The CPS-MEI is an interface for a monitored 2-wire edge that can be used in place of photo eyes and meets the monitored requirement of UL325-2010
Same as Miller Edge SM-102

YSG12-24LED

Devanco Stop and Go Light Yellow Housing 12-24V LED

LED Traffic Light Red/Green Dock Light
Weather-proof 2 piece housing with highest available UV rating
Wide input voltage range of 10-32V AC/DC eliminates the need to stock 12V and 24V models.
Ultra bright LED's for easy viewing in direct sunlight
Lenses measure nearly 4" in diameter
Requires 4 wall mounting screws 1/4" or 5/16" thread - not supplied

.......more details

Installation Instructions Instructions d'installation Sell Sheet

T751L5

LiftMaster 3/4 HP 115/230V 1P Commercial Trolley Operator Logic 5 *** No Longer Available

Trolley low profile with brake
Suspended from the ceiling the operators are used on sectional overhead doors with standard lift.
T operators are directly attached to drive and control the door.
MyQ® Technology enables you to securely monitor and control your facility operator and lights with your smartphone tablet or computer for greater peace of mind.
Security+ 2.0™ safeguards your facility – with every click a new code is sent to the commercial door operator so the door opens only for you.

Installation Manual Manuel d'Installation Sell sheet Brochure

7140251

FAAC Hydraulic Oil HP2 1 Litre *** To extent of Inventory

MT22-BLACK-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

��Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty

Installation Manual Worksheet Sell Sheet

22-575

Brake Solenoid 575V

Same as Solenoid004
Fits on all 575V garage door or gate operator brake system.

41A6408

LiftMaster Travel Module (8500 3800P 3800PLD & 3900) - 41B8861

Works on model 8500

Programming Instructions Instructions de programmation

50-104-1

Black Coil Cord 2-Wire 18-ga 20 ft. Extended Curly Cord

Retracted Length=4 Feet Extended Length=20 Feet 2 Wire 18 Gauge Cord Type SJEO

24858

Capacitor 220/250VAC 53-64MFD

Motor start capacitor for 1/3 & 1/2HP garage door openers
Same as part number 219110
Dimensions: 1.810" D x 3.38" H x 0.50" C

CPS-UN4

LiftMaster Commercial Protector System Thru-Beam Eyes NEMA4

Waterproof photoeyes.
for direct connect to operators with Logic boards. L3 L4 L5
Receiving Eye - A: 50-50997 Sending Eye - A: 50-50998
These eyes will also work on the Micanan UL325 monitored operators

Installation Manual Manuel d'Installation Sell Sheet

K001A5566

LiftMaster GL Replacement Board

Replacement Logic Board for LiftMaster Gate Operators
Fits Slide operator SL570 SL575 SL580 SL585 SL590 SL595
Fits Swing operators SW420 SW470 SW490

377LMC

LiftMaster Wireless Keyless Entry 315 MHz ***Replaced by 878MAX

Compatible with Liftmaster Sec+ garage door openers commercial door operators gate operators and radio control receivers
Mounts easily to the door jamb with two screws
Compatible with openers built 2005+
Replaces 376LMC and same as Chamberlain 956D same as 377LM
Includes 9V battery

Programming Instructions Instructions de programmation

823LM

LiftMaster Remote Light Switch Sec+ 2.0 ** To Extent of Inventory

Controls lights remotely
Turn on lights in your garage yard or home with your garage door opener remote control
Use with LiftMaster Internet Gateway to control lights from smartphone or computer
Compatible only with Security+2.0 garage door openers and accessories enabled by MyQ technology

Installation Manual Manuel d'Installation

71-B120H

LiftMaster Interior Brake Kit with Cable 115V (Logic 3 4 and Models)

Interior mount brake kit for operation with chain hoist
Works on mechanical operators as well as logic 2 3 4 and early logic 5 motors.

Instruction Manual

T-833-C

FL-Allstar 3-btn 9-Door Transmitter 109023-311 MHz***NLA

This nine channel transmitter controls up to nine doors (open-close) or three doors (open-close-stop).
It has a height switches encoder with three positions: + 0 and - .
Manufacturer's model number: 8833TC (190-109023)
Dimensions: 4 5/8" x 2 1/4" x 7/8"

Programming Instructions

41DJ001

LiftMaster Circuit Board with Plate for 3800 3900 41DJ001B

Board: Security+ 315 MHz
For jackshaft models; 3800 3800P 3800PLD & 3900
Also known as 41DB001-2

Programming Instructions Instructions de programmation

890MAX

LiftMaster 3-btn Mini Transmitter Security+ 2.0

Can be used as a replacement remote control for 80 Series 970 Series and 370 Series LiftMaster remote controls.
Compatible with 315 MHz or 390 MHz garage door openers manufactured after January 1 1993.
For use with gate operators commercial door operators or other products that are 315 MHz or 390 MHz and have a Learn Button.
Includes 3V battery (CR2032)
Same as 953CB
