Home Your Search Miller Edge
SM102

Miller Edge Signature Module w/Junction Box for 10K (T2) Sensing Edges

  • SM-102: Converts a 10K resistive signal
  • Module: 1.8”H x 1.25”W x 0.8”D (46 x 32 x 20 mm)
  • Junction box: 1.5”H x 4”W x 2”D (38 x 102 x 51 mm)
  • Module: ABS plastic with epoxy
  • Junction box: Galvanized steel
  • Module: NEMA 4
    • .......more details
SM101

Miller Edge Signature Module for T3 Monitored Plugs w/ JB-03

  • Commercial signature module for use in commercial door and gate operators built after August 29 2010.
  • Engineered to emulate monitored pulse signal required by some commercial door operators.
  • LED light indicates device power or fault conditions.
  • Nema 4
  • Temperature range: -31F to 158F
  • 5 to 40V DC
    • .......more details
RLC-K72

Miller Edge Light Curtain Non- Monitored 6ft

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ideal for pre-2010 installations not requiring a monitored solution.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing
    • .......more details
Installation manualsell sheet
RLC-K36

Miller Edge Light Curtain Non- Monitored 3ft NO/NC

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ideal for pre-2010 installations not requiring a monitored solution.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing
    • .......more details
RG-K-P

Miller Edge Reflecti-Guard Pulsed Photo Eye Monitored 30ft Range

  • Monitored retro-reflective technology
  • Includes: (1) wired emitter/receiver with integrated mounting bracket (1) reflector (1) reflector bracket
  • 30 ft. range
  • Pulsed and relay models
  • Enhanced sunlight immunity
  • Impact resistant for rugged environments
    • .......more details
RB-TX20

Miller Edge RBand Wireless Edge Transmitter

RB-TX10C

Miller Edge RBand Monitored Wireless Edge Transmitter

  • RBand transmitter only
  • On board diagnostics allows for easy set up and troubleshooting.
  • Offers pulsed and normally open outputs.
  • Ideal for commercial door operators manufactured after 2010.
  • Bi-directional link improves immunity to RF interference.
  • Nema 4
    • .......more details
RB-P-K10C

Miller Edge RBand Monitored Wireless Door Edge System

  • RBand is a monitored sensing edge transmitter/receiver system.
  • The receiver can be paired with up to three transmitters.
  • On board diagnosticsallows for easy set up and troubleshooting.
  • Offers pulsed and normally open outputs.
  • Ideal for commercial door operators manufactured after 2010.
  • Bi-directional link improves immunity to RF interference.
    • .......more details
RB-G-K10C

Miller Edge RBand Monitored Wireless Gate Edge System

  • RBand Gate Edge Transmitter/Receiver System
  • The system is intended to provide a wireless connection between a monitored sensing edge and a motorized operator that controls the associated gate
  • The RBand Receiver is compatible with up to 3 RBand Transmitters on 2 channels; 6 total transmitters.
  • RBand meets the 2016 UL 325 requirements for monitored devices and has been certified as a UL 325 Recognized Component.
  • It is designed for use with operators that comply with 2016 UL 325 using a Miller Edge 10K Sensing Edge.
PS-20A

Miller Edge Pneumatic Air Switch in ABS Enclosure

  • Pneumatic switch offering a reliable low cost alternative to a standard electric sensing adge.
  • When attached to a hose inserted into the existing weather stripping the PS-20A acts as an effective sensing edge on doors up to 18ft in length.
  • Applications: rolling doors sectional doors and mass transit.
  • Electrical configuration: 3-wire SPDT
  • Temperature range: -20F to 158F
  • Max pressure: 20 PSI
    • .......more details
Installation Manual
MWTA12B

Miller Edge Transmitter with Low Battery Alarm Small

  • The transmitter comes standard with a NEMA 4 weather-proof enclosure
  • Compact design that allow for easy troubleshooting.
  • The transmitter has an audible alarm that activates when the battery has 25% of its life remaining
  • Easy to configure · Non-monitored system ideal for operators manufactured prior to: · Doors: August 2010 · Gates: January 2016 · NEMA 4 transmitter built to endure rugged environments
  • Power Source: (2) 1.5 volts AA lithium batteries
  • Input: 2-wire N.O. sensing edge
    • .......more details
Installation manualSpec sheet
MWTA12

Miller Edge Transmitter with Audible Alarm Small *** No Longer Available

  • The MWTA12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes with an Audible Alarm feature that activates when the battery is running low and needs to be replaced.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided.
    • .......more details
Installation ManualSell Sheet
MWT12B

Miller Edge Transmitter Binary Nema 4 Enclosure

  • The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
  • Response time: 70 milliseconds
    • .......more details
Installation Instructions MWT12BSpec Sheet MWT12BFAQ MWT12B
MWT12

Miller Edge Transmitter RF in Nema 4 Enclosure *** To Extent of Inventory

  • The MWT12 safety edge transmitter is designed to provide wireless signal transmission form the safety edge to the motor controls.
  • It is easily mounted and wired to the gate or door edge sensor. When the sensing edge comes into contact with an obstruction a closed circuit signal is created and is sent to the transmitter.
  • The transmitter relays the information to the receiver and the receiver passes the signal along to the operator motor.
  • The gate or door stops movement and will then reverse the direction of travel.
  • Comes standard with a NEMA 4 weather-proof enclosure. The enclosure can be easily mounted with the four mounting holes and screws provided
  • Response time: nominal 30msec.
    • .......more details
MWRTA12B

Miller Edge Wireless Transmitter with Audible Alarm and 1 Channel Receiver

  • For 2-wire edges
  • Was previously MWRTA02A now has a new board making installation easier
  • Includes single channel receiver (MWR12A) and transmitter (MWTA12) with audible low battery alarm.
  • This feature that activates when the battery has only 25% of its life remaining indicating the battery should be replaced. The alarm sounds for 5 to 10 seconds at 1 to 2 minute intervals.
  • The receiver operates on either 12 or 24 volt AC/DC and provides N.O. or N.C. output.
MWR22B

Miller Edge 2-Channel Wireless Edge Receiver RF 318 MHz

  • Power source: 12-24 volts AC/DC nominal Nominal 60 mA 140 mA activated
  • Output: N.O. N.C
  • Wire connections: Integral 18” wiring with #6 spade lugs
  • Antenna: Attached wire or F connector
  • LED Indicators: Power channel 1
  • Polycarbonate enclosure
    • .......more details
MWR12

Miller Edge 1-Channel Receiver RF 318 MHz *** To Extent of Inventory

  • The MWR12 receiver is designed to receive information from the transmitter and relay it to the motor to stop or reverse motion if the edge comes into contact with an obstruction.
  • Power requirements: 10 to 40 VDC 10-30 VAC
  • Output: dry relay contact N/O and N/C 1A @60VAC
  • Operating temperature: -40C to 60C
  • Maximum operating distance: 100ft
  • Electrical configuration: optional N/O or N/C
    • .......more details
Installation ManualSell Sheet
MU33-2WIRE-RH-Y

Miller Edge MU33 2-Wire NM Right Hand Yellow - Sold per Foot

  • MU style bumpers are designed for use with aircraft hanger doors and large specialty doors.
  • Must specify the exact length in feet and inches when ordering.
  • Mounts vertically or horizontally
  • Sensitivity: nominal 8-13 ibf
Worksheet
MU33-2WIRE-LH-Y

Miller Edge MU33 2-Wire NM Left Hand Yellow - Sold per Foot

  • MU style bumpers are designed for use with aircraft hanger doors and large specialty doors.
  • Must specify the exact length in feet and inches when ordering.
  • Mounts vertically or horizontally
  • Sensitivity: nominal 8-13 ibf
Worksheet
MU22-CUSTOM

Miller Edge MU22 Custom Made Edge

  • Edge made to customer's exact specifications
WorksheetInstallation manualSell sheet
MU22-4WIRE-U-Y

Miller Edge MU22 4-Wire Universal Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-4WIRE-E-Y

Miller Edge MU22 4-Wire End Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-U-Y

Miller Edge MU22 2-Wire Universal Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-U-GRY

Miller Edge MU22 2-Wire Universal Gray - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-U-BLK

Miller Edge MU22 2-Wire Universal Black - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-RH-Y

Miller Edge MU22 2-Wire Right Hand Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MU22-2WIRE-RH-G

Miller Edge MU22 2-Wire Right Hand Gray - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-RH-B

Miller Edge MU22 2-Wire Right Hand Black - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MU22-2WIRE-LH-Y

Miller Edge MU22 2-Wire Left Hand Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MU22-2WIRE-LH-G

Miller Edge MU22 2-Wire Left Hand Gray - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-LH-B

Miller Edge MU22 2-Wire Left Hand Black - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MU22-2WIRE-E-Y

Miller Edge MU22 2-Wire End Yellow - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-E-G

Miller Edge MU22 2-Wire End Gray - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MU22-2WIRE-E-B

Miller Edge MU22 2-Wire End Black - Sold per Foot

  • Electromechanical edge for sectional doors and aircraft hangars. •The MU22 is a custom edge manufactured to exact specifications. •The MU22 is completely flexible and will contour to curved surfaces. It's profile can also be square rectangular or angled. •Touch sensitive signaling allows immediate reversal or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •Vertical or horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MTAW22B-R

Miller Edge MT22 Air Wave Black Right Hand Sold by the Foot

Installation ManualSell Sheet
MT22-YELLOW-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MT22-YELLOW-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MT22-MON-Y-RH

Miller Edge 4-Wire Monitored Pressure Sensitive Edge Yellow Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-MON-Y-LH

Miller Edge 4-Wire Monitored Pressure Sensitive Edge Yellow Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-MON-GRY-RH

Miller Edge 4-Wire Monitored Pressure Sensitive Edge Gray Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-MON-GRY-LH

Miller Edge 4-Wire Monitored Pressure Sensitive Edge Gray Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-GRAY-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Gray

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-GRAY-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Gray

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-BLACK-U

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot Universal Outlet

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT22-BLACK-RH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MT22-BLACK-LH

Miller Edge 2-Wire Pressure Sensitive Edge Sold per Foot

  • Electromechanical small profile edge for rolling steel foor applicaton. •Touch sensitive signaling allows for immediate stopping or reversing of motion. •The MT22 is completely flexible and will contour to curved surfaces. The MT22 also acts as weatherstrip. •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
Installation ManualWorksheetSell Sheet
MT21-YELLOW-RH

Miller Edge 2-Wire Pressure Sensitive Edge Yellow Right Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manual
MT21-YELLOW-LH

Miller Edge 2-Wire Pressure Sensitive Edge Yellow Left Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
MT21-GRAY-RH

Miller Edge 2-Wire Pressure Sensitive Edge Gray Right Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manual
MT21-BLACK-RH

Miller Edge 2-Wire Pressure Sensitive Edge Black Right Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
WorksheetInstallation manualSell sheet
MT21-2M-YELLOW-R

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Yellow Right Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
MT21-2M-YELLOW-E

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Yellow End Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
MT21-2M-BLACK-RH

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Black Right Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
MT21-2M-BLACK-LH

Miller Edge 2-Wire Monitored Pressure Sensitive Edge Black Left Hand Outlet Sold per Foot

  • Electromechanical medium profile edge for rolling fire door applications. •Touch sensitive signaling allows for immediate reversing or stopping of motion. •The MT21 is completely felixible and will contour to curved surfaces. The MT21 will also act as weatherstrip. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Horizontal mount •ANSI/UL325 recognized component •One year warranty
MLC-K72

Miller Edge Light Curtain Monitored 6ft Pulsed

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing not recommended for carwash applications
  • Operating temperature: -40F to 140F
    • .......more details
Installation manualSell sheet
MLC-K36

Miller Edge Light Curtain Monitored 3ft Pulsed

  • Light curtain made up of a series of thru-beam photo eyes designed to provide a dense barrier of protection for motorized or high speed doors.
  • Ideal for environments that require expanded protection for protruding parts that may not be detected by standard single-beam photo eyes mounted 6" above the floor.
  • Ability to span up to 32' wide
  • Universal mounting brackets included
  • IP67 waterproof housing
  • Operating temperature: -40F to 140F
    • .......more details
Installation manualSell sheet
MIRM-T2-50

Miller Edge Patriot 2 Photo Eye Monitored 50ft Non-Contact ** Discontinued

  • Attaches directly to a Sectional door.
  • The photo eyes travel below the door during the closing cycle.
  • Unlike traditional static mount photo eyes; Patriot travels with the door sensing obstructions prior to contact.
  • The Patriot2 non-contact system consists of thru beam photo optics.
  • Emitting and receiving eyes mount into a rigid steel spring loaded retracting housing.
  • The housings attach to the bottom section of the door and extend below the leading edge of the door providing an invisible infrared light beam of protection.
    • .......more details
MIRM-T2

Miller Edge Patriot 2 Photo Eye Monitored 30ft Non-Contact ** NLA

  • Attaches directly to a Sectional door.
  • The photo eyes travel below the door during the closing cycle.
  • Unlike traditional static mount photo eyes; Patriot travels with the door sensing obstructions prior to contact.
  • The Patriot2 non-contact system consists of thru beam photo optics.
  • Emitting and receiving eyes mount into a rigid steel spring loaded retracting housing.
  • The housings attach to the bottom section of the door and extend below the leading edge of the door providing an invisible infrared light beam of protection.
    • .......more details
MIRF-Z2-50

Miller Edge Patriot 2 Photo Eye Fail Safe 50ft Non-Contact

  • Meets current UL325 standards for commercial door and gate operators*
  • Thru Beam technology minimizes false reflective signals
  • Travels with the door
  • Easy to Align
  • No need to stock special sizes - works up to 30 feet wide or up to 50 ft wide depending on the model
  • Convenient - Assemble and install in the field
    • .......more details
MIRF-Z2

Miller Edge Patriot 2 Photo Eye Fail Safe 30ft Non-Contact

  • Meets current UL325 standards for commercial door and gate operators*
  • Thru Beam technology minimizes false reflective signals
  • Travels with the door
  • Easy to Align
  • No need to stock special sizes - works up to 30 feet wide or up to 50 ft wide depending on the model
  • Convenient - Assemble and install in the field
    • .......more details
MIRF-T2

Miller Edge Patriot 2 Photo Eye Non-Monitored 30ft Non-Contact

  • Attaches directly to a Sectional door.
  • The photo eyes travel below the door during the closing cycle.
  • Unlike traditional static mount photo eyes; Patriot travels with the door sensing obstructions prior to contact.
  • The Patriot2 non-contact system consists of thru beam photo optics.
  • Emitting and receiving eyes mount into a rigid steel spring loaded retracting housing.
  • The housings attach to the bottom section of the door and extend below the leading edge of the door providing an invisible infrared light beam of protection.
    • .......more details
MIRCU-02

Miller Edge Universal Non-Monitored Interface

  • Converts a monitored pulsed signal to a non-monitored normally open signal
  • Creates a Fail Safe signal; reports a fault when power is lost
  • Ideal for use with pre-2010 commercial door operators
Installation instructionsSell sheet
MILLER-LEAD-WIRE

Miller Edge Up-Charge for Custom Length Lead Wire Sold by the Foot

  • Up charge for extra lead wire
MGS20-Y-2U-06

Miller Edge Sensing Edge Square Yellow 2-Wire Universal Outlet 6ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-Y-2U-05

Miller Edge Sensing Edge Square Yellow 2-Wire Universal Outlet 5ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-Y-2U-04

Miller Edge Sensing Edge Square Yellow 2-Wire Universal Outlet 4ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-Y-2L-05

Miller Edge Sensing Edge Square Yellow 2-Wire Left Hand Outlet 5ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-B-2U-06

Miller Edge Sensing Edge Square Black 2-Wire Universal Outlet 6ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-B-2U-05

Miller Edge Sensing Edge Square Black 2-Wire Universal Outlet 5ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-B-2U-04

Miller Edge Sensing Edge Square Black 2-Wire Universal Outlet 4ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGS20-B-2L-05

Miller Edge Sensing Edge Square Black 2-Wire Left Hand Outlet 5ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGR20-Y-2U-PER-FT

Miller Edge Sensing Edge Round Yellow 2-Wire Universal Outlet Sold Per Foot

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
  • Non-monitored edge
  • Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)
MGR20-Y-2U-06

Miller Edge Sensing Edge Round Yellow 2-Wire Universal Outlet 6ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
Installation ManualSell Sheet
MGR20-Y-2U-05

Miller Edge Sensing Edge Round Yellow 2-Wire Universal Outlet 5ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
Installation ManualSell Sheet
MGR20-Y-2U-04

Miller Edge Sensing Edge Round Yellow 2-Wire Universal Outlet 4ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates.
  • 3-sided activation allows for immediate stopping or reversing of motion
  • Contours to round or square posts.
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
    • .......more details
Installation ManualSell Sheet
MGR20-Y-2R-04

Miller Edge Sensing Edge Round Yellow 2-Wire Right Hand Outlet 4ft Long

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
MGR20-B-2U-PER-FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Sold Per Foot

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty
  • Non-monitored edge
  • Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)
MGR20-B-2U-M-P/FT

Miller Edge Sensing Edge Round Black 2-Wire Universal Outlet Monitored Sold Per Foot

  • Electromechanical edge for standard 2" round or square frame sliding sing and bi-part gates. •3-sided activation allows for immediate stopping or reversing of motion •Contours to round or square posts. •Temperature range: -30F to 155F •Lead wire: 18 gauge 2ft length •Sensitivity: nominal 6-8 PSI •2 wrie NO configuration •ANSI/UL325 recognized component •Cannot be bent •One year warranty •Monitored edge - pls specify the operator edge is connecting to •Maximum length is 10ft (over 8ft requires LTL shipment at additional cost)
MG123-BLACK-NM-U

Miller Edge Black Non-Monitored Universal Outlet 2 -Wire 2" wide x 1-1/2" high Sold by the Foot

  • The MG123 sensing edge is identical to the ME123 in shape and dimensions
  • The only difference is the rubber compound softer which makes it a bit more sensitive than ME123 (4-7 lbf vs 6-11 lbf).
  • Easy to install
  • Optimum size for 2 inch gate surfaces
  • Double-T design for added stability
  • Mounts vertically or horizontally
    • .......more details
MG020-Y-2E-P/FT

Miller Edge Sensing Edge Yellow 2-Wire End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-Y-2E-04

Miller Edge Sensing Edge Yellow 2-Wire End Outlet 4ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-Y-2E-03

Miller Edge Sensing Edge Yellow 2-Wire End Outlet 3 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-B-4E-P/FT

Miller Edge Sensing Edge Black 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-B-2E-06

Miller Edge Sensing Edge Black 2-Wire End Outlet 6ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-B-2E-05

Miller Edge Sensing Edge Black 2-Wire End Outlet 5ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-B-2E-04

Miller Edge Sensing Edge Black 2-Wire End Outlet 4ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MG020-B-2E-03

Miller Edge Sensing Edge Black 2-Wire End Outlet 3 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
MEL-T315

Miller Edge MEL Transmitter 315 MHz 2nd Generation

  • MEL provides a wireless signal transmission from an edge sensor to operator controls eliminating the need to hard wire these devices
MEL-II-TX10

Miller Edge Monitored Edge Link-II Transmitter

  • Miller Edge Monitored Edge Link II TRANSMITTER ONLY
  • Monitors the presence and function of any 10K (T2) monitored sensing edge
  • Provides a monitored wireless signal transmission from the sensor to the operator controls
  • Improved immunity to RF interference with 916 MHz operating frequency
  • Eliminates visible coil cords and retracting reels
  • Saves installation time
    • .......more details
MEFF-PAIR

Miller Edge Funny Flaps for MC22 Sold as a Pair

  • Funny Flaps for use with the MC22 Sensing Edge and are a great fit for an application where extra sensitivity is needed
  • They're necessary to fill the gap between the edge and guide within the sensing edge system and their flexible durable construction offers an alternative to more rigid standard sensing edge setups.
ME210-C3

Miller Edge Black Rigid PVC Mounting Channel "L" Shape Sold by the Foot

  • Used on CPT-210 extrusion
ME123-YELLOW-U

Miller Edge Yellow Universal Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-YELLOW-RH

Miller Edge Yellow Right Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-YELLOW-LH

Miller Edge Yellow Left Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-M-YEL-U

Miller Edge Yellow Universal 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-YEL-RH

Miller Edge Yellow RH 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-YEL-LH

Miller Edge Yellow LH 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-BLK-U

Miller Edge Black Universal 4 -Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-BLK-RH

Miller Edge Black RH 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-BLK-LH

Miller Edge Black LH 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-M-BLK-END

Miller Edge Black End 4-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-CA3

Miller Edge L-Shaped Aluminum Mounting Channel Sold by the Foot

ME123-C7

Miller Edge Flat 3-1/2" Wide PVC Mounting Channel Sold by the Foot

ME123-C3

Miller Edge L-Shaped PVC Mounting Channel Sold by the Foot

  • 2" Wide 1-1/4" High
ME123-C

Miller Edge U-Shaped PVC Mounting Channel Sold by the Foot

  • 2" Wide 1-1/4" High
ME123-BLK-U

Miller Edge Black Universal Outlet 2 -Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-BLK-RH

Miller Edge Black Right Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-BLK-LH

Miller Edge Black Left Hand Outlet 2-Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-BLK-END

Miller Edge Black End Outlet 2 -Wire 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualWorksheetSell Sheet
ME123-2M-BLK-U

Miller Edge Black Universal 2 -Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-2M-BLK-RH-T3

Miller Edge Black RH 2-Wire Monitored T3 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-2M-BLK-RH

Miller Edge Black RH 2-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-2M-BLK-LH

Miller Edge Black LH 2-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME120-Y-4E-P/FT

Miller Edge Sensing Edge Yellow 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-PC

Miller Edge Rigid PVC Mounting Channel Sold per Foot

ME120-C

Miller Edge Aluminum Mounting Channel Sold per Foot

  • 1-1/16" Wide 9/16" High
ME120-BLK-E-6FT

Miller Edge 2-Wire Black End Outlet 6 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-BLK-E-5FT

Miller Edge 2-Wire Black End Outlet 5 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-BLK-E-4FT

Miller Edge 2-Wire Black End Outlet 4 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-BLK-2WIRE-R

Miller Edge Black 2-Wire NM Right Hand Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-2WIRE-L

Miller Edge Black 2-Wire NM Left Hand Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-2WIRE-E

Miller Edge Black 2-Wire End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-B-4E-P/FT

Miller Edge Sensing Edge Black 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME117-M-BLK-U

Miller Edge 4-Wire Monitored Black Universal Outlet Sold by the Foot

  • Electromechanical slide in edge for 1" to 2" sectional doors.
  • Touch sensitive signaling allows for immediate stopping or reversing of motion. The ME117 is resistant to water flame and most common greases and oils.
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation manualSell sheet
ME117-C7

Miller Edge PVC Mounting Channel Sold by the Foot

ME117-2W-BLK-U

Miller Edge 2-Wire Black Universal Outlet Sold by the Foot

  • Electromechanical slide in edge for 1" to 2" sectional doors.
  • Touch sensitive signaling allows for immediate stopping or reversing of motion. The ME117 is resistant to water flame and most common greases and oils.
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation manualSell sheet
ME116-BLK-U

Miller Edge Black Universal Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME116-BLK-RH

Miller Edge Black Right Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME116-BLK-LH

Miller Edge Black Left Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME113-R

Miller Edge Black Right Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors
  • Retrofits easily to 1-1/4" to 1-1/2" sectional doors
  • Touch sensitive signaling allows for immedita stopping or reversing of motion
  • For a sectional door: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order.
  • Lead wire: 22 gauge universal
    • .......more details
Installation ManualWorksheetSell Sheet
ME113-L

Miller Edge Black Left Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors
  • Retrofits easily to 1-1/4" to 1-1/2" sectional doors
  • Touch sensitive signaling allows for immedita stopping or reversing of motion
  • For a sectional door: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order.
  • Lead wire: 22 gauge universal
    • .......more details
Installation ManualWorksheetSell Sheet
ME113-E

Miller Edge Black End Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors
  • Retrofits easily to 1-1/4" to 1-1/2" sectional doors
  • Touch sensitive signaling allows for immedita stopping or reversing of motion
  • For a sectional door: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order.
  • Lead wire: 22 gauge universal
    • .......more details
Installation ManualWorksheetSell Sheet
ME113-C7

Miller Edge PVC Mounting Channel Flat Sold by the Foot

ME113-C3

Miller Edge PVC Mounting Channel "L" Shape Sold by the Foot

ME113-4WIRE-E

Miller Edge Black End Outlet 4-Wire Monitored 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors
  • Retrofits easily to 1-1/4" to 1-1/2" sectional doors
  • Touch sensitive signaling allows for immedita stopping or reversing of motion
  • For a sectional door: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order.
  • Lead wire: 22 gauge universal
    • .......more details
WorksheetInstallation manualSell sheet
ME112-R

Miller Edge Black 2W Non Monitored RH Outlet 1-5/16" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors and gates.
  • Retrofits easily to 1" to 1-1/4" sectional doors
  • Touch sensitive signaling allows for immediate stopping/reversing of motion
  • For sectional doors: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order
  • Lead wire: 22 gauge univversal
    • .......more details
Installation ManualWorksheetSell Sheet
ME112-L

Miller Edge Black 2W Non Monitored LH Outlet 1-5/16" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors and gates.
  • Retrofits easily to 1" to 1-1/4" sectional doors
  • Touch sensitive signaling allows for immediate stopping/reversing of motion
  • For sectional doors: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order
  • Lead wire: 22 gauge univversal
    • .......more details
Installation ManualWorksheetSell Sheet
ME112-E

Miller Edge Black 2W Non Monitored End Outlet 1-5/16" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors and gates.
  • Retrofits easily to 1" to 1-1/4" sectional doors
  • Touch sensitive signaling allows for immediate stopping/reversing of motion
  • For sectional doors: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order
  • Lead wire: 22 gauge univversal
    • .......more details
Installation ManualWorksheetSell Sheet
ME112-C4

Miller Edge Clima-Guard U-Shaped PVC Mounting Channel Sold by the Foot

ME112-C3

Miller Edge L-Shaped PVC Mounting Channel Sold by the Foot

ME111-R

Miller Edge Black Right Hand Outlet 7/8" wide x 1-1/2" high Sold by the Foot

  • Slide in style edge for barrier gate and counter shutter application.
  • Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
  • Lead wire: AWM 22 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
  • Vertical or horizontal mount
  • ANSI/UL325 recognized component
    • .......more details
Installation ManualWorksheetSell Sheet
ME111-L

Miller Edge Black Left Hand Outlet 7/8" wide x 1-1/2" high Sold by the Foot

  • Slide in style edge for barrier gate and counter shutter application.
  • Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
  • Lead wire: AWM 22 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
  • Vertical or horizontal mount
  • ANSI/UL325 recognized component
    • .......more details
Installation ManualWorksheetSell Sheet
ME111-E

Miller Edge Black End Outlet 7/8" wide x 1-1/2" high Sold by the Foot

  • Slide in style edge for barrier gate and counter shutter application.
  • Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
  • Lead wire: AWM 22 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
  • Vertical or horizontal mount
  • ANSI/UL325 recognized component
    • .......more details
Installation ManualWorksheetSell Sheet
ME111-4WIRE-M-RH

Miller Edge 4-Wire Monitored Black Right Hand Outlet 7/8" wide x 1-1/2" high Sold by the Foot

  • Slide in style edge for barrier gate and counter shutter application.
  • Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •Temperature Range: -30F to 155F
  • Lead wire: AWM 22 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
  • Vertical or horizontal mount
  • ANSI/UL325 recognized component
    • .......more details
WorksheetInstallation manualSell sheet
ME111-2L-T2

Miller Edge Black Left Hand Outlet Monitored 7/8" wide x 1-1/2" high Sold by the Foot

  • Slide in style edge for barrier gate and counter shutter application.
  • Touch sensitive signaling allows for immediate stopping/reversing of motion depending on application. •10K ohm resistor •Temperature Range: -30F to 155F
  • Lead wire: AWM 22 gauge 2ft length
  • Sensitivity: nominal 6-8 PSI
  • Vertical or horizontal mount
  • ANSI/UL325 recognized component
    • .......more details
Installation ManualWorksheetSell Sheet
ME110-M-2W-BLK-E

Miller Edge Monitored 2-Wire Black End Outlet 7/8" wide x 3/4" high Sold by the Foot

  • Electromechanical slide in edge for counter shutters rolling doors and barrier arm applications.
  • Touch sensitive signaling that allows for immediate stopping and reversing of motion.
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Worksheet
ME110-C3

Miller Edge Black Rigid PVC Mounting Channel Double-Sided Tape Sold by the Foot

  • 7/8" length
ME110-C

Miller Edge PVC Mounting Channel Sold by the Foot

  • 7/8" length
ME110-2W-BLK-R

Miller Edge 2-Wire Black Right Hand Outlet 7/8" wide x 3/4" high Sold by the Foot

  • Electromechanical slide in edge for counter shutters rolling doors and barrier arm applications.
  • Touch sensitive signaling that allows for immediate stopping and reversing of motion.
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Worksheet
ME110-2W-BLK-L

Miller Edge 2-Wire Black Left Hand Outlet 7/8" wide x 3/4" high Sold by the Foot

  • Electromechanical pressure sensitive edge for counter shutters rolling doors and barrier arm applications.
  • Touch sensitive signaling that allows for immediate stopping and reversing of motion.
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration.
    • .......more details
Worksheet
ME110-2W-BLK-E

Miller Edge 2-Wire Black End Outlet 7/8" wide x 3/4" high Sold by the Foot

  • Electromechanical slide in edge for counter shutters rolling doors and barrier arm applications.
  • Touch sensitive signaling allows for immediate stopping and reversing of motion.
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Worksheet
MC271-2W-RH-GRAY

Miller Edge MC271 2-Wire Non-Monitored Right Hand Gray Includes End Flaps - Sold per Foot

  • Ideal for Cornell double angle bottom bar
  • Flexible and will conform to floor irregularities
  • Optimum size for 2+ inch thick surfaces
  • Custom manufactured to user specifications for color length and outlet location
  • 5-inch end flaps create a complete seal and can be trimmed for custom fit
  • Sealed assembly impervious to dust and debris
    • .......more details
MC271-2W-RH-BLK

Miller Edge MC271 2-Wire Non-Monitored Right Hand Black Includes End Flaps - Sold per Foot

  • Ideal for Cornell double angle bottom bar
  • Flexible and will conform to floor irregularities
  • Optimum size for 2+ inch thick surfaces
  • Custom manufactured to user specifications for color length and outlet location
  • 5-inch end flaps create a complete seal and can be trimmed for custom fit
  • Sealed assembly impervious to dust and debris
    • .......more details
MC271-2MON-RH-GY

Miller Edge MC271 2-Wire Monitored Right Hand Gray Includes End Flaps - Sold per Foot

  • Ideal for Cornell double angle bottom bar
  • Flexible and will conform to floor irregularities
  • Optimum size for 2+ inch thick surfaces
  • Custom manufactured to user specifications for color length and outlet location
  • 5-inch end flaps create a complete seal and can be trimmed for custom fit
  • Sealed assembly impervious to dust and debris
    • .......more details
MC22-2WIRE-RH-BLK

Miller Edge MC22 2-Wire Non-Monitored Right Hand Black Includes Funny Flaps - Sold per Foot

  • Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty
Worksheet
MC22-2WIRE-LH-G

Miller Edge MC22 2-Wire Non-Monitored Left Hand Gray Includes Funny Flaps - Sold per Foot

  • Electromechanical sensing edge for use on Cornell doors. •The MC22 is manufactured to exact specifications. •The MC22 is completely flexible and will contour to curved surfaces. •Touch sensitive signaling allows immediate reversing or stopping of motion. •Temperature range: -30F to 155F •Lead wire: 22 gauge universal •Sensitivity: nominal 6-8 PSI •2 wire NO configuration •Vertical or horizontal mount •One year warranty
Worksheet
MAW123-YEL-RH

Miller Edge Air-Wave Edge Yellow Sold per Foot

  • This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
  • When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
  • It has been designed to fit most doors with double track bottom retainers.
  • With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
  • The MAW123 is resistant to flame water and most common greases and oils.
MAW123-BLK-U

Miller Edge Air-Wave Edge Black Sold per Foot

  • This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
  • When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
  • It has been designed to fit most doors with double track bottom retainers.
  • With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
  • The MAW123 is resistant to flame water and most common greases and oils.
MAW123-BLK-RH

Miller Edge Air-Wave Edge Black Sold per Foot

  • This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
  • When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
  • It has been designed to fit most doors with double track bottom retainers.
  • With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
  • The MAW123 is resistant to flame water and most common greases and oils.
MAW123-BLK-LH

Miller Edge Air-Wave Edge Black Sold per Foot

  • This pressure sensitive air-wave edge can be adapted to suit a wide variety of applications.
  • When touch activated the MAW123 sends an immediate pulse of air through the extrusion to an air-wave switch which sends a signal to controls to stop and/or reverse operations.
  • It has been designed to fit most doors with double track bottom retainers.
  • With appropriate mounting channel this edge will fit nearly all doors from 11/2" to 2" thick.
  • The MAW123 is resistant to flame water and most common greases and oils.
JB-02P-W

Miller Edge Junction Box Nema 4

  • For use with commercial door operators and CPT sensing edges from Miller Edge
  • Waterproof
  • Accommodates wire .181 to .312
Installation instructions
JB-02

Miller Edge Junction Box Metal

  • For commercial overhead doors that use coil cords or retracting reels
  • Standard metal junction box with cover
  • Includes 1 x 90-degree connector 1 straight connector
  • Includes strain relief + 2 wire nuts + pop-out holes
  • For single-angle bottom bar of rolling steel door
  • Also compatible with sectional door
    • .......more details
IG2-P1

Miller Edge Pair of Pedestal Mounts for IG2 Eyes

  • Flexible spring loaded pedestal stand
  • 30 degree of flex
  • 27" high from bottom base to photoeye
IG2-EXT-MNT

Miller Edge Wall Mount Extension Bracket

  • 1 ft L x 2" H x 3" W
IG2-B1

Miller Edge Protective Boot Covering for IG2 Eyes Sold as a Pair

EIM-101

Miller Edge Electronic Interface Module w/Junction Box (JB-02P-W)

  • Designed for use with pre-UL325-2010 commercial door operators and Miller Edge CPT sensing edges.
  • It's a durable weather-resistant solution housed in a NEMA 4-rated junction box.
  • This module is particularly suited for overhead doors using retracting reels or coil cords
CPT215-PER-FOOT

Miller Edge Field Configurable Sensing Edge Cut-to-Length

  • For do-it-yourself edges on sectional or rolling doors.
  • Black extrusion flexible PVC conductive polymer Ends: Molded polymer
  • End plugs and mounting channel sold separately.
  • Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
  • When combined with the ME123 mounting channel ideal for 2" thick surfaces
  • Minimum Length: 3ft
    • .......more details
CPT215-END-KIT-T3

Miller Edge End Kit for CPT215 Doide Capacitor (T3) Configuration

  • Kit contains: 2) Caps (2) cages (1) wired plug (1) diode capacitor plug (1) non-mon. plug (2) screws
CPT215-END-KIT-T2

Miller Edge End Kit for CPT215 10K Ohm Resistor (T2) Configuration

  • Kit contains: (2) Caps (2) cages (1) wired plug (1) 10K plug (1) non-mon. plug (2) screws
  • No glue is required
CPT210-END-KIT-U

Miller Edge Universal End Kit for CPT210

  • Kit contains: 2) Caps (2) cages (1) wired plug (1) 10K plug (1) 8.2K plug (1) diode capacitor plug (1) non-mon. plug end plug (2) screws
CPT210-C3

Miller Edge PVC Mounting Channel "L" Shape Sold by the Foot *** Disc. Repl by ME210-C3

  • Used on CPT-210 extrusion
CPT-223-PER-FT

Miller Edge Bulk Extrusion Sold per Foot

  • For DIY quick fixes to repair or replace sensing edges for sectional and rolling steel doors measuring 1-1/2" to 2" thick with a mounting channel.
  • Sensivity: 15lbs max activation
  • Lead wire 18"-22 gauge unversal
  • Wire configuration: N.O.
  • Electrical interface: sealed module- provides seamless connection to logic or relay type operators
  • ANSI/UL325 recognized component
    • .......more details
CPT-223-K5

Miller Edge Non-Monitored End Plug Kit

  • For use with the CPT-223-50 bulk extrusion
  • Kit includes: 5 wired 5 Non-Monitored end plugs and 5 1/8oz tube of vinyl adhesive
  • One kit is enough to make 5 non-monitored edges
CPT-223-50

Miller Edge Bulk Extrusion 50' roll

  • For DIY quick fixes to repair or replace sensing edges for sectional and rolling steel doors measuring 1-1/2" to 2" thick with a mounting channel.
  • Sensivity: 15lbs max activation
  • Lead wire 18"-22 gauge unversal
  • Wire configuration: N.O.
  • Electrical interface: sealed module- provides seamless connection to logic or relay type operators
  • ANSI/UL325 recognized component
    • .......more details
CPT-215-50

Miller Edge Field Configurable Sensing Edge 50 ft Roll

  • For do-it-yourself edges on sectional or rolling doors.
  • Black extrusion flexible PVC conductive polymer Ends: Molded polymer
  • End plugs and mounting channel sold separately.
  • Sensing edge size: 1-5/8"H (41mm) x 1-11/16"W (42mm)
  • When combined with the ME123 mounting channel ideal for 2" thick surfaces
  • Lead Wire 12 in. 22 gauge SJTO
    • .......more details
CPT-210-K5

Miller Edge Non-Monitored End Plug Kit *** Discontinued

  • For use with CPT-210-50 bulk extrusion
  • Kit includes: 5 wired 5 non-wired end-plugs 1oz tube of adhesive
CPT-210-50

Miller Edge Bulk Extrusion 50 ft Roll

  • For do-it-yourself edges on sectional or rolling doors.
  • Black
  • End plugs adhesive and mounting channel sold separately.
  • Sensing edge size: 1-5/8"H x 1-3/4"W
  • When combined with the ME123 mounting channel it can be installed on doors measuring 1-1/2" to 2" thick.
Installation ManualSell Sheet
CPS-MEI

LiftMaster Electric Edge Card **to extent of inventory

  • The CPS-MEI is an interface for a monitored 2-wire edge that can be used in place of photo eyes and meets the monitored requirement of UL325-2010
  • Same as Miller Edge SM-102
CG-4W-MON-BLK-RH

Miller Edge Clima-Guard 4-Wire Monitored Black Right Hand Outlet Sold by the Foot

  • Clima-Guard functions exactly like a pressure sensitive electric edge but with an added layer of protection.
  • The protective loop seal conforms to irregularities in the floor and helps prevent air infiltration and serves as a weather barrier.
  • ClimaGuard is made up of an ME112 sensing edge paired with a PVC loop seal that comes with a double slot mounting channel.
  • Electrical Configuration: Normally open
  • this edge comes with the channel
AW14K500-18-RF

Miller Edge Air Wave Edge System Trans/Recvr 18ft Non-Monitored

  • AW14-RF MRF-01 RAH-500 (18') P50 P-50H 218-27-18
  • AW14-RF-K10 end plug connector plug 1/2”-18 ft. hose
AW14K500-18

Miller Edge Air Wave Kit 18ft No Coil Cord

  • AW14 18ft. of RAH-500 P-50H 218-27-18 P50
  • Kit Includes: AW14 Air Wave Switch Barbed Coupler (18') RAH-500 1/2" dia. Rubber Hose Wire Nuts End Plugs
AW14K500-12

Miller Edge Air Wave Kit 12ft No Coil Cord

  • AW14 12ft. of RAH-500 P-50H 218-27-18 P50
  • Kit Includes: AW14 Air Wave Switch Barbed Coupler (12') RAH-500 1/2" dia. Rubber Hose Wire Nuts End Plugs
AW14-RF-K10

Miller Edge Wireless Air Wave Switch Transmitter/Receiver Kit

  • AW14-RF is the AW14 air wave switch with a transmitter embedded within the switch enclosure and the receiver wires into the operator.
  • There is no need to hardwire coil cords or retracting reels which saves installation time and improves visual aesthetics.
  • The AW-14-RF-K10 switch kit includes a MRF-01 receiver which is wired to the motor controls.
  • Battery is included # CR2032
Installation ManualSell Sheet
AW12K500-18

Miller Edge Air Wave Kit 18ft No Coil Cord

  • Kit Includes: AW12 Air Wave Switch Barbed Coupler (18') RAH-500 1/2" dia. Rubber Hose Wire Nuts End Plugs
AW12K500-12

Miller Edge Air Wave Kit 12ft No Coil Cord**Discontinued

  • Kit Includes: AW12 Air Wave Switch Barbed Coupler (12') RAH-500 1/2" dia. Rubber Hose Wire Nuts End Plugs
AW-14

Miller Edge Air Wave Switch in ABS Box

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Molded enclosure
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
    • .......more details
Instructions ManualSell Sheet
AW-12A

Miller Edge Air Wave Switch in NEMA 4 Enclosure

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
  • Ambient temperature range: -49F to 180F
    • .......more details
Instructions ManualSell Sheet
AW-10

Miller Edge Air Wave Switch Only No Enclosure

  • Air pressure is lead via a hose or pipe to a diaphragm contact. This contact converts the positive or negative pressure into an electrical contact and pulse.
  • Applications: commercial sectional doors rolling doors and mass transit
  • Works on doors up to 60ft
  • Can be used with standard pneumatic hose and Miller Edge extrusion
  • Sensitivity: 2mm to 500mm
  • Ambient temperature range: -49F to 180F
    • .......more details
Instruction manualSell sheet
