Home Garage Door Commercial Door & Gate Operator Accessories
MWR22B

Miller Edge 2-Channel Wireless Edge Receiver RF 318 MHz

  • Power source: 12-24 volts AC/DC nominal Nominal 60 mA 140 mA activated
  • Output: N.O. N.C
  • Wire connections: Integral 18” wiring with #6 spade lugs
  • Antenna: Attached wire or F connector
  • LED Indicators: Power channel 1
  • Polycarbonate enclosure
    • .......more details
Specification SheetInstallation Manual
MWTA12B

Miller Edge Transmitter with Low Battery Alarm Small

  • The transmitter comes standard with a NEMA 4 weather-proof enclosure
  • Compact design that allow for easy troubleshooting.
  • The transmitter has an audible alarm that activates when the battery has 25% of its life remaining
  • Easy to configure · Non-monitored system ideal for operators manufactured prior to: · Doors: August 2010 · Gates: January 2016 · NEMA 4 transmitter built to endure rugged environments
  • Power Source: (2) 1.5 volts AA lithium batteries
  • Input: 2-wire N.O. sensing edge
    • .......more details
Installation manualSpec sheet
MU22-2WIRE-U-Y

Miller Edge MU22 2-Wire Universal Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MWRTA12B

Miller Edge Wireless Transmitter with Audible Alarm and 1 Channel Receiver

  • For 2-wire edges
  • Was previously MWRTA02A now has a new board making installation easier
  • Includes single channel receiver (MWR12A) and transmitter (MWTA12) with audible low battery alarm.
  • This feature that activates when the battery has only 25% of its life remaining indicating the battery should be replaced. The alarm sounds for 5 to 10 seconds at 1 to 2 minute intervals.
  • The receiver operates on either 12 or 24 volt AC/DC and provides N.O. or N.C. output.
Specification SheetInstallation Manual
AW-14

Miller Edge Air Wave Switch in ABS Box

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Molded enclosure
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
    • .......more details
Instructions ManualSell Sheet
ME123-BLK-U

Miller Edge Black Universal Outlet 2 -Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-C

Miller Edge U-Shaped PVC Mounting Channel Sold by the Foot

  • 2" Wide 1-1/4" High
MT22-GRAY-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Gray

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-BLACK-U

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Universal Outlet

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
WEL-200

EMX Wireless Edge Link Transmitter / Receiver Kit WEL-200K (4012-2)

  • Provides a complete wireless solution for interfacing sensing edges with gate and door operators
  • The Wireless Edge Link eliminates the wiring between the safety edge and operator control box
  • No wiring needed reduces installation cost
  • Compatible with NC 10K and pulse monitored outputs
  • Operates two years on two AA lithium batteries
  • Connect up to 4 safety edge transmitters
    • .......more details
Manual
MP00038

Micanan Fire Release Modification

  • For Pro-HHD
  • Can be field installed
PHOTO-061

Manaras Monitored Photoelectric Cells N4X (Fraba)

  • Monitored NEMA 4X enclosure through-beam type photocell
  • 4-Wire
  • Suited for industrial environments
  • Range: 45 ft
  • Supplied with 3ft of wire
Installation Manual
41K4629

LiftMaster CPS Interface Black Box (CPICARD)

  • Allows CPS-U photoeyes to provide a 'NO' contact
  • Interface is included with CPS & CPS-N4
  • Also known as 041K4629 1C4489 41K4629 41C4489 CPI
BEA-10-FALCN-XL

BEA Falcon-XL Motion Detector Mount under 11'5"

  • Same features as the Falcon detector but made specifically for extra low mounting
  • Mounting height between 6.5' and 11.5'
  • Detection zone: 13'x6.5' at 8 1/5'
  • Allows uni or bi-directional sensing and the unique ability to open a door when traffic is moving away from the sensor.
  • Sensor also has the ability to differentiate between pedstrians and vehicles.
  • Available remote makes it easy to make adjustments to all key parameters of the sensor while at ground level.
    • .......more details
Installation manualManuel d'installationSell sheetCut sheet
PMP12RI

Carlo Gavazzi Polarized Retro-Reflective Sensor

  • Range: 40 feet (12m)
  • Modulated invisible light polarized
  • LED- indication for target detected
  • NO and NC output
  • Suitable for exterior applications and harsh environments
  • Multi supply voltage: 12 to 240VDC and 24 to 240VAC 50/60Hz
    • .......more details
Installation Manual
REEL-20

Devanco Take-Up Reel 2-Wire Metal 18-ga 20ft Black

  • 18-gauge
  • 20 ft extended
  • Take up reels are NOT recommended for use with any failsafe type edge. Use coil cord only.
  • Also called Reel cord
  • Comes with reset button for CSA conformity
CPS-OPEN4

LiftMaster Monitored Dual-Sided Photo Eyes

  • For use with sectional or rolling doors.
  • May be installed in areas exposed to rain or moisture
  • Rubberized for more durability
  • Will work on LiftMaster residential operators
Installation ManualManuel d'InstallationSell Sheet
50-107-30

Take-Up Reel 3-Wire Metal 30ft Extended

  • 3- wire 18-gauge
  • Also called Reel Cord
CPS-U

LiftMaster Commercial Protector System Eyes

  • For LiftMaster Logic 2 3 4 & 5 commercial operators only
  • NOT for outdoor applications
  • Allows activation of the timer-to-close
  • Mounting hardware included
  • Sensing distance of 30 feet
  • CDO 2010 Ready
    • .......more details
Installation ManualManuel d'InstallationSell Sheet
3BXL

Control Station Exterior Surface Mount O/C/S N4 with Key Lockout

  • Metal Enclosure
  • Buttons aligned in a triangular pattern
  • H=4-3/8" W=4-1/8" D=2-5/8"
3BXL
