ME113-R

Miller Edge Black Right Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Slide in edge designed for commercial sectional doors
  • Retrofits easily to 1-1/4" to 1-1/2" sectional doors
  • Touch sensitive signaling allows for immedita stopping or reversing of motion
  • For a sectional door: measure the daylight opening of the door or measure the panel width of the door
  • This gives you the "active length" of the edge - the length to order.
  • Lead wire: 22 gauge universal
    • .......more details
Installation ManualWorksheetSell Sheet
ME116-BLK-LH

Miller Edge Black Left Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME116-BLK-RH

Miller Edge Black Right Hand Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME116-BLK-U

Miller Edge Black Universal Outlet 2-Wire 1-1/2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide-in edge for sectional doors.
  • With appropriate mounting channel this edge will fit nearly all doors from 1-1/2" to 2" thick. The ME116 has been designed to fit all CHI doors with double track bottom retainers.
  • ME116 is resistant to flame water and most common greases and oils
  • Soft ends
  • Temperature range -30F to 155F
  • Lead wire: 22 gauge universal
    • .......more details
ME117-2W-BLK-U

Miller Edge 2-Wire Black Universal Outlet Sold by the Foot

  • Electromechanical slide in edge for 1" to 2" sectional doors.
  • Touch sensitive signaling allows for immediate stopping or reversing of motion. The ME117 is resistant to water flame and most common greases and oils.
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation manualSell sheet
ME117-C7

Miller Edge PVC Mounting Channel Sold by the Foot

ME117-M-BLK-U

Miller Edge 4-Wire Monitored Black Universal Outlet Sold by the Foot

  • Electromechanical slide in edge for 1" to 2" sectional doors.
  • Touch sensitive signaling allows for immediate stopping or reversing of motion. The ME117 is resistant to water flame and most common greases and oils.
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
Installation manualSell sheet
ME120-B-4E-P/FT

Miller Edge Sensing Edge Black 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-2WIRE-E

Miller Edge Black 2-Wire End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-2WIRE-L

Miller Edge Black 2-Wire NM Left Hand Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-2WIRE-R

Miller Edge Black 2-Wire NM Right Hand Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME120-BLK-E-4FT

Miller Edge 2-Wire Black End Outlet 4 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-BLK-E-5FT

Miller Edge 2-Wire Black End Outlet 5 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-BLK-E-6FT

Miller Edge 2-Wire Black End Outlet 6 ft Long

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
Installation ManualSell Sheet
ME120-C

Miller Edge Aluminum Mounting Channel Sold per Foot

  • 1-1/16" Wide 9/16" High
ME120-PC

Miller Edge Rigid PVC Mounting Channel Sold per Foot

ME120-Y-4E-P/FT

Miller Edge Sensing Edge Yellow 4-Wire Monitored End Outlet Sold per Foot

  • Electromechanical slide in edge with a small profile for motorized gates and doors rolling shutters and pinch point protection applications.
  • Touch sensitive signaling
  • Temperature range: -30F to 155F
  • Lead wire: 18 gauge 2ft length
  • Sensitivity: nominal 4 PSI
  • 2 wire NO configuration
    • .......more details
ME123-2M-BLK-LH

Miller Edge Black LH 2-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-2M-BLK-RH

Miller Edge Black RH 2-Wire Monitored 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
ME123-2M-BLK-RH-T3

Miller Edge Black RH 2-Wire Monitored T3 2" wide x 1-1/2" high Sold by the Foot

  • Electromechanical slide in edge for sectional doors and sliding gates.
  • Touch sensitive singaling allows for immediate stopping and reversing of motion
  • Temperature range: -30F to 155F
  • Lead wire: 22 gauge universal
  • Sensitivity: nominal 6-8 PSI
  • 2 wire NO configuration
    • .......more details
WorksheetInstallation manualSell sheet
