BEA-10FALCON-EX30

BEA Falcon Motion Detector w/Exp Proof Housing 30ft Cable

  • FALCON EX combines a microwave activation sensor with an explosion-proof/flame-proof housing
  • Ideal for use in unique environments such as chemical manufacturing petroleum refining and agriculture.
  • FALCON EX can be mounted from 11.5' to 23' to fit any industrial application.
  • Nema4/IP66
  • Detection Zone: Falcon EX: 13’×16’ at 16’
  • Operating temperature: -22 to 140F
    • .......more details
BEA-10LIGHT-A

BEA Modular LED Signal Light Audible Segment

  • Audible Alarm 2.6 KHz ±250 Hz oscillation frequency; maximum intensity 92 dB @ 39.6 in
BEA-10LIGHT-TBASE

BEA Modular LED Signal Base

  • To be used with the BEA-10LIGHT modules.
User GuideDatasheet
BEA-10LIGHT-TG

BEA Modular LED Signal Light Segment Green

  • Signal lights for industrial and vehicle flow management applications.
  • LED signal modular lights offer customizable configurations with “build-your-own” lighting elements that share a common base and bracket.
  • These LED signal units are available in red green yellow and an audible alarm cap and can be stacked in a tower configuration with up to six modules.
  • Operating temperature: -40 to 122F
  • Nema 4/IP65
  • Base sold separately
    • .......more details
User GuideDatasheet
BEA-10LIGHT-TR

BEA Modular LED Signal Light Segment Red

  • Signal lights for industrial and vehicle flow management applications.
  • LED signal modular lights offer customizable configurations with “build-your-own” lighting elements that share a common base and bracket.
  • These LED signal units are available in red green yellow and an audible alarm cap and can be stacked in a tower configuration with up to six modules.
  • Operating temperature: -40 to 122F
  • Nema 4/IP65
  • Base sold separately
    • .......more details
User GuideDatasheet
BEA-10LIGHTBKT-TL

BEA Modular LED Signal Light Bracket

  • Bracket only for modular LED lights.
BEA-10PS12-24

BEA Power Supply UL/ULC Listed

BEA-10T300PB

BEA Wired Transmitter Push Button No Case 300 MHz

  • 300MHz Analog Flag Connector Transmitter
  • For All Activation Plates Except Jamb and Vestibule 9V Battery
  • 10 dip switch access code programming
  • Operating temperature: -10 to 55C
BEA-10ULTIMO

BEA Automatic Sliding Door Sensor

  • Dual technology sensor for sliding doors: the microwave motion field activates as people/objects approach as the infrared curtains ensure the safety of pedestrians passing through the door opening.
  • Provides uniform sensitivity across the curtain.
  • Ideal for high-traffice environments such as hospitals hotels airports or retail facilities.
  • Mounting height: 6'6 to 11'6 •Operating temperature: -13 to 131F
  • IP54
Installation Manual Manuel d-InstallationSell Sheet
BEA-35-1242

BEA 30' Harness 8-Conductor LZR

  • Power cable LZR-I100
BEA-35-1555

BEA 50' of Cable Only for LZR Widescan

  • Optional 50 ft cable for use with the LZR-WIDESCAN
BEA-35-1566

BEA Power Cable RS-20US IS40

  • Replacement power cable only 35.1566
  • Replaces 35-1195
  • RS-20 US-Colored. Cable gland M16
BEA-LZR-I30

BEA Laser Scanner for Ind. Automation Time of Flight Sensor Nema 4

  • The product configuration provides four laser-based curtains offering a three dimensional safety zone each capable of 360 in x 360 in (30 ft x 30 ft)
  • Designed for the detection of people and vehicles in both indoor and outdoor environments
  • The detection accuracy makes this sensor ideal for high performance industrial doors vehicle flow safety perimeter protection and a variety of applications. Detects objects as small as 2 inches at 30 feet away
  • IP65
  • Operating temperature: -22 to 140F
  • Three visible LED spots provide accurate reference points when adjusting the tilt angle.
    • .......more details
Installation manualSell sheet
BEA-LZR-S600

BEA LZR-S600 Lazer-Based Time of Flight Sensor

  • The product configuration provides four LASER-based curtains offering a three dimensional presence detection zone.
  • This sensor is ideal for perimeter security protection industrial automation and large industrial door / gate applications that require a wide field of detection
  • The LZR®-S600 is housed in an IP65 rated enclosure and can be installed in outdoor industrial and other harsh environments.
  • Three visible LED spots provide accurate reference points when adjusting the tilt angle.
  • Parameter adjustments can be made with a BEA universal remote control.
  • Maximum detection range of 82 × 82 ft
    • .......more details
BEA-LZR-WIDESCAN

BEA Widescan LZR Motion Sensor Time of Flight

  • Should only be mounted Left Hand or Centre Mount
  • Time-of-flight lazor sensor used for motion safety & presence detection
  • Offers the benefits of activation & safety while reducing installation time.
  • Can detect objects based on direction speed object size & height.
  • The detection field operates independent of ground conditions allowing for superior functionality in harsh environments.
  • Ideal for replacing costly/labor-intensive induction loop & pull-cord solutions
    • .......more details
Mechanical InstallationSell sheet
BEA-REMOTE

BEA Falcon/LZR Programming Remote

  • Makes it easy to set up and make adjustments to all key parameters of the Falcon motion detector while at ground level
Programming instructions
BEARING005

Manaras Flange Bearing ID 5/8"

  • Flange bearing for 5/8" shaft
BEARING006

Manaras Flange Sealed Bearing 5/8"

  • Flange sealed bearing for 5/8" shaft
BEARING007

Manaras Flange Bearing ID 1"

  • Flange bearing for 1" shaft
BEARING012

Manaras Flange Bearing Green for 1' bore ** Repl. by BEARING047

  • 15/32" bolt holes
