Home Gate Operators Slide
IHSL24UL

LiftMaster Heavy-Duty Industrial Variable Speed Slide Gate Operator with battery back-up

  • For Industrial Slide Gates up to 2200 lbs.
  • Variable cycle speed is adjustable from .5 ft./sec. to 1 ft./sec.
  • Industrial brushless DC motor with battery back-up
  • Continuous-duty gate operation built with industrial oil-bath gear box
  • Enclosure Lockable Weatherproof 14g NEMA 3R Steel Cabinet
  • Smooth start/stop operation and mid-travel reversal extend operator hardware life.
    • .......more details
IHSL24UL Installation-manualIHSL24UL Manuel-InstallationIHSL24UL Guide-installationIHSL24UL Guide-de-produit
BCSI-HV-100-23

Industrial Slide Gate Operator Variable Speed 1 HP 208V 3 Ph with Heater ** Price by Quote Only

  • Heavy-duty alminum cabinet Nema 3R
  • Programmable logic controller
  • Adjustable friction clutch
  • Thermostat controlled heater
  • Opening / Closing speed of 24" / sec
  • Nema 4 control panel
    • .......more details
Installation manualSell sheetBrochureInstallation overviewDessin de installationDiagnostics and troubleshootingDiagnostics et dépannage
CSL24UL

LiftMaster New 24VDC Commercial High Traffic DC Slide Gate Operator

  • Battery Backup: 208 cycles or up to 24 days of standby power when the power is down
  • Security+2.0®: Access your property quickly with Security+2.0® Technology that utilizes a tri-band signal that virtually eliminates interference and offers extended range each time the remote control is used
  • MyQ®: Securely control and monitor your Gate Operator from anywhere and get activity notifications through the MyQ® app
  • Soft start / stop extends operator and hardware life in high-cycle and heavy-gate applications
  • Wireless dual-gate communication eliminates expensive conduit costs and unsightly driveway scars
  • Keyed manual disconnect when unlocked allows gate to be operated manually.
    • .......more details
Installation manualManuel d'installationSell sheet
INSL24UL

LiftMaster Industrial Variable Speed Slide Gate Operator with battery back-up

  • For Industrial Slide Gates up to 2200 lbs.
  • Variable cycle speed is adjustable from .5 ft./sec. to 1 ft./sec.
  • Industrial brushless DC motor with battery back-up
  • Continuous-duty gate operation built with industrial oil-bath gear box
  • Enclosure Lockable Weatherproof 14g NEMA 3R Steel Cabinet
  • Smooth start/stop operation and mid-travel reversal extend operator hardware life.
    • .......more details
Installation-manualmanuel-InstallationProduct guideGuide de produitRetrofit guideGuide d'installation
BCSI-HV-100-21

Industrial Slide Gate Operator Variable Speed 1 HP 240V 1 Ph with Heater ** Price by Quote Only

  • Heavy-duty alminum cabinet Nema 3R
  • Programmable logic controller
  • Adjustable friction clutch
  • Thermostat controlled heater
  • Opening / Closing speed of 24" / sec
  • Nema 4 control panel
    • .......more details
Installation manualSell sheetBrochureInstallation overviewDessin de installationDiagnostics and troubleshootingDiagnostics et dépannage
BCSI-HV-100-53

Industrial Slide Gate Operator Variable Speed 1 HP 600V 3 Ph with Heater ** Price by Quote Only

  • Heavy-duty alminum cabinet Nema 3R
  • Programmable logic controller
  • Adjustable friction clutch
  • Thermostat controlled heater
  • Opening / Closing speed of 24" / sec
  • Nema 4 control panel
    • .......more details
Installation manualSell sheetBrochureInstallation overviewDessin de installationDiagnostics and troubleshootingDiagnostics et dépannage
RSL12UL

LiftMaster Res. / Light Com. DC Slide Gate Op. MyQ Tech. Heater Sold Separately UL Listed

  • RSL12UL features battery backup that provides up to 114 cycles or 63 days of standby power.
  • myQ® Technology enables you to securely control and monitor your gate operator from anywhere.
  • Wireless Dual-Gate Communication synchronizes gate opening/ closing and eliminates expensive driveway trenching costs.
  • Security+ 2.0® safeguards access with an encrypted tri-band signal to virtually eliminate interference and offer extended range.
  • Includes: LMRRUL Monitored Retroreflective Photo Eye and S505AL Monitored Small Profile Resistive Edge
  • Gate Travel Speed: 10” per second
    • .......more details
Installation manualManuel d'installationSell sheetBrochure
HDSL24UL

Liftmaster Heavy-Duty Variable Speed Slide Gate Op. 24VDC for Heavy Gates.

  • 1.5 HP Variable Speed Slide Gate operator for gates up to 75' and 3000lbs
  • Battery backup provides up to 45 cycles or 120 days of standby power
  • Smooth Start/Stop with variable travel speed of .5ft/sec to 1ft/ second.
  • 120/240 input voltage optional 3 phase converter for 208/240/460/575
  • On-Board Secutiry+ 2.0® Receiver accepts (50x) 8 series remotes or unlimited 811 remotes.
  • Includes LMRRUL Monitored Retroreflective Photo Eye with intergral heater
    • .......more details
HSLG-411

Linear Commercial Slide Gate Operator 3/4 HP 115V 1 Ph - Heater not Included

  • Great for industrial and commercial applications
  • Features the APeX control board
  • Emergency manual disconnect handle
  • Powder coat finish
  • Post mount standard; pad mount optional
  • Integral entrapment sensing system with dual multi-turn precision potentiometers for accurate adjustment and enhanced safety
    • .......more details
HSLG-121

Linear Commercial Slide Gate Operator 1 HP 230V 1 Ph - Heater not Included

  • Max duty cycle: Continuous
  • Integral APeX Controller
  • Double V-belt to chain reduction
  • #40 roller chain
  • Emergency manual disconnect handle
  • Powder coat finish
    • .......more details
SL595203UL

LiftMaster Dual Voltage Slide Gate Op.2 HP 208/230/460V 3 Phase - Heater NOT Incl. UL325

  • UL 325 compliant system.
  • Power: 208/230/460/575 VAC. 3 Phase.
  • Accessory power: 24VAC 500mA max.
  • Monitored safety inputs: 3 Main Board 3 Expansion Board.
  • Temperature specs: Without Heater: -4°F (-20°C) to 140°F (60°C). With optional heater (HTRNB: HTR460 for 460V operators): -40°F (-40°C) to 140°F (60°C)
  • Gate travel speed: 12 in. per second.
    • .......more details
Installation manualManuel d'installationFirst step for installationPremière étape pour l'installationSell sheetWiring diagramWiring diagram 575V
SL595151UL

LiftMaster Dual Voltage Slide Gate Op.1.5 HP 115/208/230V 1 Phase - Heater NOT Incl.

  • Power: 115/208/230 VAC. Single Phase.
  • Accessory power: 24VAC 500mA max.
  • Monitored safety inputs: 3 Main Board 3 Expansion Board.
  • Temperature specs: Without Heater: -4°F (-20°C) to 140°F (60°C). With optional heater (HTRNB: HTR460 for 460V operators): -40°F (-40°C) to 140°F (60°C)
  • Gate travel speed: 12 in. per second.
  • Security+2.0® on-board radio receiver: Up to 50 remote controls (unlimited with 811LM/813LM).
    • .......more details
SL595103UL

LiftMaster Dual Voltage Slide Gate Op.1 HP 208/230/460V 3 Phase - Heater NOT Incl. UL325

  • UL 325 compliant system.
  • Power: 208/230/460/575 VAC. 3 Phase.
  • Accessory power: 24VAC 500mA max.
  • Monitored safety inputs: 3 Main Board 3 Expansion Board.
  • Temperature specs: Without Heater: -4°F (-20°C) to 140°F (60°C). With optional heater (HTRNB: HTR460 for 460V operators): -40°F (-40°C) to 140°F (60°C)
  • Gate travel speed: 12 in. per second.
    • .......more details
SL595101UL

LiftMaster Dual Voltage Slide Gate Op.1 HP 115/208/230V 1 Phase - Heater NOT Incl. Reflective photocell LMRRUL included

  • Power: 115/208/230 VAC. Single Phase.
  • Accessory power: 24VAC 500mA max.
  • Monitored safety inputs: 3 Main Board 3 Expansion Board.
  • Temperature specs: Without Heater: -4°F (-20°C) to 140°F (60°C). With optional heater (HTRNB: HTR460 for 460V operators): -40°F (-40°C) to 140°F (60°C)
  • Gate travel speed: 12 in. per second.
  • Security+2.0® on-board radio receiver: Up to 50 remote controls (unlimited with 811LM/813LM).
    • .......more details
Installation manualManuel d'installationFirst step for installationPremière étape pour l'installationSell sheetWiring diagramWiring diagram 575V
VS-GSLG-723

Linear Industrial Duty Variable Speed Slide Gate Op. 2 HP 230V 3 PH

  • Up to 24" per second gate speed
  • Max gate length: 100 ft
  • Max gate weight: 4000 lbs
  • Integral APeX Controller
  • Soft start/soft stop
  • Programmable speed control
    • .......more details
Installation manualSpec sheet
SL585101UL

LiftMaster Industrial Slide Gate Op. 1 HP 115/230/208V 1 Ph Heater NOT Incl.

  • SL585UL features a heavy- duty industrial lockable metal cover.
  • Security+ 2.0® safeguards access with an encrypted tri-band signal to virtually eliminate interference and offer extended range.
  • Manual Disconnect when unlocked allows gate to be operated manually.
  • Quick Close and Anti-tailgate quickly secure property preventing unauthorized access.
  • Lockout/ tag-out Feature prevents power from being switched on when servicing operator and safeguards workers from high-voltage power.
  • Automatic Solenoid Brake prevents the gate from being back driven.
    • .......more details
Installation ManualManuel installationBrochureSell sheet
HSLG-123

Linear Commercial Slide Gate Operator 1 HP 230V 3 Ph - Heater not Included

  • Max duty cycle: Continuous
  • Integral APeX Controller
  • Double V-belt to chain reduction
  • #40 roller chain
  • Emergency manual disconnect handle
  • Powder coat finish
    • .......more details
HSLG-111

Linear Commercial Slide Gate Operator 1 HP 115V 1 Ph - Heater not Included

  • Integral entrapment sensing system with dual multi-turn precision potentiometers for accurate adjustment and enhanced safety
  • Continuous-tone entrapment alarm with reset button
  • Integrated warning beeper during gate movement
  • 15 diagnostic LEDs on board for ease of setup and troubleshooting
  • Selectable pre-start alarm with provision for ADA compliant visual pre-start and run alarm
  • On-board APeX Controller three-button control station
    • .......more details
SGP-353-1-575/3

Doorlec Gate Master 1 HP 575V/3P with Heater

  • Post mount heavy-duty industrial slide gate operator
  • Max. gate weight: 2500 lbs
  • Gate travelling speed: 45 ft / minute
  • 175 watt heater included
SGO-311-1/2HP

Doorlec Slide Gate Op. 1/2HP 120V w/500w Heater

  • Engineered to accommodate heavy duty hight frequency commercial and industrial sliding gates with cantilever overhead or roller V track application
  • It is enclosed in a heavy steel base with 500 Watt thermostatically controlled heater and lockable cover
  • Three button control O/C/S
  • Adjustable clutch
  • Solenoid brake
  • Universal mount. Left or Right side
    • .......more details
