Home Chamberlain, LiftMaster Commercial Door & Gate Operator Accessories Access Controls
02-711

LiftMaster Nema 7/9 Ceiling Switch Pull Control

  • Single Pull Switch Control
  • Hazardous Area Overhead Mt. (NEMA 7/9)
  • Die cast hazardous area enclosure
  • May be used in two different ways; as an OPEN only control (all LiftMaster operators) or as an OPEN/CLOSE control (only LiftMaster operators with types B2 and S2 control wiring). In the latter case pulling the cord will open a fully closed door close a fully opened door and reverse a closing door.
  • Pulling the cord whlie the door is opening will either have no effect (type B2 wiring) or will stop the door (Solid State Logic Control Board).
  • WARNING: When used on most industrial operators this control will not stop the door. Use another control that has a STOP button in conjunction with this control.
    • .......more details
02-411

LiftMaster Pull Switch Assembly Nema 4

  • May be used in two different ways: as an OPEN only control (all LiftMaster operators) or as an OPEN/CLOSE control (only LiftMaster operators with types B2 and S2 control wiring).
  • In the latter case pulling the cord will open a fully closed door close a fully opened door and reverse a closing door.
  • Pulling the cord whlie the door is opening will either have no effect (type B2 wiring) or will stop the door (Solid State Logic Control Board).
02-103L

LiftMaster Push Button Station 3-btn Surface Mount O/C/S Nema 1 with Maintenance Alert LED

  • PBS-3
  • Open-Close-Stop
  • Momentary contact
  • Nema 1
  • Works with Liftmaster MH commercial operator
  • Dimensions: 5-5/16" H x 2-3/8" W x 1-13/16" D
    • .......more details
02-406

LiftMaster Push Button Station Nema 4 O/C/S with Keyed Lock-Out Die-Cast Enclosure

  • Code on key is #301
02-101

LiftMaster Single Button Nema-1 Pushbutton Control Station

  • Surface mount
02-409

LiftMaster Key Switch 2-Position Nema 4/12

  • Two Position Key Control Station
  • Outdoor Surface Mt. (NEMA 4/12)
  • Tamperproof
  • Die cast metal enclosure with standard key cylinder
  • OPEN/CLOSE spring return to center (OFF) key removable in center position only. Should only be used on operators wired for constant pressure to open and close (all LiftMaster industrial operators with type D control wiring).
  • Dimiensions: 3" x 3.2" x 4.2"
    • .......more details
02-409B

LiftMaster Key Switch with Best Cylinder

  • Two Position Key Control Station
  • Outdoor Surface Mt. (NEMA 4/12)
  • Tamperproof
  • Die cast metal enclosure with BEST cylinder (construction core included)
  • OPEN/CLOSE spring return to center (OFF) key removable in center position only. Should only be used on operators wired for constant pressure to open and close (all LiftMaster industrial operators with type D control wiring).
  • Dimiensions: 3" x 3.2" x 4.2"
    • .......more details
02-407

LiftMaster Key Switch Assembly On/Off Nema 4/12

  • Two-position keyswitch. Key removable in either position.
  • Surface Mount
  • May be used on all operators
  • Die-cast metal enclosure non-tamperproof
50-450

LiftMaster Interlock Switch for Sectional Door Nema 4 (Same as 50-13529)

  • Interlock switch is engaged by the door side lock and disables operator control.
23-10916

LiftMaster Hoist Interlock Switch SPDT

  • Interlock switch for LM commercial door openers with hoist disconnects
  • 15A 125/250VAC
AFB120

LiftMaster Fire Access Box w/Micro Switch & Knox Key Switch Option

  • ll-in-one fire access box
  • Includes: access door with a hole for a standard or fire department padlock interior micro switch knock out for Knox key switch and standard cylinder lock
  • Two options for automatic gate access: 1) micro switch is activated when the padlock is removed and the front panel is opened or 2) via Knox key switch
  • NOTE: fire department padlock and Knox switch NOT provided
02-410B

LiftMaster Commercial Key Control Station Open-Close and Off with Stop Button and BEST Cylinder

  • Outdoor Surface Mount Nema 4/12 station
  • Standard key cylinder is replaced with BEST cylinder
  • Open/Close spring return to center (off)
  • Key removable in center position only
  • With Stop button
02-410

LiftMaster Commercial Key Control Station Open-Close and Off with Stop Button

  • Outdoor Surface Mount Nema 4/12 station
  • Standard key cylinder
  • Open/Close spring return to center (off)
  • Key removable in center position only
  • With Stop button
LMSC1000

LiftMaster RFID Long Range Vehicle Access Card Reader

  • Easy wall or post mount vehicle tag/prox card reader can service an entire facility parking garage gated community/HOA or guarded properties.
  • Integrates into (CAPXL CAP2D) Liftmaster PPWR Passport Receiver and LiftMaster CSW24U 24 VDC Commercial Swing Gate Operator CSL24UL HCTDCUL systems to give access via encrypted-digital code.
  • Opens swing or slides gates from 20-30 feet distance
  • 26-bit Wiegand Interface console
  • Encrypted binary protocol signal
  • Helpful Programming/Testing/Function tri-color LEDs on both reader face and Wiegand console
    • .......more details
Installation manualManuel d'installationSell sheetBrochureWiring the LMSC1000 to KPR2000 Raccordement éléctrique du LMSC1000 au KPR2000
SP-LMHNTG

LiftMaster Rearview Parking Access Hang Tag 25/pkg Special Coded **Must provide FC & Start #

  • Rearview mirror hanger gives access to gated facilities complexes for cars trucks and other vehicles
  • Can be used for larger vehicles with higher cabs as vans various trucks
  • 20-25 foot detection zone
  • Device is engineered for use with the LIftMaster LMSC1000 Long Range Vehicle Access-Card Reader
  • Simple transferrable item can be swapped out for rental cars different vans/trucks in a fleet dealer/loaner repair cars and more
  • Tags are sold in batches of 25. Your location may have a facility code. Check with your maintenance department or administrator if needed
    • .......more details
LMHNTG

LiftMaster Rearview Parking Access Hang Tag 25/pkg Random Coded

  • Rearview mirror hanger gives access to gated facilities complexes for cars trucks and other vehicles
  • Can be used for larger vehicles with higher cabs as vans various trucks
  • 20-25 foot detection zone
  • Device is engineered for use with the LIftMaster LMSC1000 Long Range Vehicle Access-Card Reader
  • Simple transferrable item can be swapped out for rental cars different vans/trucks in a fleet dealer/loaner repair cars and more
  • Tags are sold in batches of 25. Your location may have a facility code. Check with your maintenance department or administrator if needed
    • .......more details
Installation manualManuel d'installationSell sheetBrochure
SRDRKP

LiftMaster Keypad Smart Reader

  • LiftMaster Smart Readers offer a contemporary appearance and leading-edge feature set to add access control to any door or entrance in your building or community including mobile credentials capabilities.
  • Standard technologies include Proximity (125 KHz) Smart (1356 MHz) and Bluetooth so that customers can migrate to newer secure credentials.
  • BLE communication enables myQ Mobile Credentials within the myQ Community app and ecosystem.
  • OSDP Auto-Connect feature to switch from Wiegand to OSDP when connected to the OSDP port on the CAPXLV2.
  • Accelerometer - based tamper detection
  • Tri-State LED light bar for user feedback
    • .......more details
LMUNTG

LiftMaster Glass Mount Parking Pass Tag Sold Per Card

  • A security-enhanced RFID passive transmitter for use with the LIftMaster LMSC1000 Long Range Vehicle Access-Card Reader.
  • Glass-mount means it can be affixed to either the windshield of a car or to the headlight housing of the vehicle
  • Aligns with the cone-shaped detection zone from LiftMaster RFID Reader and activates it to open gate barrier
  • Added security of single mount use: shuts off if removed after adhering to a surface
  • Use on trucks or other high-clearance larger vehicles; 20-25 ft detection range from reader
  • Tags are sold in batches of 50. Your location may have a facility code. Check with your maintenance department or administrator if needed
    • .......more details
Installation manualManuel d'installationSell sheetBrochure
K23-20523

LiftMaster Interlock Switch 125/250VAC 3A N4

  • For use with various LiftMaster® Commercial Door Operators
LM21XPBB

LiftMaster Extended Performance Fire Door Release Device with Battery Backup

  • UL864 Revision 9 compliant
  • Programmable DIP switch delay setting - either 10 20 30 or 60 seconds delay of door release to permit passage clearance
  • Inputs for normally open 2- or 4-wire detectors and 4-wire normally closed detectors
  • Trouble and alarm relays for communication with the fire alarm control panel if required
  • Audible trouble sounder to indicate when the release device is not operational
  • On board diagnostic LEDs for easy troubleshooting
    • .......more details
Installation Manual
